DTCDetection Item ABS Indicator Brake System
Indicator Note
19-52ABS Components
DTC Troubleshooting Index
11 -13 Right-front Wheel Speed Sensor Circuit Malfunction
ONON/OFF (see page 19-65)
12 -11 Right-front Wheel Speed Sensor Electrical Noise or Intermittent Interruption ON
ON/OFF (see page 19-68)
-12 Right-front Wheel Speed Sensor Short to the Other Sensor Circuit ONON/OFF (see page 19-69)
-21 Right-front Wheel Speed Sensor Installation Error ONON/OFF (see page 19-71)
-22 Right-front Wheel Speed Sensor Installation Error (30 km/h (19 mph) or More) ON
ON/OFF (see page 19-71)
-23 Right-front Wheel Speed Sensor Installation Error (0 to 15 km/h (0 to 9 mph) ) ON
ON/OFF (see page 19-72)
13 -13 Left-front Wheel Speed Sensor Circuit Malfunction ONON/OFF (see page 19-65)
14 -11 Left-front Wheel Speed Sensor Electrical Noise or Intermittent Interruption ON
ON/OFF (see page 19-68)
-12 Left-front Wheel Speed Sensor Short to the Other Sensor Circuit ONON/OFF (see page 19-69)
-21 Left-front Wheel Speed Sensor Installation Error ONON/OFF (see page 19-71)
-22 Left-front Wheel Speed Sensor Installation Error (30 km/h (19 mph) or More) ON
ON/OFF (see page 19-71)
-23 Left-front Wheel Speed Sensor Installation Error (0 to 15 km/h (0 to 9 mph) ) ON
ON/OFF (see page 19-72)
15 -13 Right-rear Wheel Speed Sensor Circuit Malfunction ONON/OFF (see page 19-65)
16 -11 Right-rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption ON
ON/OFF (see page 19-68)
-12 Right-rear Wheel Speed Sensor Short to the Other Sensor Circuit ONON/OFF (see page 19-69)
-21 Right-rear Wheel Speed Sensor Installation Error ONON/OFF (see page 19-71)
-22 Right-rear Wheel Speed Sensor Installation Error (30 km/h (19 mph) or More) ON
ON/OFF (see page 19-71)
-23 Right-rear Wheel Speed Sensor Installation Error (0 to 15 km/h (0 to 9 mph) ) ON
ON/OFF (see page 19-72)
17 -13 Left-rear Wheel Speed Sensor Circuit Malfunction ONON/OFF (see page 19-65)
18 -11 Left-rear Wheel Speed Sensor Electrical Noise or Intermittent Interruption ON
ON/OFF (see page 19-68)
-12 Left-rear Wheel Speed Sensor Short to the Other Sensor Circuit ONON/OFF (see page 19-69)
-21 Left-rear Wheel Speed Sensor Installation Error ONON/OFF (see page 19-71)
-22 Left-rear Wheel Speed Sensor Installation Error (30 km/h (19 mph) or More) ON
ON/OFF (see page 19-71)
-23 Left-rear Wheel Speed Sensor Installation Error (0 to 15 km/h (0 to 9 mph) ) ON
ON/OFF (see page 19-72)
21 -11 Right-front Magnetic Encoder (Wheel Bearing) Malfunction (Pulse Missing) ON
ON/OFF (see page 19-72)
22 -11 Left-front Magnetic Encoder (Wheel Bearing) Malfunction (Pulse Missing) ON
ON/OFF (see page 19-72)
23 -11 Right-rear Magnetic Encoder (Wheel Bearing) Malfunction (Pulse Missing) ON
ON/OFF (see page 19-72)
24 -11 Left-rear Magnetic Encoder (Wheel Bearing) Malfunction (Pulse Missing) ON
ON/OFF (see page 19-72)
31 -01 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Initial Pulse) ON
ON (see page 19-73)
-21 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Pulse) ON
ON (see page 19-73)
-22 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Speculative) ON
ON (see page 19-73)
-23 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Stuck ON) ON
ON (see page 19-73)
32 -01 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Initial Pulse) ON
ON (see page 19-73)
-21 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Pulse) ON
ON (see page 19-73)
-22 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Speculative) ON
ON (see page 19-73)
-23 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Stuck ON) ON
ON (see page 19-73)
33 -01 ABS Left-front Inlet Solenoid Valve Malfunction (Solenoid Initial Pulse) ON
ON (see page 19-73)
-21 ABS Left-front Inlet Solenoid Valve Malfunction (Solenoid Pulse) ON
ON (see page 19-73)
-22 ABS Left-front Inlet Solenoid Valve Malfunction (Solenoid Speculative) ON
ON (see page 19-73)
-23 ABS Left-front Inlet Solenoid Valve Malfunction (Solenoid Stuck ON) ON
ON (see page 19-73)
: Brake system indicator turns ON when two or more wheels fail.
