Page 1857 of 2893

(#'
)
20-170Exterior Trim
Emblem/Sticker Replacement
FRONT ’’A’’ EMBLEM
REAR ’’A’’ EMBLEM
CSX EMBLEM
FRONT GRILLE BASE REAR ’’A’’ EMBLEM
ADHESIVE
TAPE
TRUNK LIDCLIP
CSX EMBLEM
Edge of the trunk lid
20 (0.79) ACURA EMBLEM
SCREWS
33
(1.3) 24
(0.94)
55
(2.17)
Edge of the inner taillight
Edge of the trunk lid
ACURA EMBLEM TYPE-S EMBLEM
(For some models)
Unit: mm (in.)
Adhesive tape: Thickness 0.8 mm (0.03 in.)
FRONT ’’A’’ EMBLEM
Edge of the trunk lidEdge of the inner taillight
104.5
(4.12)
21 (0.83)
17 (0.67)
22 (0.87)
CSX EMBLEM
TYPE-S EMBLEM
(For some models)
NOTE: When removing the emblems, take care not to scratch the body.1. To remove the front ‘‘A’’ emblem, remove the front grille (see page 20-160).
2. Clean the body surface with a shop towel dampened in isopropyl alcohol. After cleaning, keep oil, grease, and water from getting on the surface.
3. Apply the emblem where shown.
4. After installing the front ‘‘A’’ emblem, reinstall the front grille.
08/08/21 15:05:05 61SNR030_200_0172
ProCarManuals.com
DYNOMITE -2009-
Page 1858 of 2893

(#'
)
20-171
Fenderwell
Front Inner Fender Replacement
Fastener Locations
:Screw,3
B :Clip,2
E, H :Clip,1
G : Clip, 8
I : Clip, 3
J
E
K
L
L
L L
A
F GD
H
AI
I
I
J
J
J
B B
B I
I
I I
I
C
NOTE: Take care not to scratch the body.1. Remove the front inner fender (A).
–1 On the back of the wheel arch, remove the screws (B), and remove the front splash guard (C).
–2 From under the front bumper (D), remove the clips (E) securing the splash shield (F) and the front inner fenderto the front bumper.
–3 From the wheel arch, remove the clips (G, H, I, J) securing the front inner fender (and splash shield) to the body.
–4 Release the hook (K) of the splash shield, then remove the front inner fender.
NOTE: To release the clips E, H and G, pry up on the center pin at the notch (L).
2. Install the inner fender in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones.
Push the clips and the hooks into place securely.
08/08/21 15:05:06 61SNR030_200_0173
ProCarManuals.com
DYNOMITE -2009-
Page 1859 of 2893
(#'
)
20-172Fenderwell
Splash Shield Replacement
Fastener Locations
: Clip, 6
B, E
:Clip,6
F, G
A
B C
D EF
G H
I
I
I I
E
F
F
F
B
B
B
G C
NOTE: Take care not to scratch the body.
1. Remove the splash shield (A).
–1 Remove the clips (B) that secure the front inner fender (C) and the front splash shield to the body.
–2 From under the front bumper (D), remove the clips (E, F).
–3 From under the body, remove the clips (G).
–4 Release the hooks (H) of the front splash shield, then pull the splash shield out.NOTE: To release the clips B, E, F and G, pry up on the center pin at the notch (I).
2. Install the splash shield in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones.
Push the clips and the hooks into place securely.
08/08/21 15:05:06 61SNR030_200_0174
ProCarManuals.com
DYNOMITE -2009-
Page 1860 of 2893
(#'
)
20-173
Front Fender Fairing Replacement
Fastener Locations :Clip,2
A
B A
1. Remove the front inner fender as needed (see page
20-171).
2. From the wheel arch, remove the clips.
3. Open the front door. Detach the hooks (A) securing the front fender fairing (B). 4. Remove the front fender fairing (A).
5. Install the fender fairing in the reverse order of
removal, and note these items:
If the clips are damaged or stress-whitened, replace them with new ones.
Push the clips and the hooks into place securely.
08/08/21 15:05:07 61SNR030_200_0175
ProCarManuals.com
DYNOMITE -2009-
Page 1861 of 2893

(#'
)
(#'
)
20-17420-174 Fenderwell
Middle Floor Undercover
Replacement
Rear Floor Undercover
Replacement
Fastener Locations
: Bolt, 4 : Clip, 8
AB
6x1.0mm
9.8 N·m
(1.0 kgf·m, 7.2 lbf·ft) C
C
A
Fastener Locations
: Clip, 3 : Bolt, 3
6x1.0mm
9.8 N·m
(1.0 kgf·m,
7.2 lbf·ft) B
NOTE: Take care not to scratch the body.
1. Remove the bolts, and detach the clips, then remove the left middle floor undercover (A) and
right middle undercover (B).
NOTE: To release the clips, pry up on the center pin
at the notch (C).
2. Install the undercovers in the r everse order of
removal, and note these items:
If the clips are damaged or stress-whitened, replace them with new ones.
Push the clips into place securely. 1. Remove the clips and the bolts, then remove the
rear floor undercover (A). Take care not to scratch
the rear bumper (B).
2. Install the undercover in the reverse order of removal, and note these items:
If the clips are damaged or stress-whitened, replace them with new ones.
Push the clips into place securely.
08/08/21 15:05:07 61SNR030_200_0176
ProCarManuals.com
DYNOMITE -2009-
Page 1862 of 2893
Î
(#'
)
(#'
)
20-17520-175
Fuel Pipe Protector Replacement Rear Fender Cover Replacement
Fastener Locations :Clip,3
A Fastener Locations
:Screw,2 :Clip,1
B
A
NOTE: Take care not to scratch the body.
Put on gloves to protect your hands.
1. Remove the left rear wheel (see page 18-32).
2. Remove the clips, then remove the fuel pipe protector (A).
3. Install the protector in the reverse order of removal, and note these items:
If the clips are damaged or stress-whitened, replace them with new ones.
Push the clips into place securely. NOTE: Take care not to scratch the rear bumper and the
body.
1. Remove the screws and the clip, then remove the rear fender cover (A) from the rear bumper (B) and
the body.
2. Install the fender cover in the reverse order of removal, and if the clip is damaged or stress-
whitened, replace them with a new one.
08/08/21 15:05:08 61SNR030_200_0177
ProCarManuals.com
DYNOMITE -2009-
Page 1863 of 2893
(#'
)
(#'
)
20-17620-176 Fenderwell
Rear Strake Replacement
Rear Air Outlet Replacement
A
6x1.0mm
9.8 N·m
(1.0 kgf·m,
7.2 lbf·ft)
Fastener Locations
:Bolt,2
BA
A
NOTE: Take care not to scratch the body. 1. Remove the bolts, then remove the rear strake (A) from the body.
2. Install the strake in the reverse order of removal. 1. Remove the rear bumper (see page 20-149).
2. Detach the hooks (A), then remove the rear air
outlet (B). Take care not to scratch the body.
3. Install the air outlet by pushing on the hook portions until the hooks snap into place.
08/08/21 15:05:08 61SNR030_200_0178
ProCarManuals.com
DYNOMITE -2009-
Page 1864 of 2893
Î
(#'
)
20-177
Openers
Component Location Index
TRUNK LID LOCK CYLINDER
TRUNK LID LATCH
FUEL FILL
DOOR LATCH
TRUNK LID OPENER CABLE/
FUEL FILL DOOR OPENER CABLE
HOOD OPENER CABLE HOOD LATCH
TRUNK LID OPENER/
FUEL FILL DOOR OPENER
HOOD RELEASE HANDLE Replacement, page 20-184
Replacement,page 20-185
Replacement, page 20-179
Replacement, page 20-178 Replacement, page 20-181
Replacement, page 20-182
08/08/21 15:05:10 61SNR030_200_0179
