Î
µ
µ
µ
µ
22-195
R10LT BLU
K5
G3
E38
CLOSE OPEN
1
2 (3.4 W)
LT BLU
BLK GRY
GRY GRY
RED
(5 W)
1
WHT
2
(LED)
GRN
G502 AMBIENT
LIGHT
DASH LIGHTS
BRIGHTNESS
CONTROLLER TRUNK
LIGHT
UNDER-DASH
FUSE/RELAY BOX
No. 14 (7.5 A) FUSE
(UNDER-DASH
FUSE/RELAY BOX) GLOVE
BOX
LIGHTGLOVE
BOX
LID
GRY
(LED)
RED 2 1
DRIVER’S
FOOTWELL
LIGHT
DASH LIGHTS
BRIGHTNESS
CONTROLLER
GRY
(TYPE S model)
BLU
DRIVER’S
DOOR
COURTESY
LIGHT
TRUNK LID
LATCH
SWITCH
GRY(LED)
RED 2 1
FRONT
PASSENGER’S
FOOTWELL
LIGHT
DASH LIGHTS
BRIGHTNESS
CONTROLLER
LT BLU
DRIVER’S
VANITY
MIRROR
LIGHT
SWITCH
DRIVER’S
VANITY
MIRROR
LIGHT (2 W)DRIVER’S
SUNVISOR
1
2 LT BLU
PASSENGER’S
VANITY
MIRROR
LIGHT
SWITCH
PASSENGER’S
VANITY
MIRROR
LIGHT (2 W)PASSENGER’S
SUNVISOR
1
2
G502 BLK *2
BLK BLK
No. 22 (7.5 A) FUSE
(UNDER-HOOD
FUSE/RELAY BOX)
C
D B
5*3
4*4
3*2
2*2
5*4
3*3 *1: ’06 07 models
*2: ’08 09 models
*3: ’06 07 models with moonroof
*4: ’06 07 models without moonroof
08/08/21 14:27:49 61SNR030_220_0197
ProCarManuals.com
DYNOMITE -2009-
Page 2146 of 2893

Î
(#'
)
Î
(#'
)
With moonroof Without moonroof
Front Individual Map Light: 8 W x 2 Front Individual Map Light: 8 W x 2
22-19622-196Interior Lights
Front Individual Map Light Test/Replacement
A
B
C
Position 13
Terminal
RIGHT LEFT ON
OFF ON
OFF Body
ground A
B
C
Position 1
Terminal
RIGHT LEFT ON
OFF ON
OFF Body
ground
1. Turn the map light switch OFF.
2. Carefully pry the lens (A) off with a small
screwdriver.
3. Remove the screws, then remove the map lights (B) and moonroof switch or navigation microphone (C).
4. Disconnect the 3P connector from the map lights and the 10P connector from the moonroof switch or
navigation microphone.
5. Check for continuity between the terminals in each switch position according to the table.
6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light
assembly.
7. Install the map light in the reverse order of removal. 1. Turn the map light switch OFF.
2. Carefully pry the lens (A) off with a small
screwdriver.
3. Remove the screws, then remove the map lights (B).
4. Disconnect the 3P connector (C) from the map lights.
5. Check for continuity between the terminals in each switch position according to the table.
6. If the continuity is not as specified, check the bulb(s). If the bulb(s) are OK, replace the light
assembly.
7. Install the map light in the reverse order of removal.
08/08/21 14:27:50 61SNR030_220_0198
ProCarManuals.com
DYNOMITE -2009-
Page 2147 of 2893

(#'
)
´
µ
(#'
)
´ µ
Ceiling Light: 8 W Trunk Light: 5 W
22-19722-197
Ceiling Light Test/Replacement Trunk Light Test/Replacement
AC
B A
B
() ()
1. Turn the ceiling light switch OFF.
2. Carefully pry the lens (A) off with a small
screwdriver.
3. Remove the screws, then remove the ceiling light (B).
4. Disconnect the 3P connector (C) from the ce iling
light.
5. Check for continuity between the terminals. There should be continuity between terminalsNo. 1 and No. 2 with the switch in the MIDDLE
position.
There should be continuity between terminals No. 2 and No. 3 (Body ground) with the switch in
the ON position.
There should be no continuity between terminals No. 1 and No. 2, and between No. 2 and body
ground with the switch in the OFF position.
6. If the continuity is not as specified, check the bulb. If the bulb is OK, replace the light.
7. Install the ceiling light in the reverse order of removal. 1. Open the trunk lid.
2. Carefully pry out the trunk light (A).
3. Disconnect the 2P connector (B) from the light.
4. Check for continuity between terminals No. 1 ( )
and No. 2 ( ). There should be continuity. If there
is no continuity, check the bulb. If the bulb is OK,
replace the trunk light assembly.
5. Install the trunk light in the reverse order of removal.
08/08/21 14:27:50 61SNR030_220_0199
ProCarManuals.com
DYNOMITE -2009-
Page 2148 of 2893

Î
(#'
)
(#'
) Courtesy light: 3.4 W
22-19822-198
Interior Lights
Ambient Light Test/Replacement Courtesy Light Replacement
A
B
C ’06-07 models
’08-09 models
A
B C
D
1. Remove the front individual map light.
With moonroof (see page 22-196)
Without moonroof (see page 22- 196)
2. Disconnect the 10P (or 12P ) connector (A) from the ambient light (B), then remove the ambient
light from the front individual map light housing (C).
1: ’06-07 models
2: ’08-09 models
3. Connect battery power to the terminal No. 5 and ground to the No. 3 terminal. The ambient light
should turn on. If the light does not turn on, replace
the ambient light.
4. Install the ambient light in the reverse order of removal. 1. Carefully pry off the lens (A) with a small
screwdriver.
2. Pry out the housing (B) from the door panel, then disconnect the 2P connector (C).
3. Separate the housing, then remove the bulb (D) from the socket.
4. Install the courtesy light in the reverse order of removal.
12
08/08/21 14:27:50 61SNR030_220_0200
ProCarManuals.com
DYNOMITE -2009-
Page 2149 of 2893

(#'
)
(#'
)
Glove Box Light: 3.4 W
Vanity Mirror Light: 2 W
’08-09 models
22-19922-199
Glove Box Light Test/Replacement Vanity Mirror Light Test/Replacement
B
A C
A B
C
1. Open the glove box.
2. Remove the screws, then disconnect the 2P
connector from the glove box light (A).
3. Check for continuity between terminals No. 1 and No. 2.
There should be continuity with the switch (B) released.
There should be no continuity with the switch (B) pushed.
4. If the continuity is not as specified, check the bulb (C). If the bulb is OK, replace the light.
5. Install the glove box light in the reverse order of removal. 1. Open the sunvisor.
2. Remove the sunvisor (see page 20-84).
3. Disconnect the 2P connector (A) from the vanity
mirror light.
4. Check for continuity between terminals No. 1 and No. 2.
With the vanity mirror cover (B) opened, there should be continuity.
With the vanity mirror cover closed, there should be no continuity.
5. If the continuity is not as specified, replace the bulb (C) or the sunvisor.
6. Install the vanity mirror light in the reverse order of removal.
08/08/21 14:27:51 61SNR030_220_0201
ProCarManuals.com
DYNOMITE -2009-
Page 2150 of 2893

Î
(#'
)
(#'
)
With moonroof
22-20022-200 Interior Lights
Interior Light Switch Test/
Replacement
Trunk Lid Latch Switch Test
B
C A
’06-07 models
’08-09 models
A
B
NOTE: The interior light switch is built into the
moonroof switch, and it switches the front individual
map light OFF and DOOR positions. 1. Remove the front individual map lights (see page 22-196).
2. Disconnect the moonroof switch 10P (12P ) connector (A) and map light 3P connector (B).1: ’06-07 models
2: ’08-09 models
3. Remove the moonroof switch (C).
4. Check for continuity between moonroof switch 10P (12P ) connector check for continuity
between terminals No. 1 (No. 7 ) and No. 8
(No. 9 ).1: ’06-07 models
2: ’08-09 models
There should be continuity when the interior light switch is in the DOOR position.
There should be no continuity when the interior light switch is in the OFF position.
5. If the continuity check is not as specified, replace the switch.
6. Install the interior light switch in the reverse order of removal. 1. Open the trunk lid.
2. Disconnect the 3P connector (A) from the trunk lid
latch assembly (B).
3. Check for continuity between terminals No. 2 and No. 3.
There should be continuity with the trunk lid open.
There should be no continuity with the trunk lid closed.
4. If the continuity is not as specified, replace the trunk lid latch assembly.
12
12 12 1
2
08/08/21 14:27:51 61SNR030_220_0202
ProCarManuals.com
DYNOMITE -2009-
Page 2151 of 2893
Î
Î
(#'
)
´ µ ´
µ
TYPE S model
Driver’s Footwell Light Front Passenger’s Footwell Light
22-201
Footwell Light Test/Replacement
()
()
A
B ()
()
A B
1. Remove the dashboard undercover (A).
Driver’s dashboard undercover (see page 20- 103)
Passenger’s dashboard undercover (see page 20-104)
2. The LED should come on when power is connectedto footwell light illumination 2P connector (B)
terminal No. 1 and ground is connected to terminal
No. 2.
3. If the LED does not come on, replace the footwell light.
4. Install the footwell light in the reverse order of removal.
Wire side of
female terminals Wire side of
female terminals
08/08/21 14:27:52 61SNR030_220_0203
ProCarManuals.com
DYNOMITE -2009-
Page 2152 of 2893
Î
(#')
22-202Entry Lights Control System
Component Location Index
CEILING LIGHT
FRONT INDIVIDUAL MAP LIGHTS
MICU
(Built into the under-
dash fuse/relay box) IGNITION KEY SWITCH
DRIVER’S DOOR SWITCH LEFT REAR DOOR SWITCH RIGHT REAR DOOR SWITCH
FRONT PASSENGER’S
DOOR SWITCH
DRIVER’S DOOR LOCK
KNOB SWITCH IGNITION KEY LIGHT
DRIVER’S DOOR
KEY CYLINDER SWITCH Test/Replacement,
page 22-197
Test/Replacement (With moonroof),
page 22-196
Input Test, page 22-204 Test, page 22-207
Test, page 22-138 Test, page 22-207
Test, page 22-140
