Page 2657 of 2893

ACURA CSX 2006 Service Repair Manual ÎHFL Buttons
Hard Reset
Linking Pairing
Soft Reset (cellular phone)
Software Version
Standard Ringtone
23-369
A
B
HFL TALK button (A): Use this button on the steeringwheel to give commands. Pr

Page 2658 of 2893

ACURA CSX 2006 Service Repair Manual (##
) HandsFreeLink Control UnitDTC Description DTC typePage
23-370HandsFreeLink System
DTC Troubleshooting Index
B1750 Communication bus line error (Bus-o

Page 2659 of 2893

ACURA CSX 2006 Service Repair Manual (##
)
Symptom Diagnostic procedure Also check for
23-371
Symptom Troubleshooting Index
HFL does not respond
Control Unit Input Test
(see page 23-388) Check

(#'#
)
Symptom Diagnostic procedure Also check for
23-371
Symptom Troubleshooting Index
HFL does not respond
Control Unit Input Test
(see page 23-388) Check and repair all CAN related DTCs
The Bluetooth icon in the
navigation display is grayed-out There is no HFL-compatible
phone paired to the vehicle. Pair
an approved HFL-compatible
phone to the vehicleThe phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The Honda approved Bluetooth
phone is having problems pairing
to the vehicle HFL System Troubleshooting
(see page 23-373)
The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The Honda approved Bluetooth
phone cannot use all its functions HFL System Troubleshooting
(see page 23-373)The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The Honda approved Bluetooth
phone does not place or receive
calls using the HFL system HFL System Troubleshooting
(see page 23-373)
The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The client wants the HFL system
reset (all phones and address
information cleared from the HFL
system) Clearing the system (see page
23-367)
See the owner’s manual for additional
information.
The HFL system is locked and the
pass code has been lost or
forgotten Symptom Troubleshooting
(see page 23-383)
The HFL system does not
recognize all voice prompts Symptom Troubleshooting
(see page 23-382)Also see Voice control tips.
The address book does not
transfer from Honda approved
Bluetooth phone to HFL system There is no HFL compatible
phone paired to the vehicle or
the approved phone does not
support the function. Pair an
approved HFL compatible
phone to the vehicle.The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a list of approved
phones, go to www.acura.com/
handsfreelink, or call 888-528-7876.
The HFL messages cannot be
heard or are weak Symptom Troubleshooting
(see page 23-383)Excessive interior noise (open windows,
vents blowing on microphone, etc.).
The Bluetooth icon does not
display (the Bluetooth phone is
linked) Symptom Troubleshooting
(see page 23-386)
08/08/21 14:18:38 61SNR030_230_0374
ProCarManuals.com
DYNOMITE -2009-

Page 2660 of 2893

ACURA CSX 2006 Service Repair Manual ´´
µ ´
µ
´
µ
Î
Î
(##
)
HandsFreeLink Control Unit Inputs and Outputs
HANDSFREELINK CONTROL UNIT 28P CONNECTOR
Cavity Wire Color C

Page 2661 of 2893

ACURA CSX 2006 Service Repair Manual (##
)µ
µ
µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
23-373
HFL System Troubleshooting
NOTE:
You must be able to duplicate the client’s concern to success

Page 2662 of 2893

ACURA CSX 2006 Service Repair Manual Î(##
)
´
23-374HandsFreeLink System
Circuit Diagram
UNDER-HOOD FUSE/RELAY BOX
Q1E5
WHT 15 16
ORN
RED
WHT
ACC
BAT
IGNITION SWITCH
No. 23 (10 A)
No.

Page 2663 of 2893

ACURA CSX 2006 Service Repair Manual Î
´µ´ µ
´µ ´ µ
´µ
23-375
3
27
HANDSFREELINK CONTROL UNIT
MIC
SIG
MIC
SIG HFL
MUTE
BRN
YEL
HFL-NAVIGATION
MICROPHONE HFL
ICON
TELEM
SIG TELEM
SIG
12 13 14
D8 D7 D9 B8 B20 B21

Page 2664 of 2893

ACURA CSX 2006 Service Repair Manual Î
Î
(## .
)
´
´
´
µ
µ
µ
µ
µ
µ
DTC B1775:
YES
NO
YES
NO
YES
NO
23-376HandsFreeLink System
DTC Troubleshooting
HANDSFREELINK CONT
