22-227
UNDER-DASH FUSE/RELAY BOX CONNECTOR S (20P)
WIP INT/LO SW (ORN)
WIP MIST
SW (GRN) WIP LO/HI
SW (WHT) UNDER-DASH FUSE/RELAY BOX CONNECTOR S (20P)
WIP INT/
LO SW
(ORN)
WIP MIST
SW (GRN) WIP LO/HI
SW (WHT)
COMBI GND (BLK)
COMBI GND (BLK)
COMBI GND (BLK)
14. Turn the ignition switch to LOCK (0).
15. Disconnect under-dash fuse/relay box connector S
(20P).
16. Check for continuity between body ground and under-dash fuse/relay box connector S (20P)
terminals No. 10, No. 15, and No. 20 individually.
Repair a short to ground in the wire.
Go to step 17. 17. Check for continuity between under-dash fuse/relay
box connector S (20P) terminal No. 4 and terminals
No. 10, No. 15, and No. 20 individually.
Repair a short between the wires.
Faulty MICU; replace the under-dash fuse/
relay box (see page 22-66).
Wire side of female terminals Wire side of female terminals
Is there continuity?
Is there continuity?
08/08/21 14:28:47 61SNR030_220_0229
ProCarManuals.com
DYNOMITE -2009-
Page 2178 of 2893
(#'
)
22-228Wipers/Washers
MICU Input Test
UNDER-DASH FUSE/RELAY BOX CONNECTOR E (42P)
YEL
GRN ORN
BLK
BLU
WHT
UNDER-DASH FUSE/RELAY BOX CONNECTOR F (34P)
UNDER-DASH FUSE/RELAY BOX CONNECTOR S (20P) YEL
BLK BLK
BLK WHT WHT
UNDER-DASH FUSE/RELAY BOX CONNECTOR T (34P) BLK
BLU
1. Before testing the wiper/washer system, troubleshoot the system using B-CAN System Diagnosis Test Mode A
(see page 22-93), and check the No. 10 (7.5 A) and No. 38 (30 A) fuses in the under-dash fuse/relay box.
2. Disconnect the under-dash fuse/relay box connectors E, F, S, and T. NOTE: All connector views are shown from wire side of female terminals.
08/08/21 14:28:47 61SNR030_220_0230
ProCarManuals.com
DYNOMITE -2009-
Page 2179 of 2893

Cavity Wire Test conditionTest: Desired result Possible cause if desired result
is not obtained
22-229
3. Inspect the connector and socket terminals to be sure they are all making good contact.
If the terminals are bent, loose or corroded, repair them as necessary and recheck the system.
IftheterminalslookOK,gotostep4.
4. With the connectors still disconnected, do these input tests at the following connectors. If any test indicates a problem, find and correct the cause, then recheck the system.
If all the input tests prove OK, go to step 5.
F18 BLU Under all conditions Connect battery power to terminal
F18:
The windshield wiper motor
should run at low speed.Poor ground (G201)
Faulty windshield wiper
motor
An open in the wire
F19 YEL Under all conditions Connect battery power to terminal F19:
The windshield wiper motor
should run at high speed.Poor ground (G201)
Faulty windshield wiper
motor
An open in the wire
F32 WHT Disconnect the windshield wiper
motor 5P connector Check for continuity between
terminal F32 and wiper motor 5P
connector terminal No. 5:
There should be continuity. An open in the wire
F33 WHT Under all conditions Connect battery power to terminal F33:
The windshield washer motor
should run.Poor ground (G201)
Faulty windshield washer
motor
An open in the wire
S6 ·
S4 BLU
·
BLK Windshield wiper/
washer switch
(intermittent dwell
timer) turned Measure the resistance between
terminals S6 and S4:
There resistance should vary from
about 0 to 1 k . Faulty windshield wiper/
washer switch
An open in the wire
A short to ground in the wire
(cont’d)
08/08/21 14:28:48 61SNR030_220_0231
ProCarManuals.com
DYNOMITE -2009-
Page 2180 of 2893

Cavity Wire Test conditionTest: Desired result Possible cause if desired result
is not obtained
22-230Wipers/Washers
MICU Input Test (cont’d)
5. Reconnect the connectors to the under-dash fuse/relay box, and do these input tests at the following connectors.
If any test indicates a problem, find and correct the cause, then recheck the system.
If all the input tests prove OK, the MICU must be faulty; replace the under-dash fuse/relay box.
E6 BLK Under all conditions Measure the voltage to ground:
There should be less than 0.5 V.Poor ground (G602)
An open in the wire
E33 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V.Poor ground (G601)
An open in the wire
F20 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V.Poor ground (G401)
An open in the wire
T34 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V.Poor ground (G501)
An open in the wire
S10 ·
S4 ORN
·
BLK Ignition switch ON (II),
windshield wiper/
washer switch (INT)
ON Measure the voltage between
terminals S10 and S4, and
terminals S20 and S4:
There should be less than 1 V. Faulty windshield wiper/
washer switch
An open in the wire
Ignition switch ON (II),
windshield wiper/
washer switch OFF Measure the voltage between
terminals S10 and S4, and
terminals S20 and S4:
There should be more than 5 V. Faulty windshield wiper/
washer switch
A short to ground in the wire
S15 ·
S4 GRN
·
BLK Ignition switch ON (II),
windshield wiper/
washer switch (MIST)
ON Measure the voltage between
terminals S15 and S4:
There should be less than 1 V.
Faulty windshield wiper/
washer switch
An open in the wire
Ignition switch ON (II),
windshield wiper/
washer switch (MIST)
OFF Measure the voltage between
terminals S15 and S4:
There should be more than 5 V.
Faulty windshield wiper/
washer switch
A short to ground in the wire
S17 ·
S4 YEL
·
BLK Ignition switch ON (II),
windshield washer
switch ON Measure the voltage between
terminals S17 and S4:
There should be less than 1 V. Faulty windshield wiper/
washer switch
An open in the wire
Ignition switch ON (II),
windshield washer
switch OFF Measure the voltage between
terminals S17 and S4:
There should be more than 5 V. Faulty windshield wiper/
washer switch
A short to ground in the wire
S20 ·
S4 WHT
·
BLK Ignition switch ON (II),
windshield wiper/
washer switch (LOW)
ON Measure the voltage between
terminals S20 and S4:
There should be less than 1 V.
Faulty windshield wiper/
washer switch
An open in the wire
Ignition switch ON (II),
windshield wiper/
washer switch OFF Measure the voltage between
terminals S20 and S4:
There should be more than 5 V. Faulty windshield wiper/
washer switch
A short to ground in the wire
Ignition switch ON (II),
windshield wiper/
washer switch (HIGH)
ON Measure the voltage between
terminals S20 and S4:
There should be less than 1 V.
Faulty windshield wiper/
washer switch
An open in the wire
Ignition switch ON (II),
windshield wiper/
washer switch OFF Measure the voltage between
terminals S20 and S4:
There should be more than 5 V. Faulty windshield wiper/
washer switch
A short to ground in the wire
08/08/21 14:28:48 61SNR030_220_0232
ProCarManuals.com
DYNOMITE -2009-
Page 2181 of 2893

(#'
) ´µ
(#'
)
22-23122-231
Wiper/Washer Switch Test Wiper Motor Test
A
B
OFF INT
LO
HI Terminal
Position
Mist ON
Washer ON 1
2
345 8
Intermittent dwell
timer turned A
B
Terminal
Position
LOW SPEED
HIGH SPEED 1
2 3
1. Remove the wiper/washer switch (see page 22-234).
2. Disconnect the dashboard wire harness 8P
connector (A) from the wiper/washer switch (B).
3. Check for continuity between the terminals in each switch position according to the table.
4. If the continuity is not as specified, replace the switch. 1. Remove the wiper arms (see page 22-233).
NOTE: Carefully remove the wiper arms so that
they do not touch the hood.
2. Remove the hood seal and cowl cover.
3. Disconnect the 5P connector (A) from the wiper motor (B).
4. Test the motor by connecting battery power and ground according to the table. If the motor does not
run or fails to run smoothly, replace the motor.
5. Connect the battery power to terminal No. 1, and body ground to terminal No. 2 of the 5P connector.
Then connect an analog voltmeter between
terminal No. 1 ( ) and terminal No. 5 ( ). When
the park switch makes contact, the pointer should
swing. If not, replace the motor.
08/08/21 14:28:48 61SNR030_220_0233
ProCarManuals.com
DYNOMITE -2009-
Page 2182 of 2893

Î
(#'
)
(#'
)
22-23222-232 Wipers/Washers
Washer Motor Test
Washer Fluid Level Switch Test
A
B A
B
1. Remove the right inner fender (see page 20-171).
2. Disconnect the 2P connector (A) from the washermotor (B).
3. Test the motor by connecting battery power to terminal No. 1 and ground terminal No. 2 of the
washer motor. The motor should run.
If the motor does not run, or fails to run smoothly, replace it.
If the motor runs smoothly, but little or no washer fluid is pumped, check for a disconnected
or blocked washer hose, or a clogged washer
motor outlet. 1. Remove the right inner fender (see page 20-171).
2. Disconnect the 2P connector (A) from the washer
fluid level switch (B).
3. Remove the washer fluid level switch from the washer reservoir.
NOTE: Fluid may flow out of the opening.
4. Check for continuity between terminals No. 1 and No. 2 in each float position.
There should be continuity when the float is down.
There should be no continuity when the float is up.
5. If the continuity is not as specified, replace the switch.
Terminal side of
male terminals
08/08/21 14:28:49 61SNR030_220_0234
ProCarManuals.com
DYNOMITE -2009-
Page 2183 of 2893

(#'
)
22-233
Wiper Motor Replacement
A
29.4 N·m
(3.0 kgf·m,
21.6 lbf·ft) B
C C
9.8 N·m (1.0 kgf·m, 7.2 lbf·ft) AB
C 9.8 N·m
(1.0 kgf·m, 7.2 lbf·ft)
22 N·m
(2.2 kgf·m, 16 lbf·ft) A
D
E
31.4 N·m
(3.2 kgf·m, 23.2 lbf·ft)
B
C
F D
7.4 N·m
(0.8 kgf·m,
5.5 lbf·ft)
1. Open the hood. Remove the caps, nuts (A), and the windshield wiper arms (B).
2. Remove the cowl covers (C).
3. Remove the bolts and the under-cowl panel (A).
4. Disconnect the 5P connector from the wiper motor (B), then remove the six bolts and wiper linkage
assembly (C). 5. Make sure the mark (A) on the link (B) is aligned
with the mark (C) on the windshield wiper linkage
(D).
6. Remove the nut (E), and separate the link and windshield wiper linkage.
7. Remove the three bolts, and separate the windshield wiper linkage from the wiper motor (F).
8. Install the wiper motor in the reverse order of removal, and note these items:
Align the marks of the link and the linkage to install the linkage with the original adjustment.
Apply multipurpose grease to the moving parts.
Before installing the wiper arms, turn the wiper switch ON, then OFF to return the wiper shafts to
the park position.
If necessary, replace any damaged clips.
9. After installation, adjust the wiper arms (see page 22-236).
08/08/21 14:28:49 61SNR030_220_0235
ProCarManuals.com
DYNOMITE -2009-
Page 2184 of 2893
(#'
)
(#'
) Washer reservoir capacity: 4.5 L (4.8 US qt)
22-23422-234
Wipers/Washers
Wiper/Washer Switch Replacement Washer Reservoir Replacement
A
B B
D AC
A
9.8 N·m
(1.0 kgf·m,
7.2 lbf·ft)
B
1. Remove the driver’s dashboard lower cover
(see page 20-102).
2. Remove the steering column covers (see page 17-9).
3. Disconnect the dashboard wire harness 8P connector (A) from the wiper/washer switch (B).
4. Remove the two screws, then slide out the wiper/ washer switch.
5. Install the wiper/washer switch in the reverse order of removal. 1. Remove the right inner fender (see page 20-171).
2. Disconnect the 2P connector(s) (A) from the
windshield washer motor (B) and the washer fluid
level switch (C).
3. Disconnect the windshield washer tube (D).
4. Remove the bolts (A) and the clip (B), then remove the washer reservoir.
5. Install the washer reservoir in the reverse order of removal.
08/08/21 14:28:50 61SNR030_220_0236
