Page 2729 of 2893

ACURA CSX 2006 Service Repair Manual
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-49
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the

Page 2730 of 2893

ACURA CSX 2006 Service Repair Manual Î
(#

-)
µ
µ
DTC 11-3x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 11-6x (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required

Page 2731 of 2893

ACURA CSX 2006 Service Repair Manual
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-51
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the

µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-51
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).Go to step 9.
Short in the driver’s airbag first or second
inflator; replace the driver’s airbag (see page
24-188), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
10. Remove the column cover (see page 17-9), then disconnect dashboard wire harness 4P connector
(A) from the cable reel.
11. Connect the SRS inflator simulator (2 connectors) and the simulator lead to the
dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory. 14. Read the DTC.
Go to step 15.
Short in the cable reel; replace the cable reel
(see page 24-200), then clear the DTC.
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector.
18. Connect the SRS short cancellers (070AZ-SAA0100) to SRS unit connector A (28P) terminals No. 7 and
No. 8 and terminals No. 1 and No. 2 (see page
24-18).
19. Measure the resistance between the terminals of both SRS simulator leads. There should be an open
circuitoratleast1M .
Faulty SRS unit or poor connection at SRS
unit connector A (28P) and the SRS unit. Check the
connection between the connector and the SRS
unit. If the connection is OK, replace the SRS unit
(see page 24-203).
Short in the dashboard wire harness; replace
dashboard wire harness, then clear the DTC.
I s DT C 11-3x or 11-6x i nd i cat ed ? I s DT C 11-3x or 11-6x i nd i cat ed ?
Is the resistance as specif ied?
08/08/21 13:55:41 61SNR030_240_0051
ProCarManuals.com
DYNOMITE -2009-

Page 2732 of 2893

ACURA CSX 2006 Service Repair Manual Î
(#

-)
µ
µ
DTC 11-8x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 11-Ax (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required

Page 2733 of 2893

ACURA CSX 2006 Service Repair Manual
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-53
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the

µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-53
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).Go to step 9.
Short to power in the driver’s airbag first or
second inflator; replace the driver’s airbag
(see page 24-188), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
10. Remove the column cover (see page 17-9), then disconnect the dashboard wire harness 4P
connector (A) from the cable reel.
11. Connect the SRS inflator simulator (2 connectors) and the simulator lead to the
dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory. 14. Read the DTC.
Go to step 15.
Short to power in the cable reel; replace the
cable reel (see page 24-200), then clear the DTC.
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector.
18. Reconnect the negative cable to the battery.
19. Turn the ignition switch to ON (II).
20. Measure the voltage between each terminal of the SRS simulator lead and body ground. There should
be less than 0.2 V.
Faulty SRS unit or poor connection at SRS
unit connector A (28P) and the SRS unit. Check the
connection between the connector and the SRS
unit. If the connection is OK, replace the SRS unit
(see page 24-203).
Short to power in the dashboard wire
harness; replace the dashboard wire harness, then
clear the DTC.
I s DT C 11-8x or 11-Ax i nd i cat ed ? I s DT C 11-8x or 11-Ax i nd i cat ed ?
Is the voltage as specif ied?
08/08/21 13:55:41 61SNR030_240_0053
ProCarManuals.com
DYNOMITE -2009-

Page 2734 of 2893

ACURA CSX 2006 Service Repair Manual Î
(#

-)
µ
µ
DTC 11-9x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 11-Bx (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required

Page 2735 of 2893

ACURA CSX 2006 Service Repair Manual
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-55
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the

Page 2736 of 2893

ACURA CSX 2006 Service Repair Manual
(#

-)
µ
µ
DTC 12-1x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 12-4x (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
