Page 2209 of 2893
Î
22-259
MICU
BLU GRN
BLU GRN
(LED)
(LED)
(LED)
G504G504 12
BRN
BLU
MAIN CIRCUIT BLK4
GAUGE CONTROL MODULE (SPEEDO) 11
ILLUMINATION
CONTROL &
DIMMING CIRCUIT
FOR LCD (TEMP) ILLUMINATION
CONTROL &
DIMMING CIRCUIT
FOR LCD (SP) ILLUMINATION
CONTROL &
DIMMING CIRCUIT
FOR LCD (FUEL)
LEFT
TURN
SIGNAL
INDICATOR
(LED)RIGHT
TURN
SIGNAL
INDICATOR
(LED)
TURN SIGNAL/
HAZARD RELAY
(SOUNDER) RIGHT TURN
SIGNAL LIGHTS
LEFT TURN
SIGNAL LIGHTS : Other communication line
08/08/21 14:35:18 61SNR030_220_0261
ProCarManuals.com
DYNOMITE -2009-
Page 2210 of 2893
Î(#'
)
TYPE S model
22-260Gauges
Circuit Diagram - Gauge Control Module (Speedo) (cont’d)
UART
No. 10
(7.5 A)
No. 1 (BAT) (100 A)
IGNITION SWITCH
BATTERY
No. 23 (10 A)WHT
BLU
BAT
IG1
ORN
No. 2 (IG) (50 A)
BRN
WHT BRN
UNDER-HOOD FUSE/RELAY BOX
IG1 HOT in ON (II) and START (III)
WHT
DRIVE CIRCUIT DRIVE CIRCUIT
5
MAIN CIRCUIT GRY1GAUGE CONTROL MODULE (SPEEDO)
6
BLINKING
CIRCUIT
GAUGE
CONTROL
MODULE
(TACH) LOW FUEL
INDICATOR
(LED)
SECURITY
INDICATOR
(LED)
FUEL
METER
LCD
TEMP
METER
LCD
SPEEDOMETER
LCD GAUGE CONTROL
MODULE (TACH)UNDER-DASH
FUSE/RELAY
BOX
H1
D4 G2D2
P5 Q1 Q9P10
REV LIMIT
INDICATOR
(LED)
DIMMING
CIRCUIT DRIVE
CIRCUIT
MICU
08/08/21 14:35:18 61SNR030_220_0262
ProCarManuals.com
DYNOMITE -2009-
Page 2211 of 2893
Î
22-261
MICU
BLU GRN
BLU GRN
(LED)
(LED)
(LED)
G504G504 12
BRN
BLU
MAIN CIRCUIT BLK4
GAUGE CONTROL MODULE (SPEEDO) 11
ILLUMINATION
CONTROL &
DIMMING CIRCUIT
FOR LCD (TEMP) ILLUMINATION
CONTROL &
DIMMING CIRCUIT
FOR LCD (SP) ILLUMINATION
CONTROL &
DIMMING CIRCUIT
FOR LCD (FUEL)
LEFT
TURN
SIGNAL
INDICATOR
(LED)RIGHT
TURN
SIGNAL
INDICATOR
(LED)
TURN SIGNAL/
HAZARD RELAY
(SOUNDER) RIGHT TURN
SIGNAL LIGHTS
LEFT TURN
SIGNAL LIGHTS : Other communication line
08/08/21 14:35:19 61SNR030_220_0263
ProCarManuals.com
DYNOMITE -2009-
Page 2212 of 2893
(#' .
)µ
µ
DTC B1152:
YES
NO
22-262 Gauges
DTC Troubleshooting
Gauge Control Module
(EEPROM) Error
NOTE: If you are troubleshooting multiple DTCs, be
sure to follow the instructions in B-CAN System
Diagnosis Test Mode A (see page 22-93).
1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Wait for at least 6 seconds.
4. Check for DTCs with the HDS.
Replace the gauge control module (tach)
(see page 22-277).
Intermittent failure, the system is OK at this
time. Check for loose or poor connections. If the
connections are good, check the battery condition
(see page 22-67), and the charging system.
I s DT C B115 2 i nd i cat ed ?
08/08/21 14:35:19 61SNR030_220_0264
ProCarManuals.com
DYNOMITE -2009-
Page 2213 of 2893

(#' .
)
µ
µ µ
µ
DTC B1155:
DTC B1156:
DTC B1159:
DTC B1188:
YES
NO YES
NO
22-263
Gauge Control Module Lost
Communication with the MICU (Headlight
Switch Message)
Gauge Control Module Lost
Communication with the MICU (Wiper Switch
Message)
Gauge Control Module Lost
Communication with the MICU (DOORSW
Message)
Gauge Control Module Lost
Communication with the MICU (RM
Message)
NOTE: If you are troubleshooting multiple DTCs, be
sure to follow the instructions in B-CAN System
Diagnosis Test Mode A (see page 22-93).
1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Check for DTCs with the HDS.
Go to step 4.
Intermittent failure. The gauge control
module is OK at this time. Check for loose or poor
connections. If the connections are good, check the
battery condition (see page 22-67), and the
charging system. 4. Check for DTCs with the HDS.
Faulty MICU; replace the under-dash fuse/
relay box (see page 22-66).
Replace the gauge control module (tach)
(see page 22-277).
Ar e DT Cs B115 5 , B115 6, 115 7 , B115 9, B1160, and / or B1188 i nd i cat ed ? Ar e DT Cs B115 5 , B115 6, 115 7 , B115 9, B1160,
and / or B1188 i nd i cat ed at t he same t i me?
08/08/21 14:35:19 61SNR030_220_0265
ProCarManuals.com
DYNOMITE -2009-
Page 2214 of 2893

(#' .
)(#' .
)
µ
µ
µ
µ µ
µ
µ
µ
DTC B1157: DTC B1160:
YES
NO
YES
NO YES
NO
YES
NO
22-26422-264Gauges
DTC Troubleshooting (cont’d)
Gauge Control Module Lost
Communication with the MICU (MICU
Message) Gauge Control Module Lost
Communication with the MICU (DRLOCKSW
Message)
NOTE: If you are troubleshooting multiple DTCs, be
sure to follow the instructions in B-CAN System
Diagnosis Test Mode A (see page 22-93).
1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Check for DTCs with the HDS.
Go to step 4.
Intermittent failure. The gauge control
module is OK at this time. Check for loose or poor
connections. If the connections are good, check the
battery condition (see page 22-67), and the
charging system.
4. Check for DTCs with the HDS.
Faulty MICU; replace the under-dash fuse/
relay box (see page 22-66).
Replace the gauge control module (tach)
(see page 22-277). NOTE: If you are troubleshooting multiple DTCs, be
sure to follow the instructions in B-CAN System
Diagnosis Test Mode A (see page 22-93).
1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Check for DTCs with the HDS.
Go to step 4.
Intermittent failure. The gauge control
module is OK at this time. Check for loose or poor
connections. If the connections are good, check the
battery condition (see page 22-67), and the
charging system.
4. Check for DTCs with the HDS.
Faulty MICU; replace the under-dash fuse/
relay box (see page 22-66).
Replace the gauge control module (tach)
(see page 22-277).
I s DT C B115 7 i nd i cat ed ?
Ar e DT Cs B115 7 and B1165 i nd i cat ed at t he sametime? I s DT C B1160 i nd i cat ed ?
Ar e DT Cs B1160 and B1905 i nd i cat ed at t he sametime?
08/08/21 14:35:19 61SNR030_220_0266
ProCarManuals.com
DYNOMITE -2009-
Page 2215 of 2893

(#' .
)
µ
µ
µ
µ µ
µ
µ
µ
DTC B1168:
DTC B1169:
DTC B1170:
DTC B1178:
DTC B1187:
YES
NO
YES
NO YES
NO
YES
NO
22-265
Gauge Control Module Lost
Communication with ECM/PCM (Engine
Messages)
Gauge Control Module Lost
Communication with the PCM (A/T
Messages)
Gauge Control Module Lost
Communication with the ABS/VSA
modulator-Control Unit (ABS/VSA message)
F-CAN Communication Line Error
Gauge Control Module Lost
Communication with the SRS Unit (SRS
Message)
NOTE: If you are troubleshooting multiple DTCs, be
sure to follow the instructions in B-CAN System
Diagnosis Test Mode A (see page 22-93).
1. Clear the DTCs using the HDS.
2. Turn the ignition switch to LOCK (0), and then back to ON (II).
3. Start and run the engine for at least 5 seconds then turn the engine off.
4. Check for DTCs with the HDS.
Go to step 5.
Intermittent failure, the F-CAN
communication line is OK at this time. Check for
loose or poor connections. If the connections are
good, check the battery condition (see page 22-67),
and the charging system.
5. Check for DTCs in the ECM/PCM or ABS/VSA.
Troubleshoot the ECM/PCM or ABS/VSA.
Go to step 6. 6. Do the Gauge Control Module (Tach) Input Test
(see page 22-271).
Go to step 7.
Repair the faulty input then recheck for
DTCs.
7. Substitute a known-good gauge control module (tach).
8. Clear the DTCs with the HDS.
9. Turn the ignition switch to LOCK (0), and then back to ON (II).
10. Start and run the engine for at least 5 seconds then turn the engine off.
11. Check for DTCs with the HDS.
Substitute a known-good ECM/PCM and
retest. If the system/indication goes away, replace
the original ECM/PCM.
The original gauge control module (tach) is
faulty; replace the gauge control module (tach)
(see page 22-277).
Ar e DT Cs B1168, B1169, B117 0, B117 8, and / or B1187 i nd i cat ed ?
Are any DTCs indicated? Are all inputs OK ?
Ar e DT Cs B1168, B1169, B117 0, B117 8, and / orB1187 i nd i cat ed ?
08/08/21 14:35:19 61SNR030_220_0267
ProCarManuals.com
DYNOMITE -2009-
Page 2216 of 2893

Î
(#' .
)
µ
µ
µ
µ µ
µ
µ
µ
DTC B1173:
YES
NO
YES
NO YES
NO
YES
NO
22-266Gauges
DTC Troubleshooting (cont’d)
GAUGE CONTROL MODULE (TACH) 36P CONNECTOR
CAN H (WHT)
CAN L (RED)
TPMS CONTROL UNIT 20P CONNECTOR
Gauge Control Module Lost
Communication with the TPMS Control Unit
(TPMS Message) (’08-09 models)
NOTE: If you are troubleshooting multiple DTCs, be
sure to follow the instructions in B-CAN System
Diagnosis Test Mode A (see page 22-93).
1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0) and then back to ON (II).
3. Check for the DTCs with the HDS.
Go to step 4.
Intermittent failure, the F-CAN
communication line is OK at this time. Check for
loose or poor connections. If the connections are
good, check the battery condition (see page 22-67),
and the charging system.
4. Check for DTCs in the TPMS.
Troubleshoot the TPMS DTCs with the
HDS.
Go to step 5.
5. Turn the ignition switch to LOCK (0).
6. Disconnect the gauge control module (tach) 36P connector.
7. Disconnect the TPMS control unit 20P connector. 8. Check for continuity between gauge control
module (tach) 36P connector terminals No. 1 and
No. 19 and TPMS control unit 20P connector
terminals No. 2 and No. 11 respectively.
Go to step 9.
Repair an open in the wire between the gauge
control module and the TPMS control unit.
9. Check for poor connections, power, and ground to the TPMS control unit. If OK, substitute a known-
good TPMS control unit.
10. Check for DTCs with the HDS.
Replace the gauge control module (tach)
(see page 22-277).
Replace the original TPMS control unit.
Wire side of female terminals
Wire side of female terminals
I s DT C B117 3 i nd i cat ed ?
Are any DTCs indicated? Is there continuity?
I s DT C B117 3 i nd i cat ed ?
08/08/21 14:35:19 61SNR030_220_0268
