DTC P2610: DTC P2A00:
YES
NO
YES
NO YES
NO
11-18211-182PGM-FI System
DTC Troubleshooting (cont’d)
ECM/PCM Ignition Off Internal
Timer Malfunction A/F Sensor (Sensor 1) Circuit
Range/Performance Problem
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Check for Temporary DTCs or DTCs with the HDS.
Go to step 4.
Intermittent failure, the system is OK at this
time.
4. Update the ECM/PCM if it does not have the latest software (see page 11-227), or substitute a known-
good ECM/PCM (see page 11-7).
5. Check for Temporary DTCs or DTCs with the HDS.
If the ECM/PCM was updated, substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the ECM/PCM was substituted, go to
step 1.
If the ECM/PCM was updated, troubleshooting
is complete. If the ECM/PCM was substituted,
replace the original ECM/PCM (see page 11-228). If
any other Temporary DTCs or DTCs are indicated,
go to the indicated DTC’s troubleshooting. NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle.
4. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1)above70°C(158°F)
A/TinD,M/Tin3rd
Vehicle speed between 44 88 km/h (22 55 mph) for 5 minutes
Drive at a steady speed between 88 120 km/h (55 75 mph) for 10 seconds, then decelerate
(with the throttle fully closed) for 5 seconds
5. Monitor the OBD STATUS for DTC P2A00 in the DTCs MENU with the HDS.
Go to step 6.
If the screen indicates PASSED, intermittent
failure, the system is OK at this time. Check for
poor connections or loose terminals at the A/F
sensor (Sensor 1) and the ECM/PCM. If the screen
indicates EXECUTING, keep driving until a result
comes on. If the screen indicates OUT OF
CONDITION, go to step 3 and recheck.
6. Turn the ignition switch to LOCK (0).
7. Replace the A/F sensor (Sensor 1) (see page 11-221).
8. Turn the ignition switch to ON (II).
9. Reset the ECM/PCM with the HDS.
Is DTC P2610 indicated?
Is DTC P2610 indicated? Does t he scr een i nd i cat e F AILE D?
08/08/21 14:21:46 61SNR030_110_0182
ProCarManuals.com
DYNOMITE -2009-
Page 506 of 2893

µ
µ µ
µ
(#'
*)
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO YES
NO
YES
NO
DTC U0028:
11-18311-183
10. Do the ECM/PCM idle learn procedure (see page
11-310).
11. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1)above70°C(158°F)
A/TinD,M/Tin3rd
Vehicle speed between 44 88 km/h (22 55 mph) for 5 minutes
Drive at a steady speed between 88 120 km/h (55 75 mph) for 10 seconds, then decelerate
(with the throttle fully closed) for 5 seconds
12. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the A/F sensor (Sensor 1) and the ECM/
PCM, then go to step 1.
Go to step 13.
13. Monitor the OBD STATUS for DTC P2A00 in the DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 12,
go to the indicated DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the A/F sensor
(Sensor1)andtheECM/PCM,thengotostep1.If
the screen indicates EXECUTING, keep driving until
a result comes on. If the screen indicates OUT OF
CONDITION, go to step 11. NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Check for Temporary DTCs or DTCs with the HDS.
Go to step 4.
Intermittent failure, the system is OK at this
time.
4. Update the ECM/PCM if it does not have the latest software (see page 11-227), or substitute a known-
good ECM/PCM (see page 11-7).
5. Turn the ignition switch to ON (II).
6. Check for Temporary DTCs or DTCs with the HDS.
If the ECM/PCM was updated, substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the ECM/PCM was substituted, go to
step 1.
If the ECM/PCM was updated, troubleshooting
is complete. If the ECM/PCM was substituted,
replace the original ECM/PCM (see page 11-228). If
any other Temporary DTCs or DTCs are indicated,
go to the indicated DTC’s troubleshooting.F-CAN Malfunction (BUS-OFF
(ECM/PCM))
Is DTC P2A00 indicated?
Does t he scr een i nd i cat e PASSE D? I s DT C U 0028 i nd i cat ed ?
I s DT C P0028 i nd i cat ed ?
08/08/21 14:21:46 61SNR030_110_0183
ProCarManuals.com
DYNOMITE -2009-
Page 507 of 2893

(#'
*
)
µ
µ
µ
µ
µ
µ µ
µ
DTC U0122:
YES
NO
YES
NO
YES
NO YES
NO
11-184PGM-FI System
DTC Troubleshooting (cont’d)
CANH (WHT)
CANH (WHT) ECM/PCM CONNECTOR A (44P)
VSA MODULATOR-CONTROL
UNIT 37P CONNECTOR
F-CAN Malfunction (ECM/PCM-
VSA Modulator-Control Unit)
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Check for Temporary DTCs or DTCs with the HDS.
Go to the troubleshooting for DTC U 0028.
Go to step 3.
3. Clear the DTC with the HDS.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 5.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the VSA modulator-control unit and the ECM/
PCM.
5. Check for communication to the VSA system with the HDS.
Go to step 6.
Go to the DLC circuit troubleshooting
(see page 11-204).
6. Turn the ignition switch to LOCK (0).
7. Jump the SCS line with the HDS.
8. Disconnect the VSA modulator-control unit 37P connector (see page 19- 171).
9. Disconnect ECM/PCM connector A (44P). 10. Check for continuity between ECM/PCM connector
terminal A36 and VSA modulator-control unit 37P
connector terminal No. 15.
Go to step 11.
Repair open in the wire between the ECM/
PCM (A36) and the VSA modulator-control unit,
then go to step 12.
Terminal side of female terminals
Wire side of female terminals
Ar e DT C U 0028 and U 0122 i nd i cat ed at t he same time?
Is DTC U0122 indicated?
Does the HDS communicate with the V SAmod ul at or -cont r ol uni t ? Is there continuity?
08/08/21 14:21:46 61SNR030_110_0184
ProCarManuals.com
DYNOMITE -2009-
Page 508 of 2893

µ
µ µ
µ
YES
NO YES
NO
11-185
CANL (RED)
CANL (RED)
VSA MODULATOR-CONTROL
UNIT 37P CONNECTOR
ECM/PCM CONNECTOR A (44P)
11. Check for continuity between ECM/PCM connector
terminal A37 and VSA modulator-control unit 37P
connector terminal No. 1.
Substitute a known-good VSA modulator-
control unit (see page 19-171), then go to step 12
and recheck. If DTC U0122 is not indicated, replace
the original VSA modulator-control unit (see page
19-171), then go to step 12.
Repair open in the wire between the ECM/
PCM (A37) and the VSA modulator-control unit,
then go to step 12. 12. Reconnect all connectors.
13. Turn the ignition switch to ON (II).
14. Reset the ECM/PCM with the HDS.
15. Do the ECM/PCM idle learn procedure (see page
11-310).
16. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the VSA modulator-control unit and
theECM/PCM,thengotostep1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting.
Wire side of female terminals Terminal side of female terminals
Is there continuity? Is DTC U0122 indicated?
08/08/21 14:21:47 61SNR030_110_0185
ProCarManuals.com
DYNOMITE -2009-
Page 509 of 2893

(#'
*
)
µ
µ
µ
µ
µ
µ µ
µ
DTC U0131:
YES
NO
YES
NO
YES
NO YES
NO
11-186PGM-FI System
DTC Troubleshooting (cont’d)
ECM/PCM CONNECTOR A (44P)
CANH (WHT)
JUMPER WIRE
EPS CONTROL UNIT CONNECTOR D (28P) CANH (WHT)
F-CAN Malfunction (ECM/PCM-
EPS Control Unit)
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Check for Temporary DTCs or DTCs with the HDS.
Go to the troubleshooting for DTC U 0028.
Go to step 3.
3. Clear the DTC with the HDS.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 5.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the EPS control unit and the ECM/PCM.
5. Check that the HDS communicates with the EPS system.
Go to step 6.
Go to the DLC circuit troubleshooting
(see page 11-204).
6. Turn the ignition switch to LOCK (0).
7. Jump the SCS line with the HDS.
8. Disconnect EPS control unit connector D (28P) (see page 17-84).
9. Disconnect ECM/PCM connector A (44P) 10. Connect ECM/PCM connector terminal A36 to body
ground with a jumper wire.
11. Check for continuity between EPS control unit connector D (28P) terminal No. 1 and body ground.
Go to step 12.
Repair open in the wire between the ECM/
PCM (A36) and the EPS control unit, then go to step
14.
Terminal side of female terminals
Wire side of female terminals
Ar e DT C U 0028 and U 0131 i nd i cat ed at t he sametime?
Is DT C U0131 ind icated ?
Does the HDS communicate with the EPS controluni t ? I s t her e cont i nui t y ?
08/08/21 14:21:47 61SNR030_110_0186
ProCarManuals.com
DYNOMITE -2009-
Page 510 of 2893

µ
µ µ
µ
YES
NO YES
NO
11-187
ECM/PCM CONNECTOR A (44P)
CANL (RED)
JUMPER WIRE
EPS CONTROL UNIT CONNECTOR D (28P) CANL (RED)
12. Connect ECM/PCM connector terminal A37 to body ground with a jumper wire.
13. Check for continuity between EPS control unit connector D (28P) terminal No. 15 and body ground.
Substitute a known-good EPS control unit
(see page 17-84), then go to step 14 and recheck. If
no DTCs are indicated, replace the original EPS
control unit (see page 17-84), then go to step 14.
Repair open in the wire between the ECM/
PCM (A37) and the EPS control unit, then go to step
14. 14. Reconnect all connectors.
15. Turn the ignition switch to ON (II).
16. Reset the ECM/PCM with the HDS.
17. Do the ECM/PCM idle learn procedure (see page
11-310).
18. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the EPS control unit and the ECM/PCM,
then go to step 1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting.
Terminal side of female terminals
Wire side of female terminals
Is there continuity? Is DT C U0131 ind icated ?
08/08/21 14:21:48 61SNR030_110_0187
ProCarManuals.com
DYNOMITE -2009-
Page 511 of 2893

(#'
*
)
µ
µ
µ
µ
µ
µ
DTC U0155:
YES
NO
YES
NO
YES
NO
11-188PGM-FI System
DTC Troubleshooting (cont’d)
GAUGE CONTROL MODULE (TACH) 36P CONNECTOR
CANH (WHT)
JUMPER WIRE
ECM/PCM CONNECTOR A (44P)CANH (WHT)
F-CAN Malfunction (ECM/PCM-
Gauge Control Module)
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Check for Temporary DTCs or DTCs with the HDS.
Go to step 4.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the gauge control module (tach) and the ECM/
PCM.
4. Check for body electrical DTCs in the DTCs MENU with the HDS.
Go to step 5.
Do the gauge control module (tach) input test
(see page 22-271).
5. Turn the ignition switch to LOCK (0).
6. Jump the SCS line with the HDS.
7. Remove the gauge control module (tach) (see page 22-277).
8. Disconnect ECM/PCM connector A (44P). 9. Connect gauge control module (tach) 36P
connector terminal No. 1 to body ground with a
jumper wire.
10. Check for continuity between ECM/PCM connector terminal A36 and body ground.
Go to step 11.
Repair open in the wire between the ECM/
PCM (A36) and the gauge control module (tach),
then go to step 13.
Wire side of female terminals
Terminal side of female terminals
Is DTC U0155 indicated? I s DT C B1168, B1169, and / or B117 8 i nd i cat ed ? Is there continuity?
08/08/21 14:21:48 61SNR030_110_0188
ProCarManuals.com
DYNOMITE -2009-
Page 512 of 2893

µ
µ µ
µ
YES
NO YES
NO
11-189
GAUGE CONTROL MODULE (TACH) 36P CONNECTOR
CANL (RED)
JUMPER WIRE
ECM/PCM CONNECTOR A (44P) CANL (RED)
11. Connect gauge control module (tach) 36Pconnector terminal No. 19 to body ground with a
jumper wire.
12. Check for continuity between ECM/PCM connector terminal A37 and body ground.
Substitute a known-good gauge control
module (tach) (see page 22-277), then go to step 14
and recheck. If no DTCs are indicated, replace the
original gauge control module (tach) (see page
22-277), then go to step 13.
Repair open in the wire between the ECM/
PCM (A37) and the gauge control module (tach),
then go to step 13. 13. Reconnect all connectors.
14. Turn the ignition switch to ON (II).
15. Reset the ECM/PCM with the HDS.
16. Do the ECM/PCM idle learn procedure (see page
11-310).
17. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the gauge control module (tach) and
theECM/PCM,thengotostep1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting.
Wire side of female terminals
Terminal side of female terminals
Is there continuity? Is DTC U0155 indicated?
08/08/21 14:21:49 61SNR030_110_0189
ProCarManuals.com
DYNOMITE -2009-
