7-3
Component Location Index
MAIN BEARINGSDOWEL PINS LOWER BLOCK
BAFFLE PLATE
CRANKSHAFT CRANKSHAFT OIL SEAL,
TRANSMISSION END
BAFFLE PLATE
DRIVE PLATE (A/T model)
THRUST WASHERS FLYWHEEL (M/T model)
(cont’d)
Oil Clearance Inspection,
page 7-6
Selection, page 7-7
End Play Inspection, page 7-5
Removal, page 7-13
Inspection, page 7-15
Installation, page 7-25
Installation, step 24 on page 7-27
Installation - in Car, page 7-32
08/08/21 14:32:28 61SNR030_070_0003
ProCarManuals.com
DYNOMITE -2009-
Page 218 of 2893
Î
7-4Engine Block
Component Location Index (cont’d)
PISTON RINGS
PISTON PIN
CONNECTING ROD
CONNECTING ROD
BEARINGS CONNECTING ROD
BEARING CAP
PISTON
ENGINE BLOCK
CONNECTING ROD BOLTS DOWEL PINSReplacement, page 7-21
Removal, page 7-18
Inspection, page 7-19
Installation, page 7-20
End Play Inspection, page 7-5
Small End Measurement, page 7-19
Oil Clearance Inspection,page 7-8
Selection, page 7-9
Removal, page 7-13
Measurement, page 7-16
Installation, page 7-23
RidgeRemoval,step15onpage7-14
Cylinder Bore Inspection, page 7-16
Warpage Inspection, page 7-16
Cylinder Bore Honing, page 7-18
Inspection, page 7-25
08/08/21 14:32:31 61SNR030_070_0004
ProCarManuals.com
DYNOMITE -2009-
Page 219 of 2893

(#'
")
µµ
µµ
Connecting Rod End Play
Standard (New): 0.15 0.30 mm (0.006 0.012 in.)
Service Limit: 0.40 mm (0.016 in.) Crankshaft End Play
Standard (New): 0.10 0.35 mm (0.004 0.014 in.)
Service Limit: 0.45 mm (0.018 in.)
7-5
Connecting Rod and Crankshaft End Play Inspection
1. Remove the oil pump (see page 8-16).
2. Remove the baffle plates (see step 8 on page 7-13).
3. Measure the connecting rod end play with a feeler
gauge between the connecting rod and the
crankshaft.
4. If the connecting rod end play is beyond the service limit, install a new connecting rod, and recheck. If it
is still beyond the service limit; replace the
crankshaft (see page 7-13). 5. Push the crankshaft firmly away from the dial
indicator, and zero the dial against the end of the
crankshaft. Then pull the crankshaft firmly back
toward the indicator, the dial reading should not
exceed the service limit.
6. If the end play is beyond the service limit, replace the thrust washers and recheck. If it is still beyond
the service limit, replace the crankshaft (see page
7-13).
08/08/21 14:32:32 61SNR030_070_0005
ProCarManuals.com
DYNOMITE -2009-
Page 220 of 2893

´
(#'
)
µ
µ
µ µ
Main Bearing Clearance Inspection
Main Bearing-to-Journal Oil Clearance
No.1,2,4,5Journals:
Standard (New): 0.017 0.041 mm (0.0007 0.0016 in.)
Service Limit: 0.050 mm (0.0020 in.)
No. 3 Journal:
Standard (New): 0.025 0.049 mm (0.0010 0.0019 in.)
Service Limit: 0.055 mm (0.0022 in.)
7-6 Engine Block
Crankshaft Main Bearing Replacement
1. To check the main bearing-to-journal oil clearance,
remove the lower block and the bearing halves
(see page 7-13).
2. Clean each main journal and bearing half with a clean shop towel.
3. Place one strip of plastigage across each main journal.
4. Reinstall the bearings and lower block, then tighten the bolts to 29 N·m (3.0 kgf·m, 22 lbf·ft) 56 ° in
thepropersequence(seestep19onpage7-27).
NOTE: Apply new engine oil to the bolt threads and flanges.
Do not rotate the crankshaft during inspection.
5. Remove the lower block and the bearings again, and measure the widest part of the plastigage. 6. If the plastigage measures too wide or too narrow,
remove the crankshaft, and remove the upper half
of the bearing. Install a new, complete bearing with
the appropriate color code(s), and recheck the
clearance. Do not file, shim, or scrape the bearings
or the caps to adjust clearance.
7. If the plastigage shows the clearance is still incorrect, try the next larger or smaller bearing (the
color listed above or below the current one), and
check again. If the proper clearance cannot be
obtained by using the appropriate larger or smaller
bearings, replace the crankshaft, and start over.
08/08/21 14:32:32 61SNR030_070_0006
ProCarManuals.com
DYNOMITE -2009-
Page 221 of 2893
Main Bearing Selection
Crankshaft Bore Code Location
Main Journal Code Location
7-7
No. 1 JOURNAL
(PULLEY END)
No. 5 JOURNAL
(TRANSMISSION END)
No. 1 JOURNAL No. 5 JOURNAL
1. Numbers, letters or bars have been stamped on theend of the engine block as a code for the size of
each of the five main journal bores. Write down the
crank bore codes.
If you cannot read the codes because of
accumulated dirt and dust, do not scrub them with
a wire brush or scraper. Clean them only with
solvent or detergent. 2. The main journal codes are stamped on the
crankshaft in either location.
(cont’d)
08/08/21 14:32:32 61SNR030_070_0007
ProCarManuals.com
DYNOMITE -2009-
Page 222 of 2893

´´
(#'
) µ
µ
µ µ
Connecting Rod Bearing Clearance
Inspection
Connecting Rod Bearing-to-Journal Oil Clearance
K20Z2 engine
Standard (New): 0.020 0.050 mm (0.0008 0.0020 in.)
Service Limit: 0.060 mm (0.0024 in.)
K20Z3 engine
Standard (New): 0.032 0.066 mm (0.0013 0.0026 in.)
Service Limit: 0.077 mm (0.0030 in.)
7-87-8 Engine Block
Crankshaft Main Bearing
Replacement (cont’d)
Connecting Rod Bearing
Replacement
Larger crank bore
1or
AorI 2or
BorII 3or
C or III4or
D or IIII
Smaller bearing (Thicker)
Blue
Pink
Yellow Green
Green/
Brown
Brown Green
Green/
Brown
Brown Green
Green/
Brown
Brown Green
Green/
Brown
Brown
Black Black/
Blue
Crank
bore
code
Pink/
YellowYellow
Yellow
Pink/
Yellow
Black
Black Black/
Blue
Main
journal
code
1
2
3
4
5
6
Smaller
main
journal Smaller
bearing
(Thicker)
3. Use the crank bore codes and crank journal codes
to select the appropriate replacement bearings
from the following table.
NOTE: Color code is on the edge of the bearing.
When using bearing halves of different colors, it does not matter which color is used in the top or
bottom. 1. Remove the oil pump (see page 8-16).
2. Remove the baffle plates (see step 8 on page 7-13).
3. Remove the connecting rod cap and the bearing
half.
4. Clean the crankshaft rod journal and the bearing half with a clean shop towel.
5. Place plastigage across the rod journal.
6. Reinstall the bearing half and connecting rod cap, and tighten the bolts to 20 N·m (2.0 kgf·m, 14 lbf·ft)90 ° (K20Z2 engine) or 29 N·m (3.0 kgf·m,
