Page 2873 of 2893

ACURA CSX 2006 Service Repair Manual
(# )
Removal
24-192SRS
Side Curtain Airbag Replacement
A
NOTE: If replacing the side curtain airbag after deployment, refer to Component Replacement/I

Page 2874 of 2893

ACURA CSX 2006 Service Repair Manual
24-193
AA
A A
A
4. Remove the mounting bolts (A) from the bracket.
(cont’d)
Left side shown; right side is similar.
08/08/21 14:01:57 61SNR030_240_0193
ProCarManuals.com
DYNOMITE -2009-

Page 2875 of 2893

ACURA CSX 2006 Service Repair Manual Î
Installation
24-194SRS
Side Curtain Airbag Replacement (cont’d)
A
6.0 N·m
(0.6 kgf·m, 4.0 lbf·ft)
A
6.0 N·m
(0.6 kgf·m, 4.0 lbf·ft)
A
9.8 N·m
(1.0 kgf·m, 7.2 lbf·ft) A
9.8 N·m
(1.0

Page 2876 of 2893

ACURA CSX 2006 Service Repair Manual
24-195
A
2. Connect the side curtain airbag 2P connector (A) to the floor wire harness.
3. Do the battery terminal reconnection procedure (see page 22-68).
4. Clear any DTCs (see page 24-23).
5.

Page 2877 of 2893

ACURA CSX 2006 Service Repair Manual Î

Î
(#
!)
Special Tools Required
Driver’s Airbag
Front Passenger’s Airbag
Side Airbag
Side Curtain Airbag
Deploying Airbags in the

Î

Î
(#'
!)
Special Tools Required
Driver’s Airbag
Front Passenger’s Airbag
Side Airbag
Side Curtain Airbag
Deploying Airbags in the Vehicle
24-196
SRS
Airbag and Tensioner Disposal
A
B
A
A
A
Deployment tool 07HAZ-SG00500
Before scrapping any airbags, side airbags, side curtain
airbags, seat belt tensioners, or seat belt buckle
tensioner (including those in a whole vehicle to be
scrapped), the part(s) must be deployed. If the vehicle is
still within the warranty period, the Honda District Parts
and Service Manager must give approval and/or special
instructions before deploying the part(s). Only after the
part(s) have been deployed (as the result of vehicle
collision, for example), can they be scrapped.
If the parts appear intact (not deployed), treat them with
extreme caution. Follow this procedure.
If an SRS equipped vehicle is to be entirely scrapped, its
airbags, side airbags, side curtain airbags, seat belt
tensioners, and seat belt buckle tensioner should be
deployed while still in the vehicle. These parts should
not be considered as salvageable parts and should
never be installed in another vehicle.1. Turn the ignition switch to LOCK (0), then disconnect the negative cable from the battery,
then wait at least 3 minutes before starting work.
2. Confirm that each airbag, side airbag, side curtain airbag, seat belt tensioner, or seat belt buckle
tensioner is securely mounted.
3. Confirm that the deployment tool is functioning properly by following the check procedure on the
tool label.
4. Remove the access panel (A) from the steering wheel, then disconnect the driver’s airbag 4P
connector (B) from the cable reel. 5. Remove the glove box, then disconnect the front
passenger’s airbag 4P connector (A) from the
dashboard wire harness.
6. Disconnect the side airbag 2P connector (A) from the floor wire harness.
7. Disconnect the floor wire harness 2P connector from the side curtain airbag (A).
08/08/21 14:01:58 61SNR030_240_0196
ProCarManuals.com
DYNOMITE -2009-

Page 2878 of 2893

ACURA CSX 2006 Service Repair Manual
Î
Î
Seat Belt Tensioner
Seat Belt Buckle Tensioner
24-197
A
A A
A
30 ft
(10 m) 07HAZ-SG00500
A 30 ft
(10 m)
07HAZ-SG00500
8. Disconnect the floor wire harness 4P connector (A) fro

Page 2879 of 2893

ACURA CSX 2006 Service Repair Manual

Deploying Components Out of the Vehicle
24-198SRS
Airbag and Tensioner Disposal (cont’d)
A
11. Connect a 12 V battery to the tool.
If the green light on the tool comes on, the ignitercirc

Page 2880 of 2893

ACURA CSX 2006 Service Repair Manual Disposal of Damaged ComponentsDeployment Tool Check
24-199
1. If installed in a vehicle, follow the removal
procedure for the driver’s airbag (see page 24-188),
front passenger’s airbag (see page
