Audio unit connector Wire color
YES
NO From terminal To terminals
YES
NO Audio unit
connector USB adapter
unit connector Wire color
YES
NO
23-237
AUDIO UNIT CONNECTOR E (14P)
AUDIO UNIT CONNECTOR E (14P)AUDIO UNIT CONNECTOR E (14P)
USB ADAPTER UNIT CONNECTOR A (14P)
11. Check for continuity between the terminals of audio unit connector E (14P) and body ground according
to the table.
E5 WHT
E6 RED
E13 BLK
E14 GRN
Short to body ground in the wire(s) between
the audio unit and the USB adapter unit. Replace
the affected shielded harness.
Go to step 12.
12. Check for continuity between the terminals of audio unit connector E (14P) according to the table.
E4 (GRY) E5 (WHT), E6 (RED), E13 (BLK), E14 (GRN)
E5 (WHT) E6 (RED), E13 (BLK), E14 (GRN)
E6 (RED) E13 (BLK), E14 (GRN)
E13 (BLK) E14 (GRN)
Short in the wires between the audio unit
and the USB adapter unit. Replace the affected
shielded harness.
Go to step 13. 13. Check for continuity between audio unit connector
E (14P) and USB adapter unit connector A (14P)
accordingtothetable.
E5 A5 WHT
E6 A6 RED
E13 A13 BLK
E14 A14 GRN
Substitute a known-good USB adapter unit
(see page 23-258), then reconnect all of the
connectors, and recheck. If the symptom/indication
goes away, replace the original USB adapter unit. If
the symptom/indication is still present, replace the
audio unit (see page 23-256).
Open in the wire(s) between the audio unit
and the USB adapter unit. Replace the affected
shielded harness.
Wire side of female terminals
Wire side of female terminals
Wire side of female terminals
Wire side of female terminalsIs there continuity?
I s t her e cont i nui t y bet w een any of t he t er mi nal s? Is there continuity?
