2006 ACURA CSX Service Repair Manual

engine oil capacity steering wheel wheelbase dashboard warning lights wiring charging

Page 2817 of 2893

ACURA CSX 2006 Service Repair Manual (#
-)
(#
-)
µ
µ µ
µ
DTC 45-2x, 45-3x, 45-Bx (‘‘x’’ can be 0 thru 9
or A thru F): DTC 46-2x, 46-

Page 2818 of 2893

ACURA CSX 2006 Service Repair Manual (#

--)(#
-

)
µ
µ µ
µ
DTC 51-xx, 52-xx, 53-xx, 54-xx, 55-xx (‘‘x’’ can
be 0 thru 9 or A thru F):

(#'
'
--)(#'
'-

)
µ
µ µ
µ
DTC 51-xx, 52-xx, 53-xx, 54-xx, 55-xx (‘‘x’’ can
be 0 thru 9 or A thru F): DTC Ex-11 (’’x’’ can be 0 thru 9 or A thru F):
YES
NO YES
NO
24-13824-138SRS
DTC Troubleshooting (cont’d)
Internal Failure of the
SRS Unit Control Operation Recorded
NOTE:
Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see page 24-13)
and General Troubleshooting Information (see page
24-22).
Before troubleshooting any of these DTCs, check the battery/system voltage and battery cable connections.
If the voltage is low, repair the charging system or
replace the battery before troubleshooting the SRS. If
the battery/system voltage is now OK, ask the client if
the battery ever went dead or if the engine was
started and run with the battery in a low state of
changed. A dead battery may trigger one or more of
these DTCs.
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Replace the SRS unit (see page 24-203).
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC. NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13) and General Troubleshooting Information
(see page 24-22).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Read the DTC (see page 24-22).
Faulty SRS unit; replace the SRS unit
(see page 24-203).
Intermittent failure, the system is OK at this
time. Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC.
Does the SRS indicator stay on, and is DT C 51-xx, 52-xx, 53-xx, 54-xx, or 55-xx indicated? Is DTC Ex-11 indicated?
08/08/21 13:59:45 61SNR030_240_0138
ProCarManuals.com
DYNOMITE -2009-

Page 2819 of 2893

ACURA CSX 2006 Service Repair Manual (#
-

)

(#

-) µ
µ
DTC Fx-11 (’’x’’ can be 0 thru 9 or A thru F): DTC 61-1x (‘‘x’’ can b

Page 2820 of 2893

ACURA CSX 2006 Service Repair Manual µ
µ µ
µ
YES
NO YES
NO
24-140SRS
DTC Troubleshooting (cont’d)
FLOOR WIRE HARNESS 3P CONNECTOR
BLK
5. From the system selection menu on the HDS, selectSRS then select SRS again, then selec

Page 2821 of 2893

ACURA CSX 2006 Service Repair Manual
(#

-)
µ
µ µ
µ
DTC 61-2x (‘‘x’’ can be 0 thru 9 or A thru F):
YES
NO YES
NO
24-141
A
Short in the Driver’s Seat Belt Buckle Switch
NOT

Page 2822 of 2893

ACURA CSX 2006 Service Repair Manual

(#

-)
µ
µ
µ
µ
µ
µ
DTC 62-1x (‘‘x’’ can be 0 thru 9 or A thru F):
YES
NO
YES
NO
YES
NO
24-142SRS
DTC Troubleshooting (cont’d)

(#'
'
-)
µ
µ
µ
µ
µ
µ
DTC 62-1x (‘‘x’’ can be 0 thru 9 or A thru F):
YES
NO
YES
NO
YES
NO
24-142SRS
DTC Troubleshooting (cont’d)
A
FLOOR WIRE HARNESS 3P CONNECTOR
BLK
Open in the Front Passenger’s Seat Belt
Buckle Switch
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13) and General Troubleshooting Information
(see page 24-22).1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), then buckle and unbuckle the driver’s seat belt s everal times.
3. Read the DTC (see page 24-22).
Go to step 4.
Intermittent failure, the system is OK at this
time. Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC.
4. Disconnect the floor wire harness 3P connector from the front passenger’s seat belt buckle switch
3P connector (A). 5. From the system selection menu on the HDS, select
SRS, then select SRS again, then select
PARAMETER INFORMATION, then Buckle Switch.
Seat Position Sensor, and check the status on the
HDS screen for FRONT RIGHT SEAT BELT BUCKLE
SWITCH when the seat belt is buckled, and
unbuckled.
If UNBUCKLE, BUCKLE, or SHORT is indicated open in the front passenger’s seat subharness, or
floor wire harness; replace the faulty harness.
If OPEN is indicated, go to step 6
6. Measure the resistance between floor wire harness 3P connector terminal No. 1 and body ground.
There should be less than 1.0 .
go to step 7.
Open in the floor wire harness or poor ground
connection at G602 (see page 22-38). If G602 is OK,
replace the floor wire harness, then clear the
DTC.
7. Alternately connect the No. 2 and No. 3 terminals of the floor wire harness 3P connector to body ground
with a jumper wire, and check the status on the
HDS screen.
Replace the front passenger’s seat belt
buckle assembly (see page 24-6), then clear the
DTC.
Open in the floor wire harness; replace the
floor wire harness, then clear the DTC.
Wire side of female terminals
Is DTC 62-1x indicated?
Is the resistance as specif ied?Does the status alternate f rom UNBUCK LE toBUCK LE?
08/08/21 13:59:46 61SNR030_240_0142
ProCarManuals.com
DYNOMITE -2009-

Page 2823 of 2893

ACURA CSX 2006 Service Repair Manual
(#
-)
µ
µ µ
µ
DTC 62-2x (‘‘x’’ can be 0 thru 9 or A thru F):
YES
NO YES
NO
24-143
A
Short in the Front Passenger’s Seat Belt
Buckle S

Page 2824 of 2893

ACURA CSX 2006 Service Repair Manual
(#

-)
µ
µ
µ
µ
DTC 71-1x (‘‘x’’ can be 0 thru 9 or A thru F):
YES
NO
YES
NO
24-144 SRS
DTC Troubleshooting (cont’d)
A
Open in the Dri

Load next 8 pages
