Page 2361 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual TROUBLE DIAGNOSIS — BASIC INSPECTION
AT-283
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
4.CHECK SHIFT UP (D3 TO D4 ) AND ENGINE BRAKE
Release accelerator pedal after shifting from D
2 to D3 .
Does

Page 2362 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual AT-284
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — BASIC INSPECTION
Cruise Test — Part 3
1. CHECK SHIFT DOWN (D4 TO D3 )
1. Confirm overdrive control switch is in “ON” position.
2. Confirm selector

Page 2363 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual TROUBLE DIAGNOSIS — BASIC INSPECTION
AT-285
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
2.CHECK ENGINE BRAKE
Does vehicle decelerate by engine brake?
Ye s o r N o
Ye s > > G O T O 3 .
No >>
�

Page 2364 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual AT-286
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — BASIC INSPECTION
6. CHECK ENGINE BRAKE
Does vehicle decelerate by engine brake?
Ye s o r N o
Yes >> 1. Stop vehicle.
2. Perform self-diagnosis.
Excep

Page 2365 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-287
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONPFP:00000
Symptom ChartECS004VV
Numbers are arranged in order of in

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-287
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONPFP:00000
Symptom ChartECS004VV
Numbers are arranged in order of inspection.
Perform inspections starting with number one and work up.
Symptom Condition Diagnostic Item Reference Page
Engine cannot start in “P” and “N”
positions.
AT-314, "
Engine Cannot Be Started In
“P” and “N” Position"
ON vehicle1. Ignition switch and starterPG-2, "
POWER SUPPLY
ROUTING",
SC-20, "
STARTING SYS-
TEM"
2. Control cable adjustmentAT- 4 1 6 , "Control Cable
Adjustment"
3. PNP switchAT- 3 4 4 , "TCM Self-diag-
nosis Does Not Activate"
Engine starts in position other than
“N” and “P” positions.
AT-314, "
Engine Cannot Be Started In
“P” and “N” Position"
ON vehicle1. Control cable adjustmentAT- 4 1 6 , "
Control Cable
Adjustment"
2. PNP switchAT- 3 4 4 , "TCM Self-diag-
nosis Does Not Activate"
Transaxle noise in “P” and “N” posi-
tions.ON vehicle1. Fluid levelAT- 2 6 4 , "
FLUID LEVEL
CHECK"
2. Line pressure testAT- 2 6 8 , "Line Pressure
Te s t"
3. Accelerator pedal position (APP) sensorAT- 3 6 2 , "
ACCELE
RATOR PEDAL POSI-
TION (APP) SENSOR"
4. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTRAT- 3 5 3 , "
VEHICLE
SPEED SENSOR·A/T
(REVOLUTION SEN-
SOR)",
AT- 3 5 8 , "
DTC VEHICLE
SPEED SENSOR MTR"
OFF vehicle5. Oil pumpAT- 4 4 4 , "
Oil Pump"
6. Torque converterAT- 4 2 5 , "
Locations of
Adjusting Shims, Needle
Bearings, Thrust Washers
and Snap Rings"
Vehicle moves when changing into “P”
position, or parking gear does not dis-
engage when shifted out of “P” posi-
tion.
AT-315, "
In “P” Position, Vehicle
Moves Forward Or Backward When
Pushed"
ON vehicle 1. Control cable adjustmentAT- 4 1 6 , "Control Cable
Adjustment"
OFF vehicle 2. Parking componentsAT- 4 2 1 , "
Components",
AT- 4 4 1 , "
REPAIR FOR
COMPONENT PARTS"
Vehicle runs in “N” position.
AT-315, "
In “N” Position, Vehicle
Moves"
ON vehicle 1. Control cable adjustmentAT- 4 1 6 , "Control Cable
Adjustment"
OFF vehicle2. Forward clutchAT- 4 7 1 , "
Forward and
Overrun Clutches"
3. Reverse clutchAT- 4 6 3 , "Reverse Clutch"
4. Overrun clutchAT- 4 7 1 , "Forward and
Overrun Clutches"

Page 2366 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual AT-288
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Vehicle will not run in “R” position (but
runs in “D”, “2” and “1” positions).
Clutch slips.
Very poor acceleration.

Page 2367 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
AT-289
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT
Sharp shock in shifting from “N” to “D”
position.ON vehicle1. Engine idling rpmEC-1391, "
I d l

Page 2368 of 3833

NISSAN X-TRAIL 2001 Service Repair Manual AT-290
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Vehicle will not run in “D”, “1”, “2” posi-
tions (but runs in “R” position). Clutch
slips. Very poor acceleration.
A
