Page 4409 of 4449

WW-18
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
4. Touch “WIPER”.
DATA MONITOR
Operation Procedure
1. Touch “WIPER” on the “SELECT TEST ITEM” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
3. Touch either “ALL ITEMS” or “SELECTION FROM MENU” on “DATA MONITOR” screen.
4. Touch “START”.
5. When “SELECTION FROM MENU” is selected, touched items to be monitored. If “ALL SIGNALS” is
selected, all items will be monitored.
6. Touch “RECORDING START” while monitoring to record the status of the item being monitored. To stop
recording, touch “RECORDING STOP”.
Display Item List
PKIA5223E
ALL SIGNALS Monitors all the signals.
SELECTION FROM MENU Selects and monitors individual signals.
Monitor item [operation or unit] Display content
IGN ON SW [ON/OFF]Displays “ignition switch ON (ON)/Other OFF or ACC (OFF)” status as judged from ignition switch
signal.
IGN SW CAN [ON/OFF]Displays “ignition switch ON (ON)/Other OFF or ACC (OFF)” status as judged from CAN commu-
nication signal.
FR WIPER HI [ON/OFF] Displays “FRONT WIPER HI (ON)/Other (OFF)” status as judged from wiper switch signal.
FR WIPER LOW [ON/OFF] Displays “FRONT WIPER LOW (ON)/Other (OFF)” status as judged from wiper switch signal.
FR WIPER INT [ON/OFF] Displays “FRONT WIPER INT (ON)/Other (OFF)” status as judged from wiper switch signal.
FR WASHER SW [ON/OFF] Displays “FRONT WASHER Switch (ON)/Other (OFF)” status as judged from wiper switch signal.
INT VOLUME [1 - 7] Displays intermittent operation dial position setting (1 - 7) as judged from wiper switch signal.
FR WIPER STOP [ON/OFF] Displays “Stopped (ON)/Operating (OFF)” status as judged from the auto-stop signal.
VEHICLE SPEED [km/h] Displays vehicle speed status as judged from vehicle speed signal.
RR WIPER ON [ON/OFF] Displays “REAR WIPER ON (ON)/Other (OFF)” status as judged from wiper switch signal.
RR WIPER INT [ON/OFF] Displays “REAR WIPER INT (ON)/Other (OFF)” status as judged from wiper switch signal.
RR WASHER SW [ON/OFF] Displays “REAR WASHER Switch (ON)/Other (OFF)” status as judged from wiper switch signal.
RR WIPER STOP [ON/OFF] Displays “REAR WIPER Stop (ON)/Other (OFF)” status, as judged from wiper switch signal.
Page 4410 of 4449

FRONT WIPER AND WASHER SYSTEM
WW-19
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
ACTIVE TEST
Operation Procedure
1. Touch “WIPER” on the “SELECT TEST ITEM” screen.
2. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Touch items to be tested, and check operation.
4. During operation check, touching “STOP” deactivates operation.
Display Item List
CONSULT-II Functions (IPDM E/R)AKS007AE
CONSULT-II can display each diagnostic item using the following diagnostic test modes: work support, self-
diagnostic results, data monitor and active test through data reception and command transmission via the
IPDM E/R CAN communication line.
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
SULT-II CONVERTER to the data link connector, then turn the
ignition switch ON.
2. Touch “START (NISSAN BASED VHCL)”.
Test item Indication on CONSULT-II display Description
Front wiper output FRONT WIPER With a certain operation (OFF, HI, LO, INT), the front wiper can be operated.
Rear wiper output RR WIPER Rear wiper can be operated by any ON-OFF operation.
Inspection Item, Diagnosis Mode Description
SELF-DIAGNOSTIC RESULTS The IPDM E/R performs self-diagnosis of CAN communication.
DATA MONITOR The input/output data of the IPDM E/R is displayed in real time.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagosis of CAN commnucation can be read.
ACTIVE TEST The IPDM E/R sends a drive signal to electronic components to check their operation.
PBIB1503E
SKIA3098E
Page 4411 of 4449

WW-20
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
3. Touch “IPDM E/R” on “SELECT SYSTEM” screen.
If “IPDM E/R” is not displayed, print “SELECT SYSTEM” screen,
then refer to GI-40, "
CONSULT-II Data Link Connector (DLC)
Circuit" .
4. Select the desired part to be diagnosed on the “SELECT DIAG
MODE” screen.
SELF-DIAGNOSTIC RESULTS
Refer to PG-21, "SELF-DIAG RESULTS" .
DATA MONITOR
Operation Procedure
1. Touch “DATA MONITOR” on “SELECT DIAG MODE ” screen.
2. Touch “ALL SIGNALS”, “MAIN SIGNALS” or “SELECTION FROM MENU” on the “DATA MONITOR”
screen.
3. Touch “START”.
4. Touch the required monitoring item on “SELECTION FROM MENU”. In “ALL SIGNALS”, all items are
monitored. In “MAIN SIGNALS”, predetermined items are monitored.
5. Touch “RECORD” while monitoring to record the status of the item being monitored. To stop recording,
touch “STOP”.
All Signals, Main Signals, Selection From Menu
NOTE:
Perform monitoring of IPDM E/R data with the ignition switch ON. When the ignition switch is at ACC, the dis-
play may not be correct.
PKIA5222E
PKIA6016E
ALL SIGNALS All items will be monitored.
MAIN SIGNALS Monitor the predetermined item.
SELECTION FROM MENU Select any item for monitoring.
Item nameCONSULT-II
screen displayDisplay or unitMonitor item selection
Description
ALL
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU
FR wiper request FR WIP REQ STOP/1LO/LO/HI×× ×Signal status input from BCM
Wiper auto stop WIP AUTO STOP ACT P/STOP P×× ×Output status of IPDM E/R
Wiper protection WIP PROT OFF/LS/HS/Block×× ×Control status of IPDM E/R
Page 4412 of 4449

FRONT WIPER AND WASHER SYSTEM
WW-21
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
ACTIVE TEST
Operation Procedure
1. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
2. Touch item to be tested, and check operation.
3. Touch “START”.
4. Touch “STOP” while testing to stop the operation.
Front Wiper Does Not OperateAKS0079W
CAUTION:
During IPDM E/R fail-safe control, front wipers may not operate. Refer to PG-18, "CAN COMMUNI-
CATION LINE CONTROL" in “PG IPDM E/R” to make sure that it is not in fail-safe status.
1. CHECK IPDM E/R TO FRONT WIPERS (1)
With CONSULT-ll
1. Select “IPDM E/R” on CONSULT-II, and select “ACTIVE TEST”
on “SELECT DIAG MODE” screen.
2. Select “FRONT WIPER” on “SELECT TEST ITEM” screen.
Without CONSULT-ll
Start up auto active test. Refer to PG-24, "
Auto Active Test" .
Does the front wiper operate normally?
YES >> GO TO 6.
NO >> GO TO 2.
2. CHECK FUSE
1. Turn ignition switch OFF.
2. Check fuse No. 73 of IPDM E/R.
OK or NG
OK >> GO TO 3.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
3, "POWER SUPPLY ROUTING CIRCUIT" .
Test item CONSULT-II screen display Description
Front wiper (HI, LO) output FRONT WIPERWith a certain operation (OFF, HI ON, LO ON), the front wiper relay
(Lo, Hi) can be operated.
SKIA3486E
Page 4413 of 4449
WW-22
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
3. CHECK IPDM E/R TO FRONT WIPERS (2)
1. Disconnect IPDM E/R connector and front wiper motor connec-
tor.
2. Check continuity between IPDM E/R harness connector and
front wiper motor harness connector terminal.
3. Check continuity between IPDM E/R harness connector terminal and Ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK CIRCUITE BETWEEN FRONT WIPERS AND GROUND
Check continuity between front wiper motor harness connector E57
terminal 2 (B) and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
Terminals
Continuity IPDM E/R Front wiper motor
ConnectorTerminal
(Wire color)ConnectorTerminal
(Wire color)
E721 (P)
E571 (P)
Ye s 31 (PU) 4 (PU)
32 (L) 5 (L)
Terminals
Continuity IPDM E/R
Connector Terminal (Wire color)
E721 (P)
Ground No 31 (PU)
32 (L)
PKIA5192E
2 (B) - Ground : Continuity should exist.
PKIA5193E
Page 4414 of 4449

FRONT WIPER AND WASHER SYSTEM
WW-23
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
5. CHECK IPDM E/R
With CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Using active test, check voltage between IPDM E/R harness
connector terminal and ground while front wiper (HI, LO) is oper-
ating.
Without CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Start up auto active test, and check voltage between IPDM E/R
harness connector terminal and ground while front wiper (HI,
LO) is operating.
OK or NG
OK >> Replace front wiper motor.
NG >> Replace IPDM E/R.
6. CHECK CIRCUIT BETWEEN COMBINATION SWITCH AND BCM
With CONSULT-ll
Select “BCM” on CONSULT-II. With “WIPER” on “DATA MONITOR”,
confirm that “FRONT WIPER INT”, “FRONT WIPER LOW”, and
“FRONT WIPER HI” turn ON-OFF according to wiper switch opera-
tion.
Without CONSULT-ll
Refer to LT- 11 3 , "
Combination Switch Inspection" .
OK or NG
OK >> GO TO 7.
NG >> Check wiper Switch. Refer to LT- 11 3 , "
Combination
Switch Inspection" .
7. CHECK CIRCUIT BETWEEN IPDM E/R AND BCM
Select “BCM” on CONSULT-II, and perform self-diagnosis for
“BCM”.
Displayed self
-diagnosis results
NO DTC>>Replace BCM. Refer to BCS-15, "Removal and Installa-
tion of BCM" .
CAN COMM CIRCUIT>>Check CAN communication line of BCM.
GO TO BCS-14, "
CAN Communication Inspection Using
CONSULT-II (Self-Diagnosis)" .
Terminals
Condition Voltage IPDM E/R(+)
(-)
Connector Terminal (Wire color)
E721 (P)
GroundStopped Approx. 0V
LO operation Battery voltage
31 (PU)Stopped Approx. 0V
HI operation Battery voltagePKIA5194E
SKIA5300E
SKIA1039E
Page 4415 of 4449

WW-24
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
Front Wiper Does Not Return to Stop PositionAKS0079X
1. CHECK CIRCUIT BETWEEN IPDM E/R AND WIPER MOTOR (1)
With CONSULT-ll
Select “IPDM E/R” on CONSULT-II. With data monitor, confirm that
“WIP AUTO STOP” turns “ACT P” - “STOP P” linked with wiper oper-
ation.
Without CONSULT-ll
GO TO 2.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
2. CHECK CIRCUIT BETWEEN IPDM E/R AND WIPER MOTOR (2)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connec-
tor.
3. Check continuity between IPDM E/R harness connector E7 ter-
minal 32 (L) and front wiper motor harness connector E57 termi-
nal 5 (L).
4. Check continuity between IPDM E/R harness connector E7 ter-
minal 32 (L) and Ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK IPDM E/R
1. Connect IPDM E/R connector and front wiper motor connector.
2. Turn ignition switch ON.
3. Check voltage between IPDM E/R harness connector terminal
and ground while front wiper motor is stopped and while it is
operating.
OK or NG
OK >> Replace IPDM E/R.
NG >> Replace front wiper motor.
Only Front Wiper LO Does Not OperateAKS0079Y
Refer to LT- 11 3 , "Combination Switch Inspection" .
SKIA5301E
32 (L) - 5 (L) : Continuity should exist.
32 (L) - Ground : Continuity should not exist.
PKIA5195E
Terminals
Condition Voltage IPDM E/R(+)
(-)
ConnectorTe r m i n a l
(Wire color)
E7 32 (L) GroundWiper stopped Approx. 0V
Wiper operating Battery voltage
PKIA5196E
Page 4416 of 4449

FRONT WIPER AND WASHER SYSTEM
WW-25
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
Only Front Wiper HI Does Not OperateAKS0079Z
1. CHECK CIRCUIT BETWEEN IPDM E/R AND FRONT WIPERS (1)
With CONSULT-ll
1. Select “IPDM E/R” on CONSULT-II, and select “ACTIVE TEST”
on “SELECT DIAG MODE” screen.
2. Select “FRONT WIPER” on “SELECT TEST ITEM” screen.
Without CONSULT-ll
Start up auto active test. Refer to PG-24, "
Auto Active Test" .
Does the front wiper operate normally?
YES >> GO TO LT- 11 3 , "Combination Switch Inspection" .
NO >> GO TO 2.
2. CHECK CIRCUIT BETWEEN IPDM E/R AND FRONT WIPERS (2)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connec-
tor.
3. Check continuity between IPDM E/R harness connector E7 ter-
minal 31 (PU) and front wiper motor harness E57 connector ter-
minal 4 (PU).
4. Check continuity between IPDM E/R harness connector E7 ter-
minal 31 (PU) and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK IPDM E/R
With CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Using active test, check voltage between IPDM E/R harness
connector E7 terminal 31 (PU) and ground while front wiper (HI)
is operating.
Without CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Start up auto active test, and check voltage between IPDM E/R
harness connector E7 terminal 31 (PU) and ground while front
wiper HI is operating.
OK or NG
OK >> Replace front wiper motor.
NG >> Replace IPDM E/R.
Only Front Wiper INT Does Not OperateAKS007A0
Refer to LT- 11 3 , "Combination Switch Inspection" .
SKIA3486E
31 (PU) - 4 (PU) : Continuity should exist.
31 (PU) - Ground : Continuity should not exist.
PKIA5197E
31 (PU) - Ground : Battery voltagePKIA5198E
