BRC-36
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
ON and OFF Timing for ABS Warning Lamp, VDC OFF Indicator Lamp, SLIP Indicator Lamp,
Brake Warning Lamp
×: ON –: OFF
NOTE:
1. Brake warning lamp will turn on in case of operating parking brake (switch turned on) or of actuating brake
fluid level switch (brake fluid is insufficient).
2. After starting engine, turn OFF.
Basic InspectionAFS001SS
BASIC INSPECTION 1: BRAKE FLUID AMOUNT, LEAKS, AND BRAKE PADS INSPECTION
1. Check fluid level in the brake reservoir tank. If fluid level is low, refill brake fluid.
2. Check brake piping and around ABS actuator and electric unit (control unit) for leaks. If there is leaking or
oozing fluid, check the following items.
If ABS actuator and electric unit (control unit) connection is loose, tighten piping to the specified torque
and re-perform the leak inspection to make sure there are no leaks.
If there is damage to the connection flare nut or ABS actuator and electric unit (control unit) screw,
replace the damaged part and re-perform the leak inspection to make sure there are no leaks.
When there is fluid leaking or oozing from a part other than ABS actuator and electric unit (control unit)
connection, if fluid is just oozing out, use a clean cloth to wipe off the oozing fluid and re-check for
leaks. If fluid is still oozing out, replace the damaged part.
When there is fluid leaking or oozing at ABS actuator and electric unit (control unit), if fluid is just oozing
out, use a clean cloth to wipe off oozing fluid and re-check for leaks. If fluid is still oozing out, replace
ABS actuator and electric unit (control unit) body.
CAUTION:
ABS actuator and electric unit (control unit) body cannot be disassembled.
3. Check brake pad degree of wear. Refer to BR-20, "
PAD WEAR INSPECTION" in “Front Disc Brake” and
BR-25, "
PAD WEAR INSPECTION" in “Rear Disc Brake”
BASIC INSPECTION 2: POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPEC-
TION
Make sure battery positive cable, negative cable and ground connection are not loose. If looseness is
detected, tighten the cables. In addition, check the battery voltage to make sure it has not dropped and alter-
nator is normal.
ConditionABS warning
lampVDC OFF indi-
cator lampSLIP indicator
lampBrake warning
lamp [Note 1]Remarks
Ignition SW OFF. – – – — —
Approx. 2 seconds after igni-
tion switch is turned ON.×××× [Note 2] —
Approx. 2 seconds later after
ignition switch ON.–––× [Note 2]Go out 2 seconds after
ignition switch is turned
ON.
VDC OFF SW is turned ON.
(VDC/TCS function is OFF.)–×–— —
VDC/TCS/ABS error.×××—There is an ABS actua-
tor and electric unit
(control unit) error.
(Power, ground or sys-
tem malfunction)
When VDC/TCS is not func-
tioning normally.–××——
EBD error.××××—
Page 1162 of 4449
![INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-37
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
BASIC INSPECTION 3: ABS WARNING LAMP, VDC OFF INDICATOR LAMP, SLIP INDICATOR
LAMP AND BRAKE WA INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-37
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
BASIC INSPECTION 3: ABS WARNING LAMP, VDC OFF INDICATOR LAMP, SLIP INDICATOR
LAMP AND BRAKE WA](/manual-img/42/57021/w960_57021-1161.png)
TROUBLE DIAGNOSIS
BRC-37
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
BASIC INSPECTION 3: ABS WARNING LAMP, VDC OFF INDICATOR LAMP, SLIP INDICATOR
LAMP AND BRAKE WARNING LAMP INSPECTION
1. Make sure ABS warning lamp, VDC OFF indicator lamp (when VDC OFF switch is OFF), and SLIP indica-
tor lamp turns on approximately 2 second, and brake warning lamp turns on when ignition switch is turned
ON. If they do not, check VDC OFF indicator lamp and then VDC OFF switch. Refer to BRC-53, "
VDC
OFF SWITCH" . Check CAN communications. Refer to “CAN Communication Inspection”. If there are no
errors with VDC OFF switch and CAN communication system, check combination meter. Refer to DI-4,
"COMBINATION METERS" .
2. Make sure ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp turn off approximately 2 sec-
ond after turn ignition switch ON, and brake warning lamp turns off after engine starts. If lamps do not turn
off, perform self-diagnosis.
3. With engine running, make sure VDC OFF indicator lamp turns on and off when VDC OFF switch is
turned ON and OFF. If indicator lamp status does not correspond to switch operation, check the VDC OFF
switch system. Refer to BRC-53, "
VDC OFF SWITCH" .
4. Make sure ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp turn off 2 seconds after
engine is started. If ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp have not turned
off 10 seconds after engine has been started, perform self-diagnosis of ABS actuator and electric unit
(control unit).
5. After performing the self-diagnosis, be sure to erase the error memory. Refer to BRC-27, "
SELF-DIAGNO-
SIS" .
CAUTION:
Brake warning lamp turns on when parking brake is operated (switch on) and brake fluid level
switch is activated (leak of brake fluid).
Inspection 1: Wheel Sensor SystemAFS001ST
DTC C1101-C1108
After using the CONSULT-II SELF-DIAG RESULTS to determine the location of the malfunctioning wheel sen-
sor, check all areas to determine the component to be replaced.
CAUTION:
Do not measure the resistance value and also voltage between sensor terminal with tester etc.,
because sensor is an active sensor.
Do not expand terminal of connector with a tester terminal stick, when it does the inspection with
tester.
INSPECTION PROCEDURE
1. CHECK TIRE
Check air pressure, wear and size.
Are air pressure, wear, and size within the standard values?
YES >> GO TO 2.
NO >> Adjust air pressure, or replace tire.
2. CHECK SENSOR AND SENSOR ROTOR
Check the condition of the sensor mount (for looseness, etc.).
Check the surface of front sensor rotor rubber for damage.
Check rear sensor rotor for damage.
OK or NG
OK >> GO TO 3.
NG >> Repair sensor mount or replace sensor rotor.
Page 1163 of 4449
BRC-38
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
3. CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 4.
NO >> INSPECTION END.
4. CHECK CONNECTOR
1. Disconnect ABS actuator and electric unit (control unit) connector and malfunctioning wheel sensor con-
nector E46 (FR-LH), E33 (FR-RH) or B69 (RR). Check terminal for deformation, open circuit, poor con-
tact, etc., and repair or replace if any malfunctioning condition is found.
2. Reconnect connectors, drive at a speed of approximately 30 km/h (19 MPH) or more for approximately
1minute, and perform self-diagnosis.
OK or NG
OK >> Connector terminal contact is loose, damaged, open or shorted.
NG >> GO TO 5.
Self-diagnosis results
FR RH SENSOR-1,-2
FR LH SENSOR- 1,-2
RR RH SENSOR-1,-2
RR LH SENSOR-1,- 2
Page 1164 of 4449
![INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-39
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
5. CHECK WHEEL SENSOR HARNESS
1. Turn ignition switch OFF and disconnect malfunctioning wheel
s INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-39
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
5. CHECK WHEEL SENSOR HARNESS
1. Turn ignition switch OFF and disconnect malfunctioning wheel
s](/manual-img/42/57021/w960_57021-1163.png)
TROUBLE DIAGNOSIS
BRC-39
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
5. CHECK WHEEL SENSOR HARNESS
1. Turn ignition switch OFF and disconnect malfunctioning wheel
sensor connector E46 (FR-LH), E33 (FR-RH) or B69 (RR) and
ABS actuator and electric unit (control unit) connector.
2. Check continuity between terminals. (Also check the continuity
when steering wheel is turned right and left and when sensor
harness inside wheel well is moved.)
OK or NG
OK >> GO TO 6.
NG >> Repair or replace harness and connector that have malfunction.
6. CHECK WHEEL SENSOR
1. Replace wheel sensor that resulted in malfunction by self-diagnosis.
2. Reconnect connectors, drive vehicle at 30 km/h (19 MPH) or more for approximately 1 minute, and then
perform self-diagnosis.
Is above displayed on self-diagnosis display?
OK >> Wheel sensor has malfunction.
NG >>
Replace ABS actuator and electric unit (control unit).
Perform to self-diagnosis again, and make sure that the result shows “NO DTC IS DETECTED.
FURTHER TESTING MAY BE REQUIRED”.
Inspection 2: Engine SystemAFS001SU
DTC C1130-C1133, C1136
SFIA1186E
Power system Signal system Ground system
WheelABS actuator
and electric unit
(control unit)
harness con-
nector E56Wheel sensor
harness con-
nector E46,
E33 or B69ABS actuator
and electric unit
(control unit)
harness con-
nector E56Wheel sensor
harness con-
nector E46,
E33 or B69ABS actuator and
electric unit (con-
trol unit) harness
connector E56
(signal)ABS actuator
and electric unit
(control unit)
harness con-
nector E56
(ground)
Front RH (E33) 34 (W) 1 (W) 33 (B) 2 (B) 33 (B), 34 (W)
16 (B), 47 (B) Front LH (E46) 45 (R) 1 (R) 46 (G) 2 (G) 45 (R), 46 (G)
Rear RH (B69) 43 (Y) 1 (Y) 42 (BR) 2 (BR) 43 (Y), 42 (BR)
Rear LH (B69) 36 (L) 3 (L) 37 (P) 4 (P) 36 (L), 37 (P)
Power system : Continuity should exist.
Signal system : Continuity should exist.
Ground system : Continuity should not exist.
Page 1165 of 4449
![INFINITI FX35 2004 Service Manual BRC-40
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the sel INFINITI FX35 2004 Service Manual BRC-40
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the sel](/manual-img/42/57021/w960_57021-1164.png)
BRC-40
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK ENGINE SYSTEM
1. Perform an ECM self-diagnosis and repair or replace malfunctioning items. Re-perform ECM self-diagno-
sis.
2. Re-perform ABS actuator and electric unit (control unit) self-diagnosis.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace malfunctioning items. Re-perform the self-diagnosis.
Inspection 3: VDC/TCS/ABS Control Unit SystemAFS001SV
DTC C1110
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the self-diagnosis display items?
YES >> Replace ABS actuator and electric unit (control unit). Re-perform the self-diagnosis.
NO >> INSPECTION END
Inspection 4: Pressure Sensor SystemAFS001SW
DTC C1142
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> INSPECTION END
Self-diagnostic results
ENGINE SIGNAL 1
ENGINE SIGNAL 2
ENGINE SIGNAL 3
ENGINE SIGNAL 4
ENGINE SIGNAL 6
Self-diagnostic results
CONTROLLER FAILURE
Self-diagnostic results
PRESS SEN CIRCUIT
Page 1166 of 4449
![INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-41
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
2. CHECK CONNECTOR
1. Disconnect pressure sensor connector and ABS actuator and electric unit ( INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-41
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
2. CHECK CONNECTOR
1. Disconnect pressure sensor connector and ABS actuator and electric unit (](/manual-img/42/57021/w960_57021-1165.png)
TROUBLE DIAGNOSIS
BRC-41
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
2. CHECK CONNECTOR
1. Disconnect pressure sensor connector and ABS actuator and electric unit (control unit) connector, check
terminals for deformation, disconnection, looseness, and so on. If any malfunction is found, repair or
replace terminal.
2. Reconnect connectors and Re-perform ABS actuator and electric unit (control unit) self-diagnosis.
OK or NG
OK >> Connector terminal contact is loose, damaged, open or shorted.
NG >> GO TO 3.
3. CHECK PRESSURE SENSOR HARNESS
1. Turn ignition switch OFF and disconnect pressure sensor con-
nector and ABS actuator and electric unit (control unit) connec-
tor.
2. Check continuity between ABS actuator and electric unit (control
unit) harness connector E56 and pressure sensor harness con-
nector E53.
OK or NG
OK >> GO TO 4.
NG >> If the open or short in harness, repair or replace harness.
4. PRESSURE SENSOR INSPECTION
1. Connect pressure sensor connector and ABS actuator and electric unit (control unit) connector.
2. Use CONSULT-II “Data Monitor” to check pressure sensor value.
OK or NG
OK >> INSPECTION END
NG >> Pressure sensor is damaged or malfunctioning, replace pressure sensor.
SFIA1188E
ABS actuator and electric
unit (control unit)
(Harness connector E56)Pressure sensor
(Harness connector E53)Continuity
19 (L) 1 (L) Yes
20 (Y) 2 (Y) Yes
18 (W) 3 (W) Yes
Condition Data monitor display
When brake pedal is depressed. Positive value
When brake pedal is released. Approx. 0 bar
Page 1167 of 4449
BRC-42
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
Inspection 5: Steering Angle Sensor SystemAFS001SX
DTC C1143
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the self-diagnosis item?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Disconnect steering angle sensor connector and ABS actuator and electric unit (control unit) connector
and check terminals for deformation, disconnection, looseness, and so on. If any malfunction is found,
repair or replace terminal.
2. Reconnect connectors and Re-perform a ABS actuator and electric unit (control unit) self-diagnosis.
OK or NG
OK >> Connector terminal contact is loose, damaged, open or shorted.
NG >> GO TO 3.
Self-diagnosis results
ST ANG SEN CIRCUIT
Page 1168 of 4449
TROUBLE DIAGNOSIS
BRC-43
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
3. CHECK STEERING ANGLE SENSOR HARNESS
1. Check CAN communication system. Refer to BRC-53, "
Inspection 14: CAN Communication System" .
2. Turn ignition switch OFF and disconnect steering angle sensor connector.
3. Check continuity between steering angle sensor harness con-
nector M14 and ground.
4. Check voltage between steering angle sensor harness connec-
tor M14 and ground.
OK or NG
OK >> GO TO 4.
NG >> If the open or short in harness, repair or replace harness.
4. CHECK STEERING WHEEL PLAY
Check steering wheel play. Refer to PS-10, "
CHECKING STEERING WHEEL PLAY" .
OK or NG
OK >> GO TO 5
NG >> Adjustment steering wheel play.
SFIA1189E
Steering angle sensor
(Harness connector M14)Ground Continuity
2 (B) — Yes
SFIA1190E
Steering angle sensor
(Harness connector M14)GroundVoltage (V)
(Approx.)
3 (G/R) — 12V
