Page 2873 of 4449

INFINITI FX35 2004 Service Manual EM-148 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2004 November 2004 FX35/FX45 CAMSHAFT AND CAMSHAFT BEARING Unit: mm (in) *: Total indicator reading Valve Lifter Unit: mm (in) Valve Cle

Page 2874 of 4449

INFINITI FX35 2004 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-149 [VQ35DE] C D E F G H I J K L MA EM Revision: 2004 November 2004 FX35/FX45 Available Valve Lifter Unit: mm (in) Identification (stamped) Mark Thickness 788U

Page 2875 of 4449

INFINITI FX35 2004 Service Manual EM-150 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2004 November 2004 FX35/FX45 CYLINDER HEAD Unit: mm (in) Valve Dimensions Unit: mm (in) Items Standard Limit Head surface distortion 0.0

Page 2876 of 4449

INFINITI FX35 2004 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-151 [VQ35DE] C D E F G H I J K L MA EM Revision: 2004 November 2004 FX35/FX45 Valve Guide Unit: mm (in) Items Standard 0.2 (0.008) Oversize (Service) Valve gui

Page 2877 of 4449

INFINITI FX35 2004 Service Manual EM-152 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2004 November 2004 FX35/FX45 Valve Seat Unit: mm (in) Valve Spring Items Standard Oversize [0.5 (0.020)] (Service) Cylinder head seat re

Page 2878 of 4449

INFINITI FX35 2004 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-153 [VQ35DE] C D E F G H I J K L MA EM Revision: 2004 November 2004 FX35/FX45 CYLINDER BLOCK Unit: mm (in) Surface flatnessStandard 0.03 (0.0012) Limit 0.10 (0

Page 2879 of 4449

INFINITI FX35 2004 Service Manual EM-154 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2004 November 2004 FX35/FX45 PISTON, PISTON RING AND PISTON PIN Available Piston Unit: mm (in) Piston Ring Unit: mm (in) Piston Pin Unit

Page 2880 of 4449

INFINITI FX35 2004 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-155 [VQ35DE] C D E F G H I J K L MA EM Revision: 2004 November 2004 FX35/FX45 CONNECTING ROD Unit: mm (in) *: After installing in connecting rodItems Standard
