GW-42
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
Trouble Diagnosis Symptom Chart / With Front Power Window Anti-pinch Sys-
tem
AIS004QC
Make sure other systems using the signal of the following systems operate normally.
Symptom Repair order Refer to page
None of the power windows can be operated using any switch.1. BCM power supply and ground circuit checkGW-44
2. Power window main switch power supply
and ground circuit checkGW-45
3. Power window serial link checkGW-71
Driver side power window alone does not operated.1. Front power window motor (driver side) cir-
cuit checkGW-48
2. Replace power window main switch —
Front passenger side power window alone does not operated.1. Front power window switch (passenger side)
power and ground circuit checkGW-46
2. Power window serial link checkGW-71
3. Front power window motor (passenger side)
circuit checkGW-49
4. Replace BCMBCS-15
Rear LH side power window alone does not operated 1. Rear power window motor (LH) circuit checkGW-50
Rear RH side power window alone does not operated 1. Rear power window motor (RH) circuit checkGW-52
Anti-pinch system does not operate normally (driver side)1. Door window sliding part malfunction
A foreign material adheres to window glass
or glass run rubber.
Glass run rubber wear or deformation.
Sash is tilted too much, or no enough.—
2. Limit switch adjustingGW-78
3. Limit switch circuit check (driver side)GW-56
4. Encoder circuit check (driver side)GW-61
Anti-pinch system does not operate normally (passenger side)1. Door window sliding part malfunction
A foreign material adheres to window glass
or glass run rubber.
Glass run rubber wear or deformation.
Sash is tilted too much, or no enough.—
2. Limit switch adjustingGW-78
3. Limit switch circuit check (passenger side)GW-57
4. Encoder circuit check (passenger side)GW-63
Power window retained power operation does not operate properly1. Check the retained power operation mode
setting.GW-412. Door switch checkGW-67
3. Replace BCM.BCS-15
Does not operate by key cylinder switch1. Door key cylinder switch checkGW-692. Replace power window main switch —
Power window lock switch does not function 1. Power window lock switch checkGW-73
Auto operation does not operate but manual operates normally
(driver side)1. Encoder circuit check (driver side)GW-61
2. Replace power window main switch. —
Auto operation does not operate but manual operates normally
(passenger side)1. Encoder circuit check (passenger side)GW-63
2. Replace front power window switch (passen-
ger side)—
Page 3202 of 4449

POWER WINDOW SYSTEM
GW-43
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Trouble Diagnosis Symptom Chart / With Front and Rear Power Window Anti-
pinch System
AIS004QD
Make sure other systems using the signal of the following systems operate normally.
Symptom Repair order Refer to page
None of the power windows can be operated using any switch.1. BCM power supply and ground circuit checkGW-44
2. Power window main switch power supply and
ground circuit checkGW-45
3. Power window serial link checkGW-71
Driver side power window alone does not operated.1. Front power window motor (driver side) circuit
checkGW-48
2. Replace power window main switch —
Front passenger side power window alone does not operated.1. Front power window switch (passenger side)
power and ground circuit checkGW-46
2. Power window serial link checkGW-71
3. Front power window motor (passenger side)
circuit checkGW-49
4. Replace BCMBCS-15
Rear LH or RH side power window alone does not operated1. Rear power window switch (LH or RH)
power and ground circuit checkGW-472. Power window serial link checkGW-73
3. Rear power window motor (LH or RH) circuit
checkGW-55
4. Replace rear power window switch (LH or RH)EI-35
Anti-pinch system does not operate normally (driver side)1. Door window sliding part malfunction
A foreign material adheres to window glass or
glass run rubber.
Glass run rubber wear or deformation.
Sash is tilted too much, or no enough.—
2. Limit switch adjustingGW-78
3. Limit switch circuit check (driver side)GW-56
4. Encoder circuit check (driver side)GW-61
Anti-pinch system does not operate normally (passenger side)1. Door window sliding part malfunction
A foreign material adheres to window glass or
glass run rubber.
Glass run rubber wear or deformation.
Sash is tilted too much, or no enough.—
2. Limit switch adjustingGW-78
3. Limit switch circuit check (passenger side)GW-57
4. Encoder circuit check (passenger side)GW-63
Anti-pinch system does not operate normally (rear LH or RH)1. Door window sliding part malfunction
A foreign material adheres to window glass or
glass run rubber.
Glass run rubber wear or deformation.
Sash is tilted too much, or no enough.—
2. Limit switch adjustingGW-78
3. Limit switch circuit check (rear LH or RH)GW-59
4. Encoder circuit check (rear LH or RH)GW-65
Page 3203 of 4449
![INFINITI FX35 2004 Service Manual GW-44
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
BCM Power Supply and Ground Circuit CheckAIS004QE
1. CHECK FUSE
Check 15A fuse [No.1, located in fuse block (J/B)]
Check 15A fuse [No INFINITI FX35 2004 Service Manual GW-44
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
BCM Power Supply and Ground Circuit CheckAIS004QE
1. CHECK FUSE
Check 15A fuse [No.1, located in fuse block (J/B)]
Check 15A fuse [No](/manual-img/42/57021/w960_57021-3202.png)
GW-44
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
BCM Power Supply and Ground Circuit CheckAIS004QE
1. CHECK FUSE
Check 15A fuse [No.1, located in fuse block (J/B)]
Check 15A fuse [No.22, located in fuse block (J/B)]
Check 50A fusible link (letter M located in the fuse and fusible link box).
NOTE:
Refer to GW-15, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to
PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between BCM connector M3, M4 terminal 38, 42,
55 and ground.
OK or NG
OK >> GO TO 3.
NG >> Check BCM power supply circuit for open or short.
Power window retained power operation does not operate
properly1. Check the retained power operation mode set-
ting.GW-41
2. Door switch checkGW-67
3. Replace BCM.BCS-15
Does not operate by key cylinder switch1. Door key cylinder switch checkGW-692. Replace power window main switch —
Power window lock switch does not function 1. Power window lock switch checkGW-73
Auto operation does not operate but manual operate normally
(driver side)1. Encoder circuit check (driver side)GW-61
2. Replace power window main switch —
Auto operation does not operate but manual operate normally
(passenger side)1. Encoder circuit check (passenger side)GW-63
2. Replace front power window switch (passen-
ger side)—
Auto operation does not operate but manual operate normally
(rear LH or RH)1. Encoder circuit check (rear LH or RH)GW-65
2. Replace rear power window switch (LH or RH) — Symptom Repair order Refer to page
38 (W/L) – Ground : Battery voltage
42 (L/R) – Ground : Battery voltage
55 (G) – Ground : Battery voltage
PIIA6160E
Page 3204 of 4449

POWER WINDOW SYSTEM
GW-45
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector M4 terminal 49, 52
and ground.
OK or NG
OK >> Power supply and ground circuit are OK.
NG >> Check BCM ground circuit for open or short.
Power Window Main Switch Power Supply Circuit Check AIS004QF
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between power window main switch connector
D6, D7 terminal 10, 19 and ground.
OK or NG
OK >> Power window main switch power supply and ground
circuit are OK.
NG >> GO TO 2.
2. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect power window main switch connector.
3. Check continuity between power window main switch connector
D7 terminal 17 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.49 (B) – Ground : Continuity should exist.
52 (B) – Ground : Continuity should exist.
PIIA6161E
10 (BR) – Ground : Battery voltage
19 (W) – Ground : Battery voltage
PIIA4171E
17 (B) – Ground : Continuity should exist.
PIIA4172E
Page 3205 of 4449

GW-46
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
3. CHECK HARNESS CONTINUITY
1. Disconnect BCM connector.
2. Check continuity between BCM connector M4 terminal 53, 54
and power window main switch connector D6, D7 terminal 10,
19.
3. Check continuity between BCM connector M4 terminal 53, 54
and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Turn ignition switch ON.
3. Check voltage between BCM connector M4 terminal 53, 54 and
ground.
OK or NG
OK >> Check condition of harness and connector.
NG >> Replace BCM.
Front Power Window Switch (Passenger Side) Power Supply and Ground Cir-
cuit Check
AIS004QG
1. CHECK POWER SUPPLY CIRCUIT
Check voltage between front power window switch (passenger side)
connector D36 terminal 10 and ground.
OK or NG
OK >> Front power window switch (passenger side) power sup-
ply and ground circuit are OK.
NG >> GO TO 2.53 (Y/B) – 10 (BR) : Continuity should exist.
54 (W) – 19 (W) : Continuity should exist.
53 (Y/B) – Ground : Continuity should not exist.
54 (W) – Ground : Continuity should not exist.
PIIA6280E
53 (Y/B) – Ground : Battery voltage
54 (W) – Ground : Battery voltage
PIIA6154E
10 (W) – Ground : Battery voltage
PIIA4174E
Page 3206 of 4449

POWER WINDOW SYSTEM
GW-47
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
2. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front power window switch (passenger side) connector.
3. Check continuity between front power window switch (passen-
ger side) connector D36 terminal 11 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK HARNESS CONTINUITY
1. Disconnect BCM connector.
2. Check continuity between BCM connector M4 terminal 54 and
front power window switch (passenger side) connector D36 ter-
minal 10.
3. Check continuity between BCM connector M4 terminal 54 and
ground.
OK or NG
OK >> Check condition of harness and connector.
NG >> Repair or replace harness between BCM and front
power window switch (passenger side).
Rear Power Window Switch (LH or RH) Power Supply and Ground Circuit Check
/ With Front and Rear Power Window Anti-pinch System
AIS004QH
1. CHECK POWER SUPPLY
Check voltage between front power window switch (LH or RH) con-
nector D58 (LH), D78 (RH) terminal 10 and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.11 (B) – Ground : Continuity should exist.
PIIA4175E
54 (W) – 10 (W) : Continuity should exist.
54 (W) – Ground : Continuity should not exist.
PIIA6281E
10 (W) – Ground : Battery voltage
PIIA6293E
Page 3207 of 4449

GW-48
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
2. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power window switch (LH or RH) connector.
3. Check continuity between rear power window switch (LH or RH)
connector D58 (LH), D78 (RH) terminal 11 and ground.
OK or NG
OK >> Rear power window switch (LH or RH) power supply
and ground circuit are OK. Refer to symptom chart.
NG >> Repair or replace harness.
3. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and rear power window switch (LH or RH) connector.
3. Check continuity between BCM connector M4 terminal 54 and
rear power window switch (LH or RH) connector D58 (LH), D78
(RH) terminal 10.
4. Check continuity between BCM connector M4 terminal 54 and
ground.
OK or NG
OK >> Check condition of harness and connector.
NG >> Repair or replace harness.
Front Power Window Motor (Driver Side) Circuit CheckAIS004QI
1. CHECK POWER WINDOW MAIN SWITCH OUTPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between power window main switch connector
and ground.
OK or NG
OK >> GO TO 2.
NG >> Replace power window main switch.11 (B) – Ground : Continuity should exist.
PIIA6294E
54 (W) – 10 (W) : Continuity should exist.
54 (W) – Ground : Continuity should not exist.
PIIA6295E
ConnectorTerminals (Wire color)
Window conditionVoltage [V]
(Approx.)
(+) (-)
D68 (L)
GroundUP Battery voltage
DOWN 0
11 ( B )UP 0
DOWN Battery voltage
PIIA4179E
Page 3208 of 4449

POWER WINDOW SYSTEM
GW-49
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect power window main switch and front power window motor (driver side) connector.
3. Check continuity between power window main switch connector
D6 terminal 8, 11 and front power window motor (driver side)
connector D8 terminal 1, 2.
OK or NG
OK >> Replace front power window motor (driver side).
NG >> Repair or replace harness between power window main
switch and front power window motor (driver side).
Front Power Window Motor (Passenger Side) Circuit CheckAIS004QJ
1. CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) OUTPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between front power window switch (passenger
side) connector and ground.
OK or NG
OK >> GO TO 2.
NG >> Replace front power window switch (passenger side).
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect front power window switch (passenger side) and front power window motor (passenger side)
connector.
3. Check continuity between front power window switch (passen-
ger side) connector D36 terminals 8, 9 and front power window
motor (passenger side) connector D38 terminals 1, 2.
OK or NG
OK >> Replace front power window motor (passenger side).
NG >> Repair or replace harness between front power window
switch (passenger side) and front power window motor
(passenger side). 8 (L) – 2 (L) : Continuity should exist.
11 (B) – 1 (B) : Continuity should exist.
PIIA9956E
ConnectorTerminals (Wire color)
Window conditionVoltage [V]
(Approx.)
(+) (-)
D368 (L)
GroundUP Battery voltage
DOWN 0
9 (G)UP 0
DOWN Battery voltage
PIIA4182E
8 (L) – 2 (L) : Continuity should exist.
9 (G) – 1 (G) : Continuity should exist.
PIIA9957E
