Page 3233 of 4449

INFINITI FX35 2004 Service Manual GW-74
SIDE WINDOW GLASS
Revision: 2004 November 2004 FX35/FX45
SIDE WINDOW GLASSPFP:83300
Removal and InstallationAIS003A5
REMOVAL
1. Remove the roof rear garnish. Refer toEI-44, "Removal and Installa

Page 3234 of 4449

INFINITI FX35 2004 Service Manual SIDE WINDOW GLASS
GW-75
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
INSTALLATION
Use a genuine Nissan Urethane Adhesive Kit or equivalent and follow the instructions furnished wi

SIDE WINDOW GLASS
GW-75
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
INSTALLATION
Use a genuine Nissan Urethane Adhesive Kit or equivalent and follow the instructions furnished with it.
While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced
out by passenger room air pressure when a door is closed.
The molding must be installed securely so that it is in position and leaves no gap.
Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNING:
Keep heat and open flames away as primers and adhesive are flammable.
The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid
contact with the skin and eyes.
Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if
inhaled. If affected by vapor inhalation, immediately move to an area with fresh air.
Driving the vehicle before the urethane adhesive has completely cured may affect the perfor-
mance of the side window in case of an accident.
CAUTION:
Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six
months after the date of manufacture. Carefully adhere to the expiration or manufacture date
printed on the box.
Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
Do not leave primers or adhesive cartridge unattended with their caps open or off.
The vehicle should not be driven for at least 24 hours or until the urethane adhesive has com-
pletely cured. Curing time varies depending on temperature and humidity. The curing time will
increase under lower temperature and lower humidity.
Repairing Water Leaks
Leaks can be repaired without removing and reinstalling glass.
If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.
This can be done by applying water to the side window area while pushing glass outward.
To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.

Page 3235 of 4449

INFINITI FX35 2004 Service Manual GW-76
FRONT DOOR GLASS AND REGULATOR
Revision: 2004 November 2004 FX35/FX45
FRONT DOOR GLASS AND REGULATORPFP:80300
Removal and InstallationAIS006NU
DOOR GLASS
Removal
1. Remove the front door finishe

Page 3236 of 4449

INFINITI FX35 2004 Service Manual FRONT DOOR GLASS AND REGULATOR
GW-77
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
6. While holding the door glass, raise it at the rear end to pull the
glass out of the sash toward

Page 3237 of 4449

INFINITI FX35 2004 Service Manual GW-78
FRONT DOOR GLASS AND REGULATOR
Revision: 2004 November 2004 FX35/FX45
Inspection after Removal
Check the regulator assembly for the following. If a malfunction is
detected, replace or grease it.

Page 3238 of 4449

INFINITI FX35 2004 Service Manual FRONT DOOR GLASS AND REGULATOR
GW-79
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Lower the glass slightly [approx. 10 to 20 mm (0.39 to 0.79 in)] and make sure the clearance to t

Page 3239 of 4449

INFINITI FX35 2004 Service Manual GW-80
REAR DOOR GLASS AND REGULATOR
Revision: 2004 November 2004 FX35/FX45
REAR DOOR GLASS AND REGULATORPFP:82300
Removal and InstallationAIS006NX
DOOR GLASS
Removal
1. Remove the rear door finisher.

Page 3240 of 4449

INFINITI FX35 2004 Service Manual REAR DOOR GLASS AND REGULATOR
GW-81
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
7. Operate the power window switch to raise/lower the door win-
dow until the glass mounting bolts
