Page 2713 of 4449

INFINITI FX35 2004 Service Manual EI-34 ROOF RAIL Revision: 2004 November 2004 FX35/FX45 ROOF RAILPFP:73820 Removal and InstallationAIS0037K REMOVAL 1. Remove cover roof rail (front/rear). 2. Remove nuts of roof rail and remove roof r

Page 2714 of 4449

INFINITI FX35 2004 Service Manual DOOR FINISHER EI-35 C D E F G H J K L MA B EI Revision: 2004 November 2004 FX35/FX45 DOOR FINISHERPFP:80900 Removal and InstallationAIS003BT DOOR FINISHER (FRONT AND REAR) Removal 1. Remove door finis

Page 2715 of 4449

INFINITI FX35 2004 Service Manual EI-36 DOOR FINISHER Revision: 2004 November 2004 FX35/FX45 5. Remove lock knob cable, inside handle cable and illumination harness connector (front door only) from backside of inside han- dle assembly

Page 2716 of 4449

INFINITI FX35 2004 Service Manual BODY SIDE TRIM EI-37 C D E F G H J K L MA B EI Revision: 2004 November 2004 FX35/FX45 BODY SIDE TRIMPFP:76913 Removal and InstallationAIS0037N CAUTION: Wrap the tip of flat-bladed screwdriver with a c

Page 2717 of 4449

INFINITI FX35 2004 Service Manual EI-38 BODY SIDE TRIM Revision: 2004 November 2004 FX35/FX45 3. Remove center pillar lower garnish. NOTE: Insert screwdriver rolled with cloth between panel on vehicle and clips, then disconnect clips.

Page 2718 of 4449

INFINITI FX35 2004 Service Manual BODY SIDE TRIM EI-39 C D E F G H J K L MA B EI Revision: 2004 November 2004 FX35/FX45 FRONT PILLAR GARNISH Removal Remove front pillar garnish clips and remove front pillar garnish. Installation Insta

Page 2719 of 4449

INFINITI FX35 2004 Service Manual EI-40 FLOOR TRIM Revision: 2004 November 2004 FX35/FX45 FLOOR TRIMPFP:74902 Removal and InstallationAIS0037O REMOVAL 1. Remove front seat and rear seat cushion. Refer to SE-101, "Removal and Installat

Page 2720 of 4449

INFINITI FX35 2004 Service Manual FLOOR TRIM EI-41 C D E F G H J K L MA B EI Revision: 2004 November 2004 FX35/FX45 11. Remove floor carpet from carpet fixing clip and remove floor car- pet. INSTALLATION Install in the reverse order o
