INFINITI FX35 2004 Service Manual CO-20 [VQ35DE] RADIATOR (ALUMINUM TYPE) Revision: 2004 November 2004 FX35/FX45 Use pliers in the locations where plate pliers A cannot be used. 5. Make sure that the rim is completely crimped down. 6

Page 1210 of 4449

INFINITI FX35 2004 Service Manual COOLING FAN CO-21 [VQ35DE] C D E F G H I J K L MA CO Revision: 2004 November 2004 FX35/FX45 COOLING FANPFP:21140 Removal and Installation ABS005GR REMOVAL 1. Remove air duct (inlet), power duct and ai

Page 1211 of 4449

INFINITI FX35 2004 Service Manual CO-22 [VQ35DE] WATER PUMP Revision: 2004 November 2004 FX35/FX45 WATE R P U M PPFP:21020 Removal and InstallationABS009RE CAUTION: When removing water pump, be careful not to get engine coolant on d

Page 1212 of 4449

INFINITI FX35 2004 Service Manual WATER PUMP CO-23 [VQ35DE] C D E F G H I J K L MA CO Revision: 2004 November 2004 FX35/FX45 7. Remove timing chain tensioner (primary) with the following pro- cedure. a. Pull the lever down and release

Page 1213 of 4449

INFINITI FX35 2004 Service Manual CO-24 [VQ35DE] WATER PUMP Revision: 2004 November 2004 FX35/FX45 9. Screw M8 bolts [pitch: 1.25 mm (0.049 in) length: approx. 50 mm (1.97 in)] into water pumps upper and lower mounting bolt holes unti

Page 1214 of 4449

INFINITI FX35 2004 Service Manual WATER PUMP CO-25 [VQ35DE] C D E F G H I J K L MA CO Revision: 2004 November 2004 FX35/FX45 c. Install timing chain tensioner (primary). d. Remove stopper pin. 4. Install chain tensioner cover and wate

Page 1215 of 4449

INFINITI FX35 2004 Service Manual CO-26 [VQ35DE] WATER INLET AND THERMOSTAT ASSEMBLY Revision: 2004 November 2004 FX35/FX45 WATER INLET AND THERMOSTAT ASSEMBLYPFP:21200 Removal and InstallationABS009RF REMOVAL 1. Remove front engine u

Page 1216 of 4449

INFINITI FX35 2004 Service Manual WATER INLET AND THERMOSTAT ASSEMBLY CO-27 [VQ35DE] C D E F G H I J K L MA CO Revision: 2004 November 2004 FX35/FX45 INSPECTION AFTER REMOVAL 1. Check valve seating condition at ordinary room temperatu
