INFINITI FX35 2004 Service Manual LAN-76 [CAN] CAN SYSTEM (TYPE 2) Revision: 2004 November 2004 FX35/FX45 Circuit Check Between ABS Actuator and Electric Unit (Control Unit) and Driver Seat Control Unit AKS00BZX 1. CHECK CONNECTOR 1.

Page 3378 of 4449

INFINITI FX35 2004 Service Manual CAN SYSTEM (TYPE 2) LAN-77 [CAN] C D E F G H I J L MA B LAN Revision: 2004 November 2004 FX35/FX45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect ECM connector. 2. Check resistance between ECM harnes

Page 3379 of 4449

INFINITI FX35 2004 Service Manual LAN-78 [CAN] CAN SYSTEM (TYPE 2) Revision: 2004 November 2004 FX35/FX45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect display unit connector. 2. Check resistance between display unit harness connect

Page 3380 of 4449

INFINITI FX35 2004 Service Manual CAN SYSTEM (TYPE 2) LAN-79 [CAN] C D E F G H I J L MA B LAN Revision: 2004 November 2004 FX35/FX45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect BCM connector. 2. Check resistance between BCM harnes

Page 3381 of 4449

INFINITI FX35 2004 Service Manual LAN-80 [CAN] CAN SYSTEM (TYPE 2) Revision: 2004 November 2004 FX35/FX45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect unified meter and A/C amp. connector. 2. Check resistance between unified meter

Page 3382 of 4449

INFINITI FX35 2004 Service Manual CAN SYSTEM (TYPE 2) LAN-81 [CAN] C D E F G H I J L MA B LAN Revision: 2004 November 2004 FX35/FX45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect driver seat control unit connector. 2. Check resistan

Page 3383 of 4449

INFINITI FX35 2004 Service Manual LAN-82 [CAN] CAN SYSTEM (TYPE 2) Revision: 2004 November 2004 FX35/FX45 CAN Communication Circuit CheckAKS00C08 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the negative battery termi

Page 3384 of 4449

INFINITI FX35 2004 Service Manual CAN SYSTEM (TYPE 2) LAN-83 [CAN] C D E F G H I J L MA B LAN Revision: 2004 November 2004 FX35/FX45 3. CHECK HARNESS FOR SHORT CIRCUIT Check continuity between data link connector M5 terminals 6 (L), 1
