EC-20
[VQ35DE]
INDEX FOR DTC
Revision: 2004 November 2004 FX35/FX45
P0159 0159 HO2S2 (B2) 2×EC-245
P0171 0171 FUEL SYS-LEAN-B1 2×EC-256
P0172 0172 FUEL SYS-RICH-B1 2×EC-265
P0174 0174 FUEL SYS-LEAN-B2 2×EC-256
P0175 0175 FUEL SYS-RICH-B2 2×EC-265
P0181 0181 FTT SENSOR 2×EC-273
P0182 0182 FTT SEN/CIRCUIT 2×EC-279
P0183 0183 FTT SEN/CIRCUIT 2×EC-279
P0222 0222 TP SEN 1/CIRC 1×EC-284
P0223 0223 TP SEN 1/CIRC 1×EC-284
P0300 0300 MULTI CYL MISFIRE 2×EC-291
P0301 0301 CYL 1 MISFIRE 2×EC-291
P0302 0302 CYL 2 MISFIRE 2×EC-291
P0303 0303 CYL 3 MISFIRE 2×EC-291
P0304 0304 CYL 4 MISFIRE 2×EC-291
P0305 0305 CYL 5 MISFIRE 2×EC-291
P0306 0306 CYL 6 MISFIRE 2×EC-291
P0327 0327 KNOCK SEN/CIRC-B1 2 —EC-297
P0328 0328 KNOCK SEN/CIRC-B1 2 —EC-297
P0335 0335 CKP SEN/CIRCUIT 2×EC-302
P0340 0340 CMP SEN/CIRC-B1 2×EC-308
P0345 0345 CMP SEN/CIRC-B2 2×EC-308
P0420 0420 TW CATALYST SYS-B1 2×EC-316
P0430 0430 TW CATALYST SYS-B2 2×EC-316
P0441 0441 EVAP PURG FLOW/MON 2×EC-321
P0442 0442 EVAP SMALL LEAK 2×EC-326
P0444 0444 PURG VOLUME CONT/V 2×EC-335
P0445 0445 PURG VOLUME CONT/V 2×EC-335
P0447 0447 VENT CONTROL VALVE 2×EC-342
P0451 0451 EVAP SYS PRES SEN 2×EC-349
P0452 0452 EVAP SYS PRES SEN 2×EC-352
P0453 0453 EVAP SYS PRES SEN 2×EC-358
P0455 0455 EVAP GROSS LEAK 2×EC-366
P0456 0456 EVAP VERY SML LEAK 2×EC-374
P0460 0460 FUEL LEV SEN SLOSH 2×EC-384
P0461 0461 FUEL LEVEL SENSOR 2×EC-386
P0462 0462 FUEL LEVL SEN/CIRC 2×EC-388
P0463 0463 FUEL LEVL SEN/CIRC 2×EC-388
P0500 0500
VEH SPEED SEN/CIRC*62×EC-390
P0506 0506 ISC SYSTEM 2×EC-392
P0507 0507 ISC SYSTEM 2×EC-394
P0550 0550 PW ST P SEN/CIRC 2 —EC-396
DTC*1
Items
(CONSULT-II screen terms)TripMIL lighting
upReference page
CONSULT-II
GST*
2ECM*3
Page 1362 of 4449
![INFINITI FX35 2004 Service Manual INDEX FOR DTC
EC-21
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45P0605 0605 ECM 1 or 2× or —EC-401
P0705 0705 PNP SW/CIRC 2×AT- 11 2
P0710 0710 ATF TEMP SEN/CIRC 2×AT- INFINITI FX35 2004 Service Manual INDEX FOR DTC
EC-21
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45P0605 0605 ECM 1 or 2× or —EC-401
P0705 0705 PNP SW/CIRC 2×AT- 11 2
P0710 0710 ATF TEMP SEN/CIRC 2×AT-](/manual-img/42/57021/w960_57021-1361.png)
INDEX FOR DTC
EC-21
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45P0605 0605 ECM 1 or 2× or —EC-401
P0705 0705 PNP SW/CIRC 2×AT- 11 2
P0710 0710 ATF TEMP SEN/CIRC 2×AT- 1 3 9
P0720 0720
VEH SPD SEN/CIR AT*62×AT- 11 6
P0725 0725 ENGINE SPEED SIG 2×AT- 1 2 1
P0740 0740 TCC SOLENOID/CIRC 2×AT- 1 2 3
P0744 0744 A/T TCC S/V FNCTN 2×AT- 1 2 5
P0745 0745 L/PRESS SOL/CIRC 2×AT- 1 2 7
P1065 1065 ECM BACK UP/CIRCUIT 2×EC-404
P 1111 1111 I N T / V T I M V / C I R - B 1 2×EC-408
P1121 1121 ETC ACTR 1×EC-415
P1122 1122 ETC FUNCTION/CIRC 1×EC-417
P1124 1124 ETC MOT PWR 1×EC-423
P1126 1126 ETC MOT PWR 1×EC-423
P1128 1128 ETC MOT 1×EC-428
P1136 1136 INT/V TIM V/CIR-B2 2×EC-408
P1143 1143 HO2S1 (B1) 2×EC-433
P1144 1144 HO2S1 (B1) 2×EC-439
P1146 1146 HO2S2 (B1) 2×EC-446
P1147 1147 HO2S2 (B1) 2×EC-457
P1148 1148 CLOSED LOOP-B1 1×EC-468
P1163 1163 HO2S1 (B2) 2×EC-433
P1164 1164 HO2S1 (B2) 2×EC-439
P1166 1166 HO2S2 (B2) 2×EC-446
P1167 1167 HO2S2 (B2) 2×EC-457
P1168 1168 CLOSED LOOP-B2 1×EC-468
P1211 1211 TCS C/U FUNCTN 2 —EC-470
P1212 1212 TCS/CIRC 2 —EC-471
P1217 1217 ENG OVER TEMP 1×EC-472
P1225 1225 CTP LEARNING 2 —EC-485
P1226 1226 CTP LEARNING 2 —EC-487
P1229 1229 SENSOR POWER/CIRC 1×EC-489
P1444 1444 PURG VOLUME CONT/V 2×EC-494
P1446 1446 VENT CONTROL VALVE 2×EC-502
P1564 1564
ASCD SW*71—EC-508, EC-515
P1568 1568
ACC COMMAND VALUE*81—EC-521
P1572 1572
ASCD BRAKE SW*71—EC-522, EC-532
P1574 1574
ASCD VHL SPD SEN*71—EC-541, EC-543
P1610 - P1615 1610 - 1615 NATS MALFUNCTION 2 —EC-68
P1705 1705 TP SEN/CIRC A/T 1×AT- 1 3 6
P1706 1706 P-N POS SW/CIRCUIT 2×EC-545
P1716 1716 TURBINE REV S/CIRC 2×AT- 1 4 3
DTC*1
Items
(CONSULT-II screen terms)TripMIL lighting
upReference page
CONSULT-II
GST*
2ECM*3
Page 1363 of 4449
![INFINITI FX35 2004 Service Manual EC-22
[VQ35DE]
INDEX FOR DTC
Revision: 2004 November 2004 FX35/FX45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnos INFINITI FX35 2004 Service Manual EC-22
[VQ35DE]
INDEX FOR DTC
Revision: 2004 November 2004 FX35/FX45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnos](/manual-img/42/57021/w960_57021-1362.png)
EC-22
[VQ35DE]
INDEX FOR DTC
Revision: 2004 November 2004 FX35/FX45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: When engine is running.
*5: The troubleshooting for this DTC needs CONSULT-II.
*6: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*7: For models with ICC or ASCD system.
*8: For models with ICC system.P1730 1730 A/T INTERLOCK 1×AT-147
P1752 1752 I/C SOLENOID/CIRC 1×AT-152
P1754 1754 I/C SOLENOID FNCTN 1×AT-154
P1757 1757 FR/B SOLENOID/CIRC 1×AT-156
P1759 1759 FR/B SOLENOID FNCT 1×AT-158
P1762 1762 D/C SOLENOID/CIRC 1×AT-160
P1764 1764 D/C SOLENOID FNCTN 1×AT-162
P1767 1767 HLR/C SOL/CIRC 1×AT-164
P1769 1769 HLR/C SOL FNCTN 1×AT-166
P1772 1772 LC/B SOLENOID/CIRC 1×AT-168
P1774 1774 LC/B SOLENOID FNCT 1×AT-170
P1805 1805 BRAKE SW/CIRCUIT 2 —EC-550
P2122 2122 APP SEN 1/CIRC 1×EC-555
P2123 2123 APP SEN 1/CIRC 1×EC-555
P2127 2127 APP SEN 2/CIRC 1×EC-562
P2128 2128 APP SEN 2/CIRC 1×EC-562
P2135 2135 TP SENSOR 1×EC-569
P2138 2138 APP SENSOR 1×EC-576
DTC*1
Items
(CONSULT-II screen terms)TripMIL lighting
upReference page
CONSULT-II
GST*
2ECM*3
Page 1364 of 4449
![INFINITI FX35 2004 Service Manual PRECAUTIONS
EC-23
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE INFINITI FX35 2004 Service Manual PRECAUTIONS
EC-23
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE](/manual-img/42/57021/w960_57021-1363.png)
PRECAUTIONS
EC-23
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
ABS00A2R
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
On Board Diagnostic (OBD) System of Engine and A/TABS006JZ
The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:
Be sure to turn the ignition switch OFF and disconnect the negative battery cable before any
repair or inspection work. The open/short circuit of related switches, sensors, solenoid valves,
etc. will cause the MIL to light up.
Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MIL to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
Certain systems and components, especially those related to OBD, may use a new style slide-
locking type harness connector. For description and how to disconnect, refer to PG-74, "
HAR-
NESS CONNECTOR" .
Be sure to route and secure the harnesses properly after work. The interference of the harness
with a bracket, etc. may cause the MIL to light up due to the short circuit.
Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to the malfunction of the EVAP system or fuel injection system,
etc.
Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM and
TCM (Transmission control module) before returning the vehicle to the customer.
PrecautionABS006K0
Always use a 12 volt battery as power source.
Do not attempt to disconnect battery cables while engine is
running.
Before connecting or disconnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect negative
battery cable. Failure to do so may damage the ECM
because battery voltage is applied to ECM even if ignition
switch is turned OFF.
Before removing parts, turn ignition switch OFF and then
disconnect negative battery cable.
SEF289H
Page 1365 of 4449
![INFINITI FX35 2004 Service Manual EC-24
[VQ35DE]
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Do not disassemble ECM.
If a battery cable is disconnected, the memory will return to
the ECM value.
The ECM will now start to self- INFINITI FX35 2004 Service Manual EC-24
[VQ35DE]
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Do not disassemble ECM.
If a battery cable is disconnected, the memory will return to
the ECM value.
The ECM will now start to self-](/manual-img/42/57021/w960_57021-1364.png)
EC-24
[VQ35DE]
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Do not disassemble ECM.
If a battery cable is disconnected, the memory will return to
the ECM value.
The ECM will now start to self-control at its initial value.
Engine operation can vary slightly when the terminal is dis-
connected. However, this is not an indication of a malfunc-
tion. Do not replace parts because of a slight variation.
When connecting ECM harness connector, fasten it
securely with a lever as far as it will go as shown in the fig-
ure.
When connecting or disconnecting pin connectors into or
from ECM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on ECM
pin terminal, when connecting pin connectors.
Securely connect ECM harness connectors.
A poor connection can cause an extremely high (surge)
voltage to develop in coil and condenser, thus resulting in
damage to ICs.
Keep engine control system harness at least 10 cm (4 in)
away from adjacent harness, to prevent engine control sys-
tem malfunctions due to receiving external noise, degraded
operation of ICs, etc.
Keep engine control system parts and harness dry.
Before replacing ECM, perform “ECM Terminals and Refer-
ence Value” inspection and make sure ECM functions prop-
erly. Refer to EC-100
.
Handle mass air flow sensor carefully to avoid damage.
Do not disassemble mass air flow sensor.
Do not clean mass air flow sensor with any type of deter-
gent.
Do not disassemble electric throttle control actuator.
Even a slight leak in the air intake system can cause seri-
ous incidents.
Do not shock or jar the camshaft position sensor (PHASE),
crankshaft position sensor (POS).
PBIB1164E
PBIB1512E
PBIB0090E
MEF040D
Page 1366 of 4449
PRECAUTIONS
EC-25
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45
After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.
When measuring ECM signals with a circuit tester, never
allow the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.
Do not use ECM ground terminals when measuring input/
output voltage. Doing so may result in damage to the ECM's
transistor. Use a ground other than ECM terminals, such as
the ground.
B1 indicates the bank 1, B2 indicates the bank 2 as shown
in the figure.
SEF217U
SEF348N
SEC893C
Page 1367 of 4449
![INFINITI FX35 2004 Service Manual EC-26
[VQ35DE]
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Do not operate fuel pump when there is no fuel in lines.
Tighten fuel hose clamps to the specified torque.
Do not depress accelerat INFINITI FX35 2004 Service Manual EC-26
[VQ35DE]
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Do not operate fuel pump when there is no fuel in lines.
Tighten fuel hose clamps to the specified torque.
Do not depress accelerat](/manual-img/42/57021/w960_57021-1366.png)
EC-26
[VQ35DE]
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Do not operate fuel pump when there is no fuel in lines.
Tighten fuel hose clamps to the specified torque.
Do not depress accelerator pedal when starting.
Immediately after starting, do not rev up engine unneces-
sarily.
Do not rev up engine just prior to shutdown.
When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–Keep the antenna as far as possible from the electronic
control units.
–Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–Adjust the antenna and feeder line so that the standing-
wave radio can be kept smaller.
–Be sure to ground the radio to vehicle body.
Wiring Diagrams and Trouble DiagnosisABS006K1
When you read wiring diagrams, refer to the following:
GI-15, "How to Read Wiring Diagrams"
PG-3, "POWER SUPPLY ROUTING CIRCUIT" for power distribution circuit
When you perform trouble diagnosis, refer to the following:
GI-11, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES"
GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident"
PBIB1569E
SEF709Y
SEF708Y
Page 1368 of 4449
![INFINITI FX35 2004 Service Manual PREPARATION
EC-27
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsABS006K2
The actual shapes of Kent-Moore tools may differ from tho INFINITI FX35 2004 Service Manual PREPARATION
EC-27
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsABS006K2
The actual shapes of Kent-Moore tools may differ from tho](/manual-img/42/57021/w960_57021-1367.png)
PREPARATION
EC-27
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsABS006K2
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
EG17650301
(J-33984-A)
Radiator cap tester
adapterAdapting radiator cap tester to radiator cap and
radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV10117100
(J-36471-A)
Heated oxygen
sensor wrenchLoosening or tightening heated oxygen sensors
with 22 mm (0.87 in) hexagon nut
KV10114400
(J-38365)
Heated oxygen
sensor wrenchLoosening or tightening heated oxygen sensors
a: 22 mm (0.87 in)
(J-44321)
Fuel pressure gauge
kitChecking fuel pressure
KV109E0010
(J-46209)
Break-out boxMeasuring the ECM signals with a circuit tester
KV109E0080
(J-45819)
Y-cable adapterMeasuring the ECM signals with a circuit tester
S-NT564
S-NT379
S-NT636
LEC642
S-NT825
S-NT826
