EM-20
[VQ35DE]
INTAKE MANIFOLD COLLECTOR
Revision: 2004 November 2004 FX35/FX45
1. Remove engine cover with power tool.
2. Disconnect water hoses from intake manifold collector (upper), attach blind plug to prevent engine coolant
leakage.
CAUTION:
Perform this step when engine is cold.
Do not spill engine coolant on drive belts.
3. Remove air cleaner case and air duct. Refer to EM-17, "
AIR CLEANER AND AIR DUCT" .
4. Remove electric throttle control actuator as the following:
a. Disconnect harness connector.
b. Loosen bolts in reverse order as shown in the figure.
CAUTION:
Handle carefully to avoid any shock to electric throttle
control actuator.
Do not disassemble.
5. Remove fuel sub-tube mounting bolt to disconnect from rear of intake manifold collector (lower). Refer to
EM-45, "
FUEL INJECTOR AND FUEL TUBE" .
6. Disconnect vacuum hose and water hose from intake manifold collector (upper).
7. Remove EVAP canister purge volume control solenoid valve bracket mounting bolt from intake manifold
collector (upper).
SBIA0486E
KBIA0957E
Page 2746 of 4449
INTAKE MANIFOLD COLLECTOR
EM-21
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2004 November 2004 FX35/FX45
8. Loosen bolts in reverse order as shown in the figure to remove
intake manifold collector (upper) with power tool.
9. Remove PCV hose [between intake manifold collector and rocker cover (right bank)].
10. Loosen bolts in reverse order as shown in the figure, and
remove intake manifold collector cover, gasket, intake manifold
collector (lower) and gasket with power tool.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
INSPECTION AFTER REMOVAL
Surface Distortion
Check the surface distortion of both the intake manifold collector
(upper and lower) mating surfaces with straightedge and feeler
gauge.
If it exceeds the limit, replace intake manifold collector (upper
and/or lower).
PBIC0773E
PBIC0774E
Limit : 0.1 mm (0.004 in)
PBIC0775E
Page 2747 of 4449
![INFINITI FX35 2004 Service Manual EM-22
[VQ35DE]
INTAKE MANIFOLD COLLECTOR
Revision: 2004 November 2004 FX35/FX45
INSTALLATION
Note to the following, and install in the reverse order of removal.
Part Installation Direction
Referring t INFINITI FX35 2004 Service Manual EM-22
[VQ35DE]
INTAKE MANIFOLD COLLECTOR
Revision: 2004 November 2004 FX35/FX45
INSTALLATION
Note to the following, and install in the reverse order of removal.
Part Installation Direction
Referring t](/manual-img/42/57021/w960_57021-2746.png)
EM-22
[VQ35DE]
INTAKE MANIFOLD COLLECTOR
Revision: 2004 November 2004 FX35/FX45
INSTALLATION
Note to the following, and install in the reverse order of removal.
Part Installation Direction
Referring to front marks, install parts shown in figure.
Intake Manifold Collector (Lower)
Tighten in numerical order as shown in the figure.
NOTE:
Tighten mounting bolts to secure gasket (lower), intake manifold col-
lector (lower), gasket (upper), and intake manifold collector cover.
Intake Manifold Collector (Upper)
If stud bolts were removed, install them and tighten to the speci-
fied torque below.
Shank length under bolt head varies with bolt location. Install
bolts while referring to numbers shown below and in figure. (Bolt
length does not include pilot portion.)
Tighten in numerical order as shown in the figure.
Water Hose
Insert hose by 27 to 32 mm (1.06 to 1.26 in) from connector end.
PBIC0776E
PBIC0774E
: 5.9 N·m (0.6 kg-m, 52 in-lb)
Bolt
M6 × 25 mm (0.98 in) : 7, 8, 10, 11, 13, 14, 15, 16, 18
M6 × 45 mm (1.77 in) : 2, 4, 5
M6 × 60 mm (2.36 in) : 1, 3, 6, 9
M6 Nut : 12, 17
PBIC0773E
Page 2748 of 4449
INTAKE MANIFOLD COLLECTOR
EM-23
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2004 November 2004 FX35/FX45
Clamp hose at location of 3 to 7 mm (0.12 to 0.28 in) from hose end.
Electric Throttle Control Actuator
Install gasket with three protrusions for installation check facing any direction other than upward.
Tighten in numerical order as shown in the figure.
Perform the “Throttle Valve Closed Position Learning” when har-
ness connector of electric throttle control actuator is discon-
nected. Refer to EC-49, "
Throttle Valve Closed Position
Learning" .
Perform the “Idle Air Volume Learning” and “Throttle Valve
Closed Position Learning” when electric throttle control actuator
is replaced. Refer to EC-49, "
Idle Air Volume Learning" .
KBIA0957E
Page 2749 of 4449
EM-24
[VQ35DE]
INTAKE MANIFOLD
Revision: 2004 November 2004 FX35/FX45
INTAKE MANIFOLDPFP:14003
Removal and InstallationABS004U3
REMOVAL
1. Release fuel pressure. Refer to EC-51, "FUEL PRESSURE RELEASE" .
2. Remove intake manifold collector (upper and lower). Refer to EM-19, "
INTAKE MANIFOLD COLLECTOR"
.
3. Remove fuel tube and fuel injector assembly. Refer to EM-45, "
FUEL INJECTOR AND FUEL TUBE" .
4. Loosen bolts and nuts in reverse order of illustration to remove
intake manifold with power tool.
5. Remove intake manifold gaskets.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
INSPECTION AFTER REMOVAL
Surface Distortion
Check the surface distortion of the intake manifold mating sur-
face with straightedge and feeler gauge.
If it exceeds the limit, replace intake manifold.
1. Harness bracket 2. Intake manifold 3. Gasket
SBIA0487E
PBIC0778E
Limit : 0.1 mm (0.04 in)
PBIC0870E
Page 2750 of 4449
INTAKE MANIFOLD
EM-25
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2004 November 2004 FX35/FX45
INSTALLATION
Note to the following, and install in the reverse order of removal.
Intake Manifold
If stud bolts were removed, install them and tighten to the specified torque below.
Tighten all mounting bolts and nuts to the specified torque in two
or more steps in numerical order shown in the figure. : 10.8 N·m (1.1 kg-m, 8 ft-lb)
1st step:
: 7.4 N·m (0.75 kg-m, 5 ft-lb)
2nd step and after:
: 29.0 N·m (3.0 kg-m, 21 ft-lb)
PBIC0778E
Page 2751 of 4449
![INFINITI FX35 2004 Service Manual EM-26
[VQ35DE]
EXHAUST MANIFOLD AND THREE WAY CATALYST
Revision: 2004 November 2004 FX35/FX45
EXHAUST MANIFOLD AND THREE WAY CATALYSTPFP:14004
Removal and InstallationABS004U4
REMOVAL
WARNING:
Perform INFINITI FX35 2004 Service Manual EM-26
[VQ35DE]
EXHAUST MANIFOLD AND THREE WAY CATALYST
Revision: 2004 November 2004 FX35/FX45
EXHAUST MANIFOLD AND THREE WAY CATALYSTPFP:14004
Removal and InstallationABS004U4
REMOVAL
WARNING:
Perform](/manual-img/42/57021/w960_57021-2750.png)
EM-26
[VQ35DE]
EXHAUST MANIFOLD AND THREE WAY CATALYST
Revision: 2004 November 2004 FX35/FX45
EXHAUST MANIFOLD AND THREE WAY CATALYSTPFP:14004
Removal and InstallationABS004U4
REMOVAL
WARNING:
Perform the work when the exhaust and cooling system have completely cooled down.
1. Remove engine cover with power tool. Refer to EM-19, "
INTAKE MANIFOLD COLLECTOR" .
2. Remove air cleaner case and air duct. Refer to EM-17, "
AIR CLEANER AND AIR DUCT" .
3. Remove front and rear engine undercover and front cross bar with power tool.
4. Disconnect heated oxygen sensors 2 (bank 1 and bank 2) harness connectors.
5. Using heated oxygen sensor wrench (SST), remove heated oxy-
gen sensors 2 (bank 1 and bank 2).
CAUTION:
Be careful not to damage heated oxygen sensor.
Discard any heated oxygen sensor which has been
dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; replace with a new
sensor.
1. Heated oxygen sensor 2 (bank 1) 2. Three way catalyst (right bank) 3. Gasket
4. heated oxygen sensor 1 (bank 1) 5. Exhaust manifold cover (right bank) 6. Exhaust manifold (right bank)
7. Exhaust manifold (left bank) 8. Exhaust manifold cover (left bank) 9. Three way catalyst (left bank)
10. heated oxygen sensor 1 (bank 2) 11. Heated oxygen sensor 2 (bank 2)
SBIA0583E
KBIA1740E
Page 2752 of 4449
![INFINITI FX35 2004 Service Manual EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-27
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2004 November 2004 FX35/FX45
6. Remove exhaust mounting bracket between right/left catalytic converter and tr INFINITI FX35 2004 Service Manual EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-27
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2004 November 2004 FX35/FX45
6. Remove exhaust mounting bracket between right/left catalytic converter and tr](/manual-img/42/57021/w960_57021-2751.png)
EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-27
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2004 November 2004 FX35/FX45
6. Remove exhaust mounting bracket between right/left catalytic converter and transmission. Refer to EX-3,
"EXHAUST SYSTEM" .
7. Remove three way catalyst (right and left bank).
8. Disconnect heated oxygen sensor 1 (bank 1 and bank 2) harness connectors and remove harness clip.
9. Using heated oxygen sensor wrench (SST), remove heated oxy-
gen sensor 1 (bank 1 and bank 2).
CAUTION:
Be careful not to damage heated oxygen sensor.
Discard any heated oxygen sensor which has been
dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; replace with a new
sensor.
10. Remove water pipes on both right and left side. Refer to CO-28, "
WATER OUTLET AND WATER PIPING"
.
11. Remove exhaust manifold cover (right and left bank).
12. Loosen nuts in the reverse order as shown in the figure to
remove exhaust manifold with power tool.
NOTE:
Disregard the numerical order No. 7 and No. 8 in removal.
13. Remove exhaust manifold gaskets.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
SBIA0575E
