QUICK REFERENCE CHART FX35/FX45
REAR WHEEL ALIGNMENT (Unladen*)
ELS0003Y
* : Fuel, engine coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
BRAKEELS0003Z
* : Under force of 490 N( 50 kg, 110 lb ) with engine running.
REFILL CAPACITIESELS00040
Camber
Degree minute (Decimal degree)Minimum – 1° 18′ ( – 1.30° )
Nominal – 0° 48′ ( – 0.80° )
Maximum – 0° 18′ ( – 0.30° )
To t a l t o e - i nDistance ( A – B ) Minimum 2.4 mm ( 0.094 in )
Nominal 4.7 mm ( 0.185 in )
Maximum 7.0 mm ( 0.276 in )
Angle (left plus right )
Degree minute (Degree)Minimum 0° 05′ ( 0.08° )
Nominal 0° 10′ ( 0.17° )
Maximum 0° 15′ ( 0.25° )
Front brake Pad wear limit 2.0 mm ( 0.079 in )
Rotor repair limit 26.0 mm ( 1.024 in )
Rear brake Pad wear limit 2.0 mm ( 0.079 in )
Rotor repair limit 14.0 mm ( 0.551 in )
Pedal free height 161.5 - 171.5 mm ( 6.358 - 6.752 in )
Pedal depressed height* More than 80 mm ( 3.15 in )
UNITLiter US measure
Fuel tank90 23 - 3/4 gal
Coolant ( With reservoir tank )VQ35DE 8.6 9 - 1/8 qt
VK45DE 10.0 10 - 5/8 qt
Engine(VQ35DE)Drain and refill
With oil filter change 4.7 5 qt
Without oil filter change 4.4 4 - 5/8 qt
Dry engine (Overhaul) 5.4 5 - 3/4 qt
Engine(VK45DE)Drain and refill
With oil filter change 6.6 7qt
Without oil filter change 6.0 6 - 3/8 qt
Dry engine (Overhaul) 7.7 8 - 1/8 qt
Transmission A/T 10.3 10 - 7/8 qt
Transfer1.25 2 - 5/8 pt
Differential carrierFront 0.65 1 - 3/8 pt
Rear 1.4 3 pt
Power steering system 1.0 1 - 1/8 qt
Air conditioning systemCompressor oil 0.18 6.0 fl oz
Refrigerant 0.55 kg 1.21 lb
2004

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
BR-5
C
D
E
G
H
I
J
K
L
MA
B
BR
Revision: 2004 November 2004 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartAFS001MS
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: Applicable Reference page
BR-20
, BR-25
BR-20
, BR-25
BR-20
, BR-25—
—
BR-24, BR-29—
—
—
BR-24, BR-29

—
NVH in PR section
NHV in RFD section
NVH in FAX, RAX and FSU, RSU section
NVH in WT section
NVH in WT section
NVH in RAX section
NVH in PS section
Possible cause and
SUSPECTED PARTS
Pads - damaged
Pads - uneven wear
Shims damaged
Rotor imbalance
Rotor damage
Rotor runout
Rotor deformation
Rotor deflection
Rotor rust
Rotor thickness variation
Drum out of round
PROPELLER SHAFT
DIFFERENTIAL
AXLE AND SUSPENSION
TIRES
ROAD WHEEL
DRIVE SHAFT
STEERING
Symptom BRAKENoise××× ×× ×××
××
Shake×××××
××
Shimmy, Judder××××××× ××× ×

EM-146
[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2004 November 2004 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00100
Standard and LimitABS004XK
GENERAL SPECIFICATIONS
Cylinder arrangementV-6
Displacement cm
3 (cu in)3,498 (213.45)
Bore and stroke mm (in)95.5 x 81.4 (3.76 x 3.205)
Valve arrangementDOHC
Firing order1-2-3-4-5-6
Number of piston ringsCompression 2
Oil 1
Number of main bearings4
Compression ratio10.3
Compression pressure
kPa (kg/cm
2 , psi)/300 rpmStandard 1,275 (13.0, 185)
Minimum 981 (10.0, 142)
Differential limit between cylinders 98 (1.0, 14)
Cylinder number
Va l v e t i m i n g
(Intake valve timing control - “OFF”)
Unit: degree
abcde f
240 238 - 6 64 8 52
SEM713A
PBIC0187E

EM-266
[VK45DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2004 November 2004 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitABS006IX
GENERAL SPECIFICATIONS
DRIVE BELTS
INTAKE MANIFOLD AND EXHAUST MANIFOLD
Unit: mm (in) Cylinder arrangementV-8
Displacement cm
3 (cu in)4,494 (274.22)
Bore and stroke mm (in)93 x 82.7 (3.66 x 3.256)
Valve arrangementDOHC
Firing order1-8-7-3-6-5-4-2
Number of piston ringsCompression 2
Oil 1
Number of main bearings5
Compression ratio10.5
Compression pressure
kPa (kg/cm
2 , psi)/300 rpmStandard 1,320 (13.5, 191)
Minimum 1,130 (11.5, 164)
Differential limit
between cylinders98 (1.0, 14)
Cylinder number
Va l v e t i m i n g
Unit: degree
abcde f
228240060048
SEM957C
PBIC0187E
Tension of drive belts Auto adjustment by auto tensioner
Items Limit
Surface distortionIntake manifold (upper) 0.1 (0.004)
Intake manifold (lower) 0.1 (0.004)
Exhaust manifold 0.3 (0.012)

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
FAX-9
[AWD]
C
E
F
G
H
I
J
K
L
MA
B
FA X
Revision: 2004 November 2004 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartADS000OK
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
—
FAX-15—
FAX-10—
FAX-10
NVH in FFD section
NVH in FAX and FSU section
Refer to FRONT AXLE in this chart.
NVH in WT section
NVH in WT section
Refer to DRIVE SHAFT in this chart.
NVH in BR section
NVH in PS section
Possible cause and SUSPECTED PARTS
Excessive joint angle
Joint sliding resistance
Imbalance
Improper installation, looseness
Parts interference
Wheel bearing damage
FRONT DIFFERENTIAL
FRONT AXLE AND FRONT SUSPENSION
FRONT AXLE
TIRES
ROAD WHEEL
DRIVE SHAFT
BRAKES
STEERING
SymptomDRIVE
SHAFTNoise×× ×××××× ××
Shake×× ×××××××
FRONT
AXLENoise×××× ××××××
Shake××× ××××××
Vibration××× ××××
Shimmy×× ××× ××
Judder××××××
Poor quality ride or handling×× ×××

FFD-1
FRONT FINAL DRIVE
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION FFD
A
B
FFD
Revision: 2004 November 2004 FX35/FX45
FRONT FINAL DRIVE
PRECAUTIONS .......................................................... 2
Precautions .............................................................. 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
Commercial Service Tools ........................................ 5
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 6
NVH Troubleshooting Chart ..................................... 6
FRONT OIL SEAL ...................................................... 7
Removal and Installation .......................................... 7
REMOVAL ............................................................. 7
INSTALLATION ..................................................... 8
SIDE OIL SEAL .......................................................... 9
Removal and Installation .......................................... 9
REMOVAL ............................................................. 9
INSTALLATION ..................................................... 9
FRONT FINAL DRIVE ASSEMBLY .......................... 10
Removal and Installation (VQ35DE) ...................... 10
REMOVAL ........................................................... 10
INSTALLATION ................................................... 10
Removal and Installation (VK45DE) ........................ 11
REMOVAL ............................................................ 11
INSTALLATION .................................................... 11
Front Final Drive Breather Hose ............................ 12
REMOVAL AND INSTALLATION (VQ35DE) ....... 12
REMOVAL AND INSTALLATION (VK45DE) ....... 13
Components ........................................................... 14
COMPONENTS (VQ35DE) ................................. 14
COMPONENTS (VK45DE) ................................. 16Side Shaft ............................................................... 18
BEARING AND OIL SEAL REPLACEMENT ....... 18
EXTENSION TUBE REPLACEMENT ................. 19
PRE-DISASSEMBLY INSPECTION .................... 19
DISASSEMBLY AND ASSEMBLY ...................... 21
Differential Case Assembly .................................... 24
Installation Drive Pinion Assembly ......................... 27
DIFFERENTIAL CASE INSTALLATION .............. 28
TOOTH CONTACT INSPECTION ....................... 30
TOOTH CONTACT PATTERN AND HEIGHT
ADJUSTING WASHER SELECTION .................. 31
TOOTH CONTACT ADJUSTMENT ..................... 31
TOTAL PRELOAD INSPECTION ........................ 33
DRIVE PINION PRELOAD ADJUSTMENT ......... 33
After Inspection ....................................................... 35
Carrier Cover Installation ........................................ 36
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 37
General Specifications ............................................ 37
Drive Gear Runout .................................................. 37
Side Gear Adjustment ............................................ 37
Available Side Gear Thrust Washers ...................... 37
SIDE BEARING PRELOAD ADJUSTING SHIMS ... 37
Drive Pinion Height Adjustment .............................. 38
AVAILABLE PINION HEIGHT ADJUSTING
WASHERS .......................................................... 38
Drive Pinion Preload Adjustment ............................ 38
AVAILABLE PINION HEIGHT ADJUSTING
WASHERS .......................................................... 38
Total Preload Adjustment ........................................ 38

FFD-2
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
PrecautionsADS000N3
CAUTION:

Before starting diagnosis of the vehicle, understand symptoms well. Perform correct and system-
atic operations.

Check for the correct installation status prior removal or disassembly. When mating marks are
required, be sure they do not interfere with the function of the parts they are applied to.

Carry out an overhaul in a clean work place, Using a dust proof room is recommended.

Before disassembly, using steam or white gasoline, completely remove sand and mud from the
exterior the unit, preventing them from entering into the unit during disassembly or assembly.

Check appearance of the disassembled parts for damage, deformation, and abnormal wear. If a
malfunction is detected, replace it with a new one.

Normally replace lock pins, oil seals, and bearings with new ones every times they are removed.

In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to out-
side. If tightening sequence is specified, observe it.

Clean and flush the parts sufficiently and blow them dry.

Be careful not to damage the sliding surfaces and mating surface.

When applying sealant, remove the old sealant from the mounting surface; then remove any mois-
ture, oil, and foreign materials from the application and mounting surfaces.

Always use shop paper for cleaning the inside of components.

Avoid using cotton gloves or a shop cloth to prevent entering of lint.

During assembly, observe the specified tightening torque, and new differential oil, Vaseline, or
multi-purpose grease, as specified for each vehicle, when necessary.

FFD-6
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: 2004 November 2004 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartADS000N6
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
Refer to FFD-24, "
INSPECTION
" .
Refer to FFD-30, "
TOOTH CONTACT INSPECTION
" .
Refer to FFD-24, "
INSPECTION
" .
Refer to RFD-13, "
Pre-Inspection
"
—
Refer to MA-31, "
Checking Differential Gear Oil
" .
NVH in PR section.
NVH in FAX, RAX, FSU and RSU sections.
NVH in WT section.
NVH in WT section.
NVH in FAX section.
NVH in BR section.
NVH in PS section.
Possible cause and suspected parts
Rough gear tooth
Improper gear contact
Tooth surfaces worn
Incorrect backlash
Companion flange excessive runout
Improper gear oil
Propeller shaft
Axle and suspension
Tire s
Road wheel
Drive shaft
Brakes
Steering
Symptom Differential Noise×××××××××××××
