Page 1153 of 4449

INFINITI FX35 2004 Service Manual BRC-28
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
Display Item List
Self-diagnostic item Malfunction detecting condition Check system
FR LH SENSOR- 1
[C1104]Circuit of fron

BRC-28
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
Display Item List
Self-diagnostic item Malfunction detecting condition Check system
FR LH SENSOR- 1
[C1104]Circuit of front LH wheel sensor is open, shorted or sensor power
voltage is unusual.
BRC-37, "
Inspection 1:
Wheel Sensor System"
(Note 1) RR RH SENSOR- 1
[C1101]Circuit of rear RH wheel sensor is open, shorted or sensor power
voltage is unusual.
FR RH SENSOR- 1
[C1103]Circuit of front RH wheel sensor is open, shorted or sensor power
voltage is unusual.
RR LH SENSOR- 1
[C1102]Circuit of rear LH wheel sensor is open, shorted or sensor power
voltage is unusual.
FR LH SENSOR- 2
[C1108]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
RR RH SENSOR- 2
[C1105]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
FR RH SENSOR- 2
[C1107]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
RR LH SENSOR- 2
[C1106]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
STOP LAMP SW
[C1116]Stop lamp switch circuit is open or shorted.BRC-50, "
Inspection 10:
Stop Lamp Switch Sys-
tem"
PRESS SEN CIRCUIT
[C1142]Pressure sensor signal line is open or shorted, or sensor power
voltage is unusual, or pressure sensor is malfunctioning.BRC-40, "Inspection 4:
Pressure Sensor Sys-
tem"
ST ANG SEN CIRCUIT
[C1143]Neutral position of steering angle sensor is dislocated, or steer-
ing angle sensor is malfunctioning.BRC-42, "Inspection 5:
Steering Angle Sensor
System"
YAW RATE SENSOR
[C1145]Yaw rate sensor has generated an error, or yaw rate sensor sig-
nal line is open or shorted.BRC-44, "
Inspection 6:
Yaw Rate/Side G-Sensor
(2WD model), Yaw Rate/
Side/Decel G-sensor
(AWD models) System"

Page 1154 of 4449

INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-29
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control
lin

TROUBLE DIAGNOSIS
BRC-29
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
BRC-46, "
Inspection 7:
Solenoid and VDC
Change-Over Valve Sys-
tem"
FR LH OUT ABS SOL
[C1121]Circuit of front LH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
RR RH IN ABS SOL
[C1126]Circuit of rear RH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
RR RH OUT ABS SOL
[C1127]Circuit of rear RH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
FR RH IN ABS SOL
[C1122]Circuit of front RH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
FR RH OUT ABS SOL
[C1123]Circuit of front RH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
RR LH IN ABS SOL
[C1124]Circuit of rear LH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
RR LH OUT ABS SOL
[C1125] Circuit of rear LH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
CV1
[C1164]Primary side VDC switch-over solenoid valve 1 (cut valve 1) is
open or shorted, or control line is open or shorted to power sup-
ply or ground.
CV2
[C1165]Secondary side VDC switch-over solenoid valve 2 (cut valve 2) is
open or shorted, or control line is open or shorted to power sup-
ply or ground.
SV1
[C1166]Primary side VDC switch-over solenoid valve 1 (suction valve 1)
is open or shorted, or control line is open or shorted to power
supply or ground.
SV2
[C1167]Secondary side VDC switch-over solenoid valve 2 (suction valve
2) is open or shorted, or control line is open or shorted to power
supply or ground.
PUMP MOTOR (Note 3)
[ C 1111 ]During actuator motor operation with ON, when actuator motor
turns OFF or when control line for actuator motor relay is open.
BRC-47, "
Inspection 8:
Actuator Motor System"During actuator motor operation with OFF, when actuator motor
turns ON or when control line for relay is shorted to ground.
ABS SENSOR
[ABNORMAL SIGNAL]
[C1115]Wheel sensor input is malfunction.BRC-37, "
Inspection 1:
Wheel Sensor System"
(Note 1)
BATTERY VOLTAGE
[ABNORMAL]
[C1109]ABS actuator and electric unit (control unit) power voltage is too
low.BRC-48, "
Inspection 9:
ABS Actuator and Elec-
tric Unit (Control Unit)
Power Supply and
Ground System"
ST ANG SEN SIGNAL
[C1144]Neutral position correction of steering angle sensor is not fin-
ished.BRC-42, "Inspection 5:
Steering Angle Sensor
System"ST ANG SEN COM CIR
[C1156]CAN communication line or steering angle sensor has generated
an error.
SIDE G-SEN CIRCUIT
[C1146]Side G-sensor is malfunctioning, or signal line of side G-sensor is
open or shorted.BRC-44, "
Inspection 6:
Yaw Rate/Side G-Sensor
(2WD model), Yaw Rate/
Side/Decel G-sensor
(AWD models) System"
CONTROLLER FAILURE
[C1110]Internal malfunction of ABS actuator and electric unit (control
unit)BRC-40, "Inspection 3:
VDC/TCS/ABS Control
Unit System"
Self-diagnostic item Malfunction detecting condition Check system

Page 1155 of 4449

INFINITI FX35 2004 Service Manual BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
Note 1: After completing repairs of shorted sensor circuit, when turn ignition switch ON, ABS warning lamp
turned on. Chec

BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
Note 1: After completing repairs of shorted sensor circuit, when turn ignition switch ON, ABS warning lamp
turned on. Check that ABS warning lamp turned off while driving vehicle at approximately 30 km/h (19 MPH)
or more for approximately 1 minute according to self-diagnosis procedure. In addition, if wheel sensor 2 is dis-
played for wheels, check wheel sensor circuit and also check ABS actuator and electric unit (control unit)
power voltage.
Note 2: If multiple malfunctions are detected including CAN communication line [U1000], perform diagnosis for
CAN communication line first.
Note 3: “ACTUATOR RLY” on the CONSULT-II self-diagnostic results indicates the malfunction of actuator
relay or circuit. Actuator relay is imbedded in ABS actuator and electric unit (control unit).
DATA MONITOR
Operation Procedure
1. After turning OFF ignition switch, connect CONSULT-II and CONVERTER to data link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
2. Turn ignition switch ON.
3. Touch “START (NISSAN BASED VHCL)”, “ABS”, “DATA MONITOR” in order on the CONSULT-II screen.
If “ABS” is not indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAN COMM CIRCUIT
[U1000]
CAN communication line is open or shorted.
ABS actuator and electric unit (control unit) internal malfunc-
tion
Battery voltage for EMC is suddenly interrupted for approxi-
mately 0.5 seconds or more.BRC-53, "
Inspection 14:
CAN Communication
System" (Note 2)
BR FLUID LEVEL LOW
[C1155]Brake fluid level drops or circuit between ABS actuator and elec-
tric unit (control unit) and brake fluid level switch is open or
shorted.BRC-51, "
Inspection 11:
Brake Fluid Level Switch
System"
VARIANT CODING
[C1170]V coding is not functioning.ABS actuator and elec-
tric unit (control unit) and
circuit
G - SENSOR (AWD model)
[C1113]Decel G sensor is malfunctioning, or signal line of Decel G sen-
sor is open or shorted.BRC-44, "
Inspection 6:
Yaw Rate/Side G-Sensor
(2WD model), Yaw Rate/
Side/Decel G-sensor
(AWD models) System"
ENGINE SIGNAL 1
[C1130]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.–
ENGINE SIGNAL 2
[C1131]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine ETC system is malfunctioning.–
ENGINE SIGNAL 3
[C1132]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine CAN system is malfunctioning.–
ENGINE SIGNAL 4
[C1133]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine torque down system is malfunc-
tioning.–
ENGINE SIGNAL 6
[C1136]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine control system is malfunctioning.–
ACTUATOR RLY
[C1140] (Note 3)
Actuator solenoid valve relay is ON, even if control unit sends
off signal.
Actuator solenoid valve relay is OFF, even if control unit sends
on signal.BRC-47, "
Inspection 8:
Actuator Motor System"
DECEL G SEN SET (AWD model)
[C1160]Neutral position correction of Decel G -sensor is not finished.BRC-52, "
Inspection 13:
When “DECEL G SEN
SET” Appears on Self-
Diagnosis Results Dis-
play (AWD Model)"
Self-diagnostic item Malfunction detecting condition Check system

Page 1156 of 4449

INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-31
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting engine or t

TROUBLE DIAGNOSIS
BRC-31
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting engine or turning on
ignition switch, “ABS” might not be displayed in the system selection screen. In this case, repeat
the operation from step 1.
4. Return to the Monitor Item Selection screen, and touch “ECU INPUT SIGNALS”, “MAIN SIGNALS” or
“SELECTION FROM MENU”. Refer to the following information.
5. When “START” is touched, the data monitor screen is displayed.
Display Item List
Item
(Unit)Data monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU
GEAR×××Gear position judged by PNP
switch signal is displayed.
FR RH SENSOR
(km/h, MPH)×××Wheel speed calculated by front
RH wheel sensor signal is dis-
played.
FR LH SENSOR
(km/h, MPH)×××Wheel speed calculated by front
LH wheel sensor signal is dis-
played.
RR RH SENSOR
(km/h, MPH)×××Wheel speed calculated by rear
RH wheel sensor signal is dis-
played.
RR LH SENSOR
(km/h, MPH)×××Wheel speed calculated by rear
LH wheel sensor signal is dis-
played.
BATTERY VOLT
(V)×××Voltage supplied to ABS actuator
and electric unit (control unit) is
displayed.
SLCT LVR POSI×××Shift position judged by PNP
switch signal.
ACCEL POS SIG
(%)×––Throttle valve open/close status
judged by CAN communication
signal is displayed.
ENGINE SPEED
(rpm)×××Engine speed judged by CAN
communication signal is displayed.
STR ANGLE SIG
(deg)×––Steering angle detected by steer-
ing angle sensor is displayed.
YAW RATE SEN
(d/s)××–Yaw rate detected by yaw rate
sensor is displayed.
DECEL G-SEN (AWD model)
(G)×××Longitudinal acceleration detected
by decel G-sensor is displayed.
SIDE G-SENSOR
(m/s
2 )×––Lateral acceleration detected by
side G-sensor is displayed.
PRESS SENSOR
(bar)×––Brake fluid pressure detected by
pressure sensor is displayed.
STOP LAMP SW
(ON/OFF)×××Stop lamp switch (ON/OFF) status
is displayed.
OFF SW
(ON/OFF) ×× ×VDC OFF switch (ON/OFF) sta-
tus is displayed.
ABS WARN LAMP
(ON/OFF)–××ABS warning lamp (ON/OFF) sta-
tus is displayed.
SLIP LAMP
(ON/OFF)–××SLIP indicator lamp (ON/OFF) sta-
tus is displayed.
FR LH IN SOL
(ON/OFF)–××Front LH IN ABS solenoid (ON/
OFF) status is displayed.

Page 1157 of 4449

INFINITI FX35 2004 Service Manual BRC-32
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
FR LH OUT SOL
(ON/OFF)–××Front LH OUT ABS solenoid (ON/
OFF) status is displayed.
RR RH IN SOL
(ON/OFF)–××Rear RH

BRC-32
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
FR LH OUT SOL
(ON/OFF)–××Front LH OUT ABS solenoid (ON/
OFF) status is displayed.
RR RH IN SOL
(ON/OFF)–××Rear RH IN ABS solenoid (ON/
OFF) status is displayed.
RR RH OUT SOL
(ON/OFF) –××Rear RH OUT ABS solenoid (ON/
OFF) status is displayed.
FR RH IN SOL
(ON/OFF)–××Front RH IN ABS solenoid (ON/
OFF) status is displayed.
FR RH OUT SOL
(ON/OFF)–××Front RH OUT ABS solenoid (ON/
OFF) status is displayed.
RR LH IN SOL
(ON/OFF)–××Rear LH IN ABS solenoid (ON/
OFF) status is displayed.
RR LH OUT SOL
(ON/OFF)–××Rear LH OUT ABS solenoid (ON/
OFF) status is displayed.
OFF LAMP
(ON/OFF)–××OFF Lamp (ON/OFF) status is dis-
played.
MOTOR RELAY
(ON/OFF)–××ABS motor relay signal (ON/OFF)
status is displayed.
ACTUATOR RLY
(ON/OFF)– ×× ABS actuator relay signal (ON/
OFF) status is displayed.
CV1
(ON/OFF)––×Primary side switch-over solenoid
valve 1 (cut valve 1) (ON/OFF)
status is displayed.
CV2
(ON/OFF)––×Secondary side switch-over sole-
noid valve 2 (cut-valve 2) (ON/
OFF) status is displayed.
SV1
(ON/OFF)––×Primary side switch-over solenoid
valve 1 (suction valve 1) (ON/OFF)
status is displayed.
SV2
(ON/OFF)––×Secondary side switch-over sole-
noid valve 2 (suction valve 2) (ON/
OFF) status is displayed.
VDC FAIL SIG
(ON/OFF)––×VDC fail signal (ON/OFF) status is
displayed.
TCS FAIL SIG
(ON/OFF)––×TCS fail signal (ON/OFF) status is
displayed.
ABS FAIL SIG
(ON/OFF)––×ABS fail signal (ON/OFF) status is
displayed.
EBD FAIL SIG
(ON/OFF)––×EBD fail signal (ON/OFF) status is
displayed.
FLUID LEV SW
(ON/OFF)×––Brake fluid level switch (ON/OFF)
status is displayed.
EBD SIGNAL
(ON/OFF)––×EBD operation (ON/OFF) status is
displayed.
ABS SIGNAL
(ON/OFF)––×ABS operation (ON/OFF) status is
displayed.
TCS SIGNAL
(ON/OFF)––×TCS operation (ON/OFF) status is
displayed.
VDC SIGNAL
(ON/OFF)––×VDC operation (ON/OFF) status is
displayed.
EBD WARN LAMP
(ON/OFF)––×Brake warning lamp (ON/OFF)
status is displayed. (Note) Item
(Unit)Data monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU

Page 1158 of 4449

INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-33
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
×:Applicable
–:Not applicable
Note: Serves as EBD warning lamp.
ACTIVE TEST
CAUTION:
Do not

Page 1159 of 4449

INFINITI FX35 2004 Service Manual BRC-34
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45
*: ON for 1 to 2 seconds after the touch, and then OFF
NOTE:
If active test is performed with brake pedal depressed, peda

Page 1160 of 4449

INFINITI FX35 2004 Service Manual TROUBLE DIAGNOSIS
BRC-35
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
For Fast and Accurate DiagnosisAFS001SR
PRECAUTIONS FOR DIAGNOSIS
Before performing diagnosis,

TROUBLE DIAGNOSIS
BRC-35
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2004 November 2004 FX35/FX45
For Fast and Accurate DiagnosisAFS001SR
PRECAUTIONS FOR DIAGNOSIS
Before performing diagnosis, always read precautions. Refer to BRC-12, "How to Proceed With Diagno-
sis" .
If ABS actuator and electric unit (control unit), steering angle sensor, steering system parts or suspension
system parts have been replaced, or if alignment has been adjusted, be sure to adjust neutral position of
steering angle sensor before driving. Refer to BRC-6, "
Adjustment of Steering Angle Sensor Neutral Posi-
tion" .
After diagnosis is finished, be sure to erase memory. Refer to BRC-27, "SELF-DIAGNOSIS" .
When checking continuity and voltage between units, be sure to check for disconnection, looseness,
bend, or collapse of connector terminals. If any malfunction is found, repair or replace connector termi-
nals.
For intermittent symptoms, possible cause is malfunction in harness, harness connector, or terminals.
Move harness, harness connector, and terminals to check for poor connections.
If a circuit tester is used for the check, be careful not to forcibly extend any connector terminal.
To use CONSULT-II to perform self-diagnosis of ABS actuator and electric unit (control unit), active tests,
or work support, first stop work, then connect CONSULT-II and select “ABS”.
While self-diagnostic results of CONSULT-II shows malfunction, if CONSULT-II active test is performed,
an engine system error may be indicated. In this case, start engine to resume the normal screen.
VDC/TCS/ABS system electronically controls brake operation and engine output. The following symptoms
may be caused by normal operations:
Symptom Symptom description Result
Motor operation noiseThis is noise of motor inside ABS actuator and electric unit (control unit).
Slight noise may occur during VDC, TCS, and ABS operation.
Normal
When the vehicle speed goes over 20 km/h (12.5 MPH), motor and
valves operating noise may be heard. It happens only once after IGN
(ignition) is ON. This is a normal status of the system operation check.
System operation check
noiseWhen engine starts, slight “click” noise may be heard from engine room.
This is normal and is part of system operation check.Normal
VDC/TCS operation
(SLIP indicator lamp blink-
ing)TCS may activate momentarily if wheel speed changes when driving
over location where friction coefficient varies, when up/downshifting, or
when fully depressing accelerator pedal.
Normal
Cancel the VDC/TCS
function for the
inspection on a chas-
sis dynamometer. For inspection of speedometer or other instruments, press
VDC OFF SW to turn VDC/TCS function off.
When accelerator pedal is depressed on a chassis dynamometer (fixed
front-wheel type), vehicle speed will not increase. This is not normal. It is
result of TCS being activated by stationary front wheels. Warning lamp
may also illuminate to indicate “sensor system error”. This is also nor-
mal, and is the result of the stationary front wheels being detected. To be
certain, restart engine, and drive vehicle at 30 km/h (19 MPH) or more.
Make sure warning lamp does not illuminate.
ABS operation (Longer stop-
ping distance)On roads with low friction coefficients, such as snowy roads or gravel
roads, vehicles with ABS may require a longer stopping distance. There-
fore, when driving on such roads, avoid overconfidence and keep speed
sufficiently low.Normal
Insufficient feeling of accel-
erationDepending on road conditions, driver may feel that feeling of accelera-
tion is insufficient. This is because traction control, which controls
engine and brakes to achieve optimal traction, has the highest priority
(for safety). As a result, there may be times when acceleration is slightly
less than usual for the same accelerator pedal operation.Normal

Load next 8 pages

Page: < prev 1-10 ... 1121-1128 1129-1136 1137-1144 1145-1152 1153-1160 1161-1168 1169-1176 1177-1184 1185-1192 ... 4456 next >

drain bolt fuel filter tailgate engine gas mileage coolant temperature
