Page 697 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT MIRROR HORIZONTAL SENSOR OUT OF RANGE LOW When Monitored and Set Condition: LEFT MIRROR HORIZONTAL SENSOR OUT OF RANGE LOW When Monitored: Continuously when the PCI bus is active. Set Co

Page 698 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Memory Seat Mirror Module C1 connector. Disconnect the Left Power Mirror connector. Measure the resistance of the Left Mirror Horizont

Page 699 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT MIRROR VERTICAL SENSOR OUT OF RANGE HIGH When Monitored and Set Condition: LEFT MIRROR VERTICAL SENSOR OUT OF RANGE HIGH When Monitored: Continuously when the PCI bus is active. Set Cond

Page 700 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Left Power Mirror connector. Measure the resistance of the Left Mirror Sensor Ground circuit in the harness connector to ground. Is th

Page 701 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT MIRROR VERTICAL SENSOR OUT OF RANGE LOW When Monitored and Set Condition: LEFT MIRROR VERTICAL SENSOR OUT OF RANGE LOW When Monitored: Continuously when the PCI bus is active. Set Condit

Page 702 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Memory Seat Mirror Module C1 connector. Disconnect the Left Power Mirror connector. Measure the resistance of the Left Mirror Vertical

Page 703 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: MEMORY POSITION SWITCH STUCK When Monitored and Set Condition: MEMORY POSITION SWITCH STUCK When Monitored: Anytime the Body Control Module is awake. Set Condition: If the Memory switch is ac

Page 704 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 4 If there are no possible causes remaining, view repair. All Repair Replace the Body Control Module. Perform MEMORY SYSTEM VERIFICATION TEST - VER 1. 675 MEMORY SEAT MEMORY
