Page 2449 of 4284

CHRYSLER VOYAGER 2001 Service Manual AUTO TEMP CONTROL C2 - BLACK 13 WAY CAV CIRCUIT FUNCTION 1 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL 2 C121 20DB/DG SENSOR GROUND 3 E12 20OR/GY PANEL LAMPS DRIVER 4 A114 20GY/RD FUSED B(+) (I.O

Page 2450 of 4284

CHRYSLER VOYAGER 2001 Service Manual BLOWER MOTOR RESISTOR C1 (MTC) - BLACK 6 WAY CAV CIRCUIT FUNCTION 1 C75 12DB/GY BLOWER MOTOR HIGH DRIVER 2 C74 12DB/WT BLOWER MOTOR M3 DRIVER 3 C73 14DB/VT BLOWER MOTOR M2 DRIVER 4 C7 12DB FUSED FRONT

Page 2451 of 4284

CHRYSLER VOYAGER 2001 Service Manual BODY CONTROL MODULE C2 - BLACK/GREEN 34 WAY CAV CIRCUIT FUNCTION 1 L61 18WT/LG LEFT FRONT TURN SIGNAL DRIVER 2 L63 18WT/DG LEFT REAR TURN SIGNAL DRIVER 3 L60 18WT/TN RIGHT FRONT TURN SIGNAL DRIVER 4 L

Page 2452 of 4284

CHRYSLER VOYAGER 2001 Service Manual BODY CONTROL MODULE C3 - BLACK/WHITE 34 WAY CAV CIRCUIT FUNCTION 1 G23 20VT/DB (POWER SLIDING DOOR)SLIDING DOORS OVERHEAD SWITCH MUX 2 D23 20WT/BR FLASH PROGRAM ENABLE 3 G152 20VT/GY (POWER SLIDING DO

Page 2453 of 4284

CHRYSLER VOYAGER 2001 Service Manual BODY CONTROL MODULE C4 - BLACK/GRAY 34 WAY CAV CIRCUIT FUNCTION 1 E18 20OR/LB (POWER MIRRORS) PANEL LAMPS DRIVER (MIRROR SWITCH) 2 E12 20OR/GY PANEL LAMPS DRIVER (HVAC) 3 E19 20OR/BR PANEL LAMPS DRIVE

Page 2454 of 4284

CHRYSLER VOYAGER 2001 Service Manual BODY CONTROL MODULE C5 - BLACK/BLACK 34 WAY CAV CIRCUIT FUNCTION 1 L91 20WT/DB HAZARD SWITCH SENSE 2- - 3- - 4- - 5- - 6- - 7- - 8- - 9- - 10 G20 20VT/BR IGNITION SWITCH SENSE 11 - - 12 - - 13 - - 14

Page 2455 of 4284

CHRYSLER VOYAGER 2001 Service Manual BRAKE FLUID LEVEL SWITCH - BLACK 2 WAY CAV CIRCUIT FUNCTION A B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE B Z420 20BK/OR GROUND BRAKE LAMP SWITCH - BLACK 6 WAY CAV CIRCUIT FUNCTION 1 A103 18GY/RD FUSED

Page 2456 of 4284

CHRYSLER VOYAGER 2001 Service Manual C100 - BLACK (POWERTRAIN SIDE) CAV CIRCUIT 1 D21 18WT/BR 2 D16 18WT/OR (EATX) 3 D20 18WT/LG (GAS) 3 K119 20DB/LG (DIESEL) 4 D25 20WT/VT (DIESEL) 4 D25 18WT/VT (GAS) 5 Z111 18BK/WT 6 N1 18DB/OR (DIESEL
