Page 145 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: ORC, DRIVER SQUIB 2 SHORT TO BATTERY - ACTIVE When Monitored and Set Condition: ORC, DRIVER SQUIB 2 SHORT TO BATTERY - ACTIVE When Monitored: When the ignition is on, the ORC monitors the vol

Page 146 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 2NOTE: Ensure that the battery is fully charged. WARNING: TURN THE IGNITION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BEFORE PROCEEDING. WARNING: IF THE AIRBAG CONTROL

Page 147 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 4NOTE: Ensure that the battery is fully charged. WARNING: TURN THE IGNITION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BEFORE PROCEEDING. WARNING: DO NOT PLACE AN INTAC

Page 148 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: ORC, DRIVER SQUIB 2 SHORT TO GROUND - ACTIVE When Monitored and Set Condition: ORC, DRIVER SQUIB 2 SHORT TO GROUND - ACTIVE When Monitored: When the ignition is on, the ORC monitors the resis

Page 149 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 2NOTE: Ensure that the battery is fully charged. WARNING: TURN THE IGNITION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BEFORE PROCEEDING. WARNING: DO NOT PLACE AN INTAC

Page 150 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 4NOTE: Ensure that the battery is fully charged. WARNING: TURN THE IGNITION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BEFORE PROCEEDING. WARNING: IF THE AIRBAG CONTROL

Page 151 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: ORC, INTERROGATE LEFT SIACM - ACTIVE When Monitored and Set Condition: ORC, INTERROGATE LEFT SIACM - ACTIVE When Monitored: With ignition on, the ORC monitors the PCI Bus for a Left SIACM sta

Page 152 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: ORC, INTERROGATE RIGHT SIACM - ACTIVE When Monitored and Set Condition: ORC, INTERROGATE RIGHT SIACM - ACTIVE When Monitored: With ignition on, the ORC monitors the PCI Bus for a Right SIACM
