CHRYSLER VOYAGER 2001 Service Manual Symptom:
EVAPORATOR TEMPERATURE SENSOR CIRCUIT SHORT (AC-
TIVE) - MANUAL A/C
When Monitored and Set Condition:
EVAPORATOR TEMPERATURE SENSOR CIRCUIT SHORT (ACTIVE) - MANUAL
A/C
When Monitored: With th

Page 570 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY
2 Turn the ignition off.
Disconnect the A/C - Heater Control Module C1 harness connector.
Open the glove box door. Disconnect the glove box door roller latch from each side o

Page 571 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom List:
FRONT AND REAR BLOWER OUTPUT 1 OPEN
FRONT AND REAR BLOWER OUTPUT 2 OPEN
Test Note: All symptoms listed above are diagnosed using the same tests.
The title for the tests will be FRONT AND

Page 572 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY
2 Remove either the Front Blower Motor Relay or the Rear Blower Motor Relay, if
equipped, from the IPM.
Using a 12-volt test light connected to ground, probe cavity 86 of the

TEST ACTION APPLICABILITY
2 Remove either the Front Blower Motor Relay or the Rear Blower Motor Relay, if
equipped, from the IPM.
Using a 12-volt test light connected to ground, probe cavity 86 of the blower relay
connector.
Is the test light illuminated?All
Ye s®Go To 3
No®Check the B+ feed to the Intelligent Power Module (IPM) for an
open. If OK, replace the IPM in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
3 Turn the ignition off.
Install a substitute relay in place of the existing Front Blower Motor Relay and the
existing Rear Blower Motor Relay, if equipped.
With the DRB, erase DTCs.
Turn the ignition off, wait 30 seconds, then turn the ignition on.
With the DRB, read DTCs.
Did these DTCs reset?All
Ye s®Go To 4
No®Replace the Front Blower Motor Relay and the Rear Blower
Motor Relay, if equipped.
Perform BODY VERIFICATION TEST - VER 1.
4 Turn the ignition off.
Remove the Front Control Module from the IPM.
Remove the Front Blower Motor Relay and the Rear Blower Motor Relay, if equipped,
from the IPM.
Measure the resistance between ground and the Front/Rear Blower Motor Relay
Control circuit (FCM connector cavity 30).
Is the resistance below 5.0 ohms?All
Ye s®Replace the Intelligent Power Module (IPM) in accordance with
the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
No®Go To 5
5 Turn the ignition off.
Remove the Front Control Module from the IPM.
Remove the Front Blower Motor Relay from the IPM.
Measure the resistance of the Front/Rear Blower Motor Relay Control circuit
between the FCM connector cavity 30 and the Front Blower Motor Relay connector
cavity 85.
Is the resistance below 5.0 ohms?All
Ye s®Replace the Front Control Module (FCM) in accordance with the
Service Information.
Perform BODY VERIFICATION TEST - VER 1.
No®Replace the Intelligent Power Module (IPM) in accordance with
the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
543
HEATING & A/C
FRONT AND REAR BLOWER OUTPUT 1 OPEN ÐContinued

Page 573 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom List:
FRONT AND REAR BLOWER OUTPUT 1 SHORT TO BATT
FRONT AND REAR BLOWER OUTPUT 2 SHORT TO BATT
Test Note: All symptoms listed above are diagnosed using the same tests.
The title for the tests

Page 574 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY
2 Turn the ignition off.
Install a substitute relay in place of the existing Front Blower Motor Relay.
With the DRB, erase DTCs.
Turn the ignition on.
With the DRB, read DTCs

Page 575 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom List:
LOOPBACK FAILURE (ACTIVE) - MANUAL A/C
LOOPBACK TEST FAILURE (ACTIVE) - MANUAL A/C
Test Note: All symptoms listed above are diagnosed using the same tests.
The title for the tests will b

Page 576 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom List:
NO PCM MESSAGE RECEIVED (ACTIVE) - MANUAL A/C
PCM COMMUNICATION FAILURE (ACTIVE) - MANUAL A/C
VEHICLE ODOMETER FAILURE (ACTIVE) - MANUAL A/C
Test Note: All symptoms listed above are diag
