Page 97 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY
2WARNING: TURN IGNITION OFF, DISCONNECT THE BATTERY AND WAIT
TWO MINUTES BEFORE PROCEEDING.
WARNING: DO NOT PLACE AN INTACT UNDEPLOYED SEAT BACK PAD-
DED SIDE DOWN ON A HARD

TEST ACTION APPLICABILITY
2WARNING: TURN IGNITION OFF, DISCONNECT THE BATTERY AND WAIT
TWO MINUTES BEFORE PROCEEDING.
WARNING: DO NOT PLACE AN INTACT UNDEPLOYED SEAT BACK PAD-
DED SIDE DOWN ON A HARD SURFACE, THE AIRBAG WILL PROPEL
INTO THE AIR IF ACCIDENTALLY DEPLOYED, AND COULD RESULT IN
SERIOUS OR FATAL INJURY.
Disconnect the Left Seat Airbag inline connector located between the seat back and
seat cushion.
Do not disconnect the airbag connectors at the base of the seat.
Disconnect the Left Side Impact Airbag Control Module connector
NOTE: Check connectors - Clean and repair as necessary.
Connect the SRS Load Tool 8443 SIACM adaptor to the Left Side Impact Airbag
Control Module connector.
Measure the resistance of the Left Seat Squib Line 2 circuit between the Left Side
Impact Airbag Control Module connector and ground.
Is the resistance below 5.0 Ohms on the Left Seat Squib Line 2 circuit?All
Ye s®Repair Left Seat Squib Line 2 short to ground.
Perform AIRBAG VERIFICATION TEST - VER 1.
No®Go To 3
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
3WARNING: TURN IGNITION OFF, DISCONNECT THE BATTERY AND WAIT
TWO MINUTES BEFORE PROCEEDING.
WARNING: DO NOT PLACE AN INTACT UNDEPLOYED SEAT BACK PAD-
DED SIDE DOWN ON A HARD SURFACE, THE AIRBAG WILL PROPEL
INTO THE AIR IF ACCIDENTALLY DEPLOYED, AND COULD RESULT IN
SERIOUS OR FATAL INJURY.
Disconnect the Left Seat Airbag inline connector located between the seat back and
seat cushion.
Do not disconnect the airbag connectors at the base of the seat.
Disconnect the Left Side Impact Airbag Control Module connector.
NOTE: Check connectors - Clean and repair as necessary.
Connect the SRS Load Tool 8443 SIACM adaptor to the Left Side Impact Airbag
Control Module connector.
Measure the resistance of the Left Seat Squib Line 1 circuit between the Left SIACM
connector and ground.
Is the resistance below 5.0 Ohms on the Left Seat Squib Line 1 circuit?All
Ye s®Repair Left Seat Squib Line 1 short to ground.
Perform AIRBAG VERIFICATION TEST - VER 1.
No®Go To 4
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
68
AIRBAG
LEFT SIACM, SEAT SQUIB SHORT TO GROUND - ACTIVE ÐContinued

Page 98 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY
4WARNING: TURN IGNITION OFF, DISCONNECT THE BATTERY AND WAIT
TWO MINUTES BEFORE PROCEEDING.
WARNING: IF THE LEFT SIDE IMPACT AIRBAG CONTROL MODULE IS
DROPPED AT ANY TIME, IT

Page 99 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom List:
ORC ACCELEROMETER - ACTIVE
ORC ACCELEROMETER - STORED
ORC INTERNAL 1 - ACTIVE
ORC INTERNAL 1 - STORED
ORC INTERNAL 2 - ACTIVE
ORC INTERNAL 2 - STORED
ORC OUTPUT DRIVER 1 - ACTIVE
ORC OUT

Page 100 of 4284

CHRYSLER VOYAGER 2001 Service Manual ORC INTERNAL 2 - ACTIVE
When Monitored: When the ignition on, the ORC on board diagnostics continuously
performs internal circuit tests.
Set Condition: This DTC will set if the ORC identifies an out o

Page 101 of 4284

CHRYSLER VOYAGER 2001 Service Manual ORC, NO PCI TRANSMISSION - ACTIVE
When Monitored: With the ignition in the On position and the ORC transmitting
information on the PCI BUS.
Set Condition: The code will set if the ORC cannot detect th

Page 102 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom:
ORC, CALIBRATION MISMATCH - ACTIVE
When Monitored and Set Condition:
ORC, CALIBRATION MISMATCH - ACTIVE
When Monitored: With ignition on, the ORC monitors the PCI Bus for the VIN message
cont

Page 103 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY
3WARNING: TURN THE IGNITION OFF, DISCONNECT THE BATTERY AND
WAIT TWO MINUTES BEFORE PROCEEDING.
WARNING: IF THE OCCUPANT RESTRAINT CONTROLLER IS DROPPED
AT ANY TIME, IT MUST

Page 104 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom List:
ORC, CALIBRATION MISMATCH - STORED
ORC, CLUSTER MESSAGE MISMATCH - STORED
ORC, DRIVER SBS OPEN - STORED
ORC, DRIVER SBS SHORT TO BATTERY - STORED
ORC, DRIVER SBS SHORT TO GROUND - STORED
