Page 2465 of 4284

CHRYSLER VOYAGER 2001 Service Manual C203 (UNITED KINGDOM) - WHITE (BODY SIDE) CAV CIRCUIT 1 D97 18WT/OR 2 D96 18WT/LB 3 A600 18RD/LB 4 G944 18LB/BR C203 (UNITED KINGDOM) - WHITE (INSTRU- MENT PANEL SIDE) CAV CIRCUIT 1 D97 20WT/OR 2 D96

Page 2466 of 4284

CHRYSLER VOYAGER 2001 Service Manual C300 (RHD) - BLACK (LEFT DOOR SIDE) CAV CIRCUIT 1 G75 20VT 2 Z822 20BK/BR 3 X53 20DG 4 X55 20DG/BR 5 G161 20VT/DG 6 P1 20TN/LG 7 P3 20TN/WT 8 F304 12WT/PK 9- 10 - C300 (RHD) - BLACK (BODY SIDE) CAV CI

Page 2467 of 4284

CHRYSLER VOYAGER 2001 Service Manual C301 - LT. GRAY (BODY SIDE) CAV CIRCUIT 1 M21 20YL/BR 2 X13 16DG/GY 3 X15 16GY/DG 4 X153 20DG/YL 5 X155 20DG/LB 6 G163 20VT/LB (POWER LOCKS) 7 G200 20VT/BR (LHD/MEMORY) 8 G920 20VT/YL (LHD/MEMORY) 9 Q

Page 2468 of 4284

CHRYSLER VOYAGER 2001 Service Manual C303 (LHD) - BLACK (RIGHT DOOR SIDE) CAV CIRCUIT 1 G74 20VT/WT 2 Z822 20BK/BR (POWER LOCKS) 2 Z74 20BK/WT (EXCEPT POWER LOCKS) 3 X54 20GY 4 X56 20GY/BR 5 G160 20VT/LG (POWER LOCKS) 6 P2 20TN/GY (POWER

Page 2469 of 4284

CHRYSLER VOYAGER 2001 Service Manual C303 (RHD) - BLACK (BODY SIDE) CAV CIRCUIT 1 G74 20VT/WT 2 Z821 12BK/BR 3 X54 20GY 4 X56 20GY/BR 5 G160 20VT/LG 6 P2 20TN/GY 7 P4 20TN/BR 8 F304 12WT/PK 9- 10 - 11 Q13 16OR/DB 12 Q23 16OR/LB 13 Q14 16

Page 2470 of 4284

CHRYSLER VOYAGER 2001 Service Manual C305 - GRAY (SEAT SIDE) CAV CIRCUIT 1 Z849 14BK/OR (POWER SEAT) 1 Z849 12BK/OR (HEATED SEAT) 2 R57 18LG/GY 3 R59 18LG/TN 4 P7 20LG/DG (HEATED SEAT) 5 A210 14OR/RD (POWER/HEATED SEAT) 6 F503 20WT/PK (H

Page 2471 of 4284

CHRYSLER VOYAGER 2001 Service Manual C307 - GRAY (SEAT SIDE) CAV CIRCUIT 1 Z848 18BK/OR (POWER/HEATED SEAT) 2 R58 18LB/GY 3 R60 18LB/TN 4 P8 20LG/WT (HEATED SEAT) 5 A210 14OR/RD (POWER/HEATED SEAT) 6 F503 20WT/PK (HEATED SEAT) 7- 8- 9- 1

Page 2472 of 4284

CHRYSLER VOYAGER 2001 Service Manual C309 - GREEN (RIGHT DOOR WIRE TRACK ASSEMBLY SIDE) CAV CIRCUIT 1 Z824 14BK (POWER SLIDING DOOR) 1 Z76 20BK (MANUAL SLIDING DOOR) 2 P34 20BK/TN 3 G76 20BK/DG 4 P38 20BK/DB 5- 6- 7 G152 20BK/GY (POWER S
