Page 4265 of 4284

CHRYSLER VOYAGER 2001 Service Manual 8.7 TRANSMISSION COMPONENT LOCATIONS C O M P O N E N T L O C A T I O N S 161 COMPONENT LOCATIONS

Page 4266 of 4284

CHRYSLER VOYAGER 2001 Service Manual NOTES 162

Page 4267 of 4284

CHRYSLER VOYAGER 2001 Service Manual 9.0 CONNECTOR PINOUTS AUTOSTICK SWITCH - BLACK 2 WAYCAV CIRCUIT FUNCTION 1 T55 20YL/VT AUTOSTICK/OVERDRIVE OFF MUX INPUT 2 Z65 20BK/YL GROUND BODY CONTROL MODULE C2 - BLACK/GREEN 34 WAYCAV CIRCUIT FUN

Page 4268 of 4284

CHRYSLER VOYAGER 2001 Service Manual BRAKE LAMP SWITCH - BLACK 6 WAYCAV CIRCUIT FUNCTION 1 A103 18GY/RD FUSED B(+) 2 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT 3 V30 20VT/WT SPEED CONTROL BRAKE SWITCH OUTPUT 4 V32 20VT/YL SPEED CONTROL ON/OFF

Page 4269 of 4284

CHRYSLER VOYAGER 2001 Service Manual DIAGNOSTIC JUNCTION PORT - BLACK 16 WAYCAV CIRCUIT FUNCTION 1 D25 20WT/VT PCI BUS (PCM/SKIM) 2 D25 20WT/VT PCI BUS (HVAC) 3 D25 20WT/VT PCI BUS (RADIO) 4 D25 20WT/VT PCI BUS (ORC) 5 D25 20WT/VT PCI BU

Page 4270 of 4284

CHRYSLER VOYAGER 2001 Service Manual INTELLIGENT POWER MODULE C4 - GRAY 10 WAYCAV CIRCUIT FUNCTION 1 Z127 12BK/DG GROUND 2 T750 12YL/GY ENGINE STARTER MOTOR RELAY OUTPUT 3 K342 16BR/WT AUTOMATIC SHUTDOWN RELAY OUTPUT 4 F500 18DG/PK (ANTI

Page 4271 of 4284

CHRYSLER VOYAGER 2001 Service Manual INTELLIGENT POWER MODULE C7 - BLACK 20 WAYCAV CIRCUIT FUNCTION 1 C16 20DB/GY FUSED REAR WINDOW DEFOGGER RELAY OUTPUT 2 T751 20YL FUSED IGNITION SWITCH OUTPUT (START) 3 D25 20WT/VT PCI BUS 4- - 5 K32 1

Page 4272 of 4284

CHRYSLER VOYAGER 2001 Service Manual OUTPUT SPEED SENSOR (3.3L/3.8L) - GRAY 2 WAYCAV CIRCUIT FUNCTION 1 T13 18DG/VT SPEED SENSOR GROUND 2 T14 18DG/BR OUTPUT SPEED SENSOR SIGNAL PARK/NEUTRAL POSITION SWITCH (2.4L) - BLACK 3 WAYCAV CIRCUIT
