Symptom:
*CHECKING IAC MOTOR (2.4L)
POSSIBLE CAUSES
IAC MOTOR OPERATION
IAC DRIVER CIRCUITS OPEN
IAC MOTOR
TEST ACTION APPLICABILITY
1 Turn the ignition on.
With the DRBIIIt, monitor engine RPM.
With the DRBIIIt, set the engine speed to 1400 RPM.
Does the engine speed reach 1400 rpm?All
Ye s®The IAC Motor is operation normally
Perform POWERTRAIN VERIFICATION TEST VER - 2.
No®Go To 2
2 Turn the ignition off.
Disconnect IAC Motor harness connector.
Disconnect the PCM harness connector.
Repeat each measurement for each IAC Driver circuit.
Measure the resistance of each IAC Driver circuit between the IAC Motor harness
connector and the PCM harness connector.
Is the resistance below 5.0 ohms at all IAC Driver circuits?All
Ye s®Replace the Idle Air Control Motor.
Perform POWERTRAIN VERIFICATION TEST VER - 2.
No®Repair the IAC Driver circuit(s) for an open.
Perform POWERTRAIN VERIFICATION TEST VER - 2.
231
DRIVEABILITY - GAS
Page 4026 of 4284
Symptom:
*CHECKING IAT SENSOR
POSSIBLE CAUSES
IAT SENSOR OPERATION
IAT SENSOR
TEST ACTION APPLICABILITY
1NOTE: Do not allow more than 5 minutes delay during the removal of the
IAT sensor and measure the temperature.
Turn the ignition on.
With the DRBIIIt, read and record the IAT temperature value.
Remove the IAT sensor.
Using a temperature probe, measure the temperature inside the opening of the IAT
sensor.
Compare both temperature readings.
Are the temperature readings with 12ÉC (10ÉF) of one another?All
Ye s®The IAT sensor is operating normally.
Perform POWERTRAIN VERIFICATION TEST VER - 2.
No®Replace the IAT sensor.
Perform POWERTRAIN VERIFICATION TEST VER - 2.
232
DRIVEABILITY - GAS
Page 4027 of 4284
Symptom:
*CHECKING MAP SENSOR
POSSIBLE CAUSES
MAP SENSOR OPERATION
MAP SENSOR
TEST ACTION APPLICABILITY
1 Turn the ignition off.
Attach a vacuum gauge to a manifold vacuum source.
NOTE: If the engine will not idle, maintain a constant engine speed above
idle.
Allow the engine to idle.
With the DRBIIIt, monitor the MAP sensor vacuum.
Compare the MAP vacuum value on the DRBIIItand the vacuum reading on the
vacuum gauge.
Are the vacuum readings within 1 inch of vacuum of each other?All
Ye s®The MAP sensor is operating normally.
Perform POWERTRAIN VERIFICATION TEST VER - 2.
No®Replace the MAP sensor.
Perform POWERTRAIN VERIFICATION TEST VER - 2.
233
DRIVEABILITY - GAS
Page 4028 of 4284
Symptom:
