Page 1449 of 4284

CHRYSLER VOYAGER 2001 Service Manual 8.7 SWITCHES C O M P O N E N T L O C A T I O N S 230 COMPONENT LOCATIONS 8.6 SENSORS (Continued)

Page 1450 of 4284

CHRYSLER VOYAGER 2001 Service Manual 9.0 CONNECTOR PINOUTS A/C COMPRESSOR CLUTCH - LT. GRAY 2 WAYCAV CIRCUIT FUNCTION 1 C3 18DB/YL A/C COMPRESSOR CLUTCH RELAY OUTPUT 2 Z153 18BK/GY GROUND A/C PRESSURE SENSOR - GRAY 4 WAYCAV CIRCUIT FUNCT

Page 1451 of 4284

CHRYSLER VOYAGER 2001 Service Manual BOOST PRESSURE SENSOR (DIESEL) - BLACK 4 WAYCAV CIRCUIT FUNCTION 1 K121 20DB BOOST PRESSURE SENSOR GROUND 2 K21 20DB/LG INTAKE AIR TEMPERATURE SENSOR SIGNAL 3 F851 18LB/PK SENSOR REFERENCE VOLTAGE B 4

Page 1452 of 4284

CHRYSLER VOYAGER 2001 Service Manual DATA LINK CONNECTOR - BLACK 16 WAYCAV CIRCUIT FUNCTION 1- - 2 D25 20WT/VT PCI BUS 3- - 4 Z11 18BK/LG GROUND 5 Z111 18BK/WT (EXCEPT BUILT-UP-EXPORT)GROUND 5 Z111 20BK/WT (BUILT-UP- EXPORT)GROUND 6 D20

Page 1453 of 4284

CHRYSLER VOYAGER 2001 Service Manual ENGINE CONTROL MODULE C1 (DIESEL) - BLACK 81 WAYCAV CIRCUIT FUNCTION 1 Z130 14BK/BR GROUND 2 Z131 14BK/DG GROUND 3 K20 14BR/GY GENERATOR FIELD CONTROL 4 K342 14BR/WT ECM/PCM RELAY OUTPUT 5 K342 14BR/W

Page 1454 of 4284

CHRYSLER VOYAGER 2001 Service Manual ENGINE CONTROL MODULE C1 (DIESEL) - BLACK 81 WAYCAV CIRCUIT FUNCTION 51 - - 52 K121 20DB BOOST PRESSURE SENSOR GROUND 53 - - 54 K957 20BK/OR MASS AIR FLOW SENSOR GROUND 55 N7 20DB/OR VEHICLE SPEED SEN

Page 1455 of 4284

CHRYSLER VOYAGER 2001 Service Manual ENGINE CONTROL MODULE C2 (DIESEL) - BLACK 40 WAYCAV CIRCUIT FUNCTION 82 - - 83 - - 84 - - 85 - - 86 T753 20DG/YL IGNITION SWITCH OUTPUT (START) 87 - - 88 K35 20GY/YL EGR SOLENOID CONTROL 89 K35 20GY/Y

Page 1456 of 4284

CHRYSLER VOYAGER 2001 Service Manual ENGINE OIL PRESSURE SENSOR (DIESEL) - BLACK 3 WAYCAV CIRCUIT FUNCTION 1 F855 20PK/YL SENSOR REFERENCE VOLTAGE A 2 G6 20VT/GY ENGINE OIL PRESSURE SENSOR SIGNAL 3 K936 20BR/YL ENGINE OIL PRESSURE SENSOR
