Page 609 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT TURN SIGNAL INDICATOR OPEN (HIGHLINE) When Monitored and Set Condition: LEFT TURN SIGNAL INDICATOR OPEN (HIGHLINE) When Monitored: With the ignition on. Set Condition: The BCM detects an

Page 610 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Message Center harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, probe the Fused B+ circuit in

Page 611 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT TURN SIGNAL INDICATOR OPEN (LOWLINE) When Monitored and Set Condition: LEFT TURN SIGNAL INDICATOR OPEN (LOWLINE) When Monitored: With the ignition on. Set Condition: The BCM detects an o

Page 612 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Instrument Cluster harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, probe the Fused B+ circuit

Page 613 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT TURN SIGNAL INDICATOR SHORT (HIGHLINE) When Monitored and Set Condition: LEFT TURN SIGNAL INDICATOR SHORT (HIGHLINE) When Monitored: With the ignition on. Set Condition: The BCM detects

Page 614 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Message Center harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, probe the Fused B+ circuit in

Page 615 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT TURN SIGNAL INDICATOR SHORT (LOWLINE) When Monitored and Set Condition: LEFT TURN SIGNAL INDICATOR SHORT (LOWLINE) When Monitored: With the ignition on. Set Condition: The BCM detects a

Page 616 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Instrument Cluster harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, probe the Fused B+ circuit
