8W-63 POWER SEATS
Component Page
Body Control Module............... 8Wa-63-4, 7
Diagnostic Junction Port.............. 8Wa-63-4
Driver Heated Seat Back............. 8Wa-63-7
Driver Heated Seat Cushion........... 8Wa-63-7
Driver Heated Seat Module........ 8Wa-63-3, 4, 7
Driver Power Seat Front Riser Motor.... 8Wa-63-2
Driver Power Seat Horizontal Motor..... 8Wa-63-2
Driver Power Seat Rear Riser Motor..... 8Wa-63-2
Driver Power Seat Recliner Motor...... 8Wa-63-2
Driver Power Seat Switch............. 8Wa-63-2
Fuse 22 (IPM).................... 8Wa-63-2, 4
G200....................... 8Wa-63-2, 4, 5, 7
G301........................... 8Wa-63-3, 8
Instrument Panel Switch Bank......... 8Wa-63-7
Intelligent Power Module........... 8Wa-63-2, 4
Memory Power Seat Switch........... 8Wa-63-5
Memory Seat Front Vertical Motor...... 8Wa-63-5
Memory Seat Front Vertical Position Sensor. 8Wa-63-6
Memory Seat Horizontal Motor......... 8Wa-63-5
Memory Seat Horizontal Position Sensor . 8Wa-63-6
Memory Seat Rear Vertical Motor....... 8Wa-63-5
Memory Seat Rear Vertical Position Sensor. 8Wa-63-6
Memory Seat Recliner Motor........... 8Wa-63-5
Memory Seat Recliner Position Sensor . . . 8Wa-63-6
Memory Seat Switch................. 8Wa-63-4
Memory Seat/Mirror Module....... 8Wa-63-4, 5, 6
Passenger Heated Seat Back........... 8Wa-63-8
Passenger Heated Seat Cushion........ 8Wa-63-8
Passenger Heated Seat Module......... 8Wa-63-8
Passenger Power Seat Front Riser Motor . 8Wa-63-3
Passenger Power Seat Horizontal Motor . . 8Wa-63-3
Passenger Power Seat Rear Riser Motor . . 8Wa-63-3
Passenger Power Seat Recliner Motor.... 8Wa-63-3
Passenger Power Seat Switch.......... 8Wa-63-3
Power Seat Circuit Breaker........ 8Wa-63-2, 3, 4
RG8W-63 POWER SEATS8Wa-63-1
