Page 2513 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT DOOR SPEAKER - BLACK/RED 6 WAY CAV CIRCUIT FUNCTION 1 X153 20DG/YL (HIGH LINE) LEFT FRONT INSTRUMENT PANEL SPEAKER (+) 2 X15 16GY/DG (HIGH LINE) AMPLIFIED SPEAKER GROUND 3 X155 20DG/LB (HIGH LINE

Page 2514 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT FRONT PARK/TURN SIGNAL LAMP (EXCEPT BUILT-UP-EXPORT) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 L61 18WT/LG LEFT FRONT TURN SIGNAL DRIVER 2 L77 18WT/BR FUSED PARK LAMP RELAY OUTPUT (LEFT) 3 Z377 18BK/B

Page 2515 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT HIGH BEAM LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Z343 16BR GROUND 1 Z343 16BR GROUND 2 L33 16GY LEFT HIGH BEAM DRIVER LEFT INSTRUMENT PANEL SPEAKER - BLACK 2 WAY CAV CIRCUIT

Page 2516 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT PARK LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Z343 16BR GROUND 2 L77 16BK FUSED PARK LAMP RELAY OUTPUT(LEFT) LEFT POWER MIRROR - BLACK 12 WAY CAV CIRCUIT FUNCTION 1 P171 20TN/Y

Page 2517 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT REAR PILLAR SPEAKER - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X157 20DG LEFT REAR PILLAR SPEAKER (+) 2 X151 20DG/WT LEFT REAR PILLAR SPEAKER (-) LEFT REAR READING LAMP (LUXURY) - GRAY 3 WAY CAV CIRCUI

Page 2518 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT REMOTE RADIO SWITCH - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X20 20RD/BK RADIO CONTROL MUX 2 X920 20RD/DB RADIO CONTROL MUX RETURN LEFT REPEATER LAMP (BUILT-UP-EXPORT) - GRAY 2 WAY CAV CIRCUIT FUNCTI

Page 2519 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT SLIDING DOOR CONTROL MODULE C2 (POWER SLIDING DOOR) - BLACK/RED 20 WAY CAV CIRCUIT FUNCTION 1 Q71 20TN/VT LEFT DOOR MOTOR HALL EFFECT SUPPLY 2- - 3 Q35 20OR/GY LEFT DOOR LOCK SENSE 4 Q55 20OR/BR

Page 2520 of 4284

CHRYSLER VOYAGER 2001 Service Manual LEFT SLIDING DOOR LOCK MOTOR/AJAR SWITCH (MANUAL SLIDING DOOR) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 P5 20BK/DB LEFT SLIDING DOOR UNLOCK DRIVER 2 P32 20BK/TN LEFT SLIDING DOOR LOCK DRIVER 3 G77 20BK/DG
