Page 4273 of 4284

CHRYSLER VOYAGER 2001 Service Manual C O N N E C T O R P I N O U T S 169 CONNECTOR PINOUTS

Page 4274 of 4284

CHRYSLER VOYAGER 2001 Service Manual FUSES (IPM)FUSE NO.AMPS FUSED CIRCUIT FUNCTION 1 20A INTERNAL FUSED B(+) 2 15A INTERNAL FUSED PARK LAMP RELAY OUTPUT 3 15A INTERNAL FUSED PARK LAMP RELAY OUTPUT 4 30A INTERNAL FUSED B(+) 5 20A F306 16

Page 4275 of 4284

CHRYSLER VOYAGER 2001 Service Manual POWERTRAIN CONTROL MODULE C1 - GRAY/BLACK 40 WAYCAV CIRCUIT FUNCTION 1- - 2 K18 16DB/OR (3.3L/3.8L) IGNITION COIL NO. 3 DRIVER 3 K17 16DB/TN IGNITION COIL NO. 2 DRIVER 4- - 5 V32 18VT/YL SPEED CONTROL

Page 4276 of 4284

CHRYSLER VOYAGER 2001 Service Manual POWERTRAIN CONTROL MODULE C2 - GRAY/GRAY 40 WAYCAV CIRCUIT FUNCTION 41 V37 18VT SPEED CONTROL SWITCH SIGNAL 42 C18 18LB/BR A/C PRESSURE SIGNAL 43 K900 18DB/DG SENSOR GROUND 44 F888 18BR/PK 8 VOLT SUPP

Page 4277 of 4284

CHRYSLER VOYAGER 2001 Service Manual SOLENOID/PRESSURE SWITCH ASSEMBLY (3.3L/3.8L) - BLACK 8 WAYCAV CIRCUIT FUNCTION 1 T47 18YL/DG 2-4 PRESSURE SWITCH SENSE 2 T50 18YL/TN LOW/REVERSE PRESSURE SWITCH SENSE 3 T9 18DG/TN OVERDRIVE PRESSURE

Page 4278 of 4284

CHRYSLER VOYAGER 2001 Service Manual TRANSMISSION CONTROL MODULE (3.3L/3.8L) - BLACK 60 WAYCAV CIRCUIT FUNCTION 1 T1 18DG/LB TRS T1 SENSE 2- - 3 T3 18DG/DB TRS T3 SENSE 4- - 5- - 6 K24 18BR/LB CRANKSHAFT POSITION SENSOR SIGNAL 7 D21 18WT

Page 4279 of 4284

CHRYSLER VOYAGER 2001 Service Manual TRANSMISSION RANGE SENSOR (3.3L/3.8L) - GRAY 10 WAYCAV CIRCUIT FUNCTION 1 T2 18DG/WT TRS REVERSE SENSE 2- - 3 T13 18DG/VT SPEED SENSOR GROUND 4 T54 18DG/OR TRANSMISSION TEMPERATURE SENSOR SIGNAL 5 T41

Page 4280 of 4284

CHRYSLER VOYAGER 2001 Service Manual NOTES 176
