Page 689 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: HORIZONTAL SENSOR OUT OF RANGE HIGH When Monitored and Set Condition: HORIZONTAL SENSOR OUT OF RANGE HIGH When Monitored: Continuously when the PCI bus is active. Set Condition: This conditio

Page 690 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Disconnect the Driver Power Seat Horizontal Position Sensor connector. Measure the voltage between Seat Sensor 5 volt supply circuit and ground. Turn ignition on. Is the vo

Page 691 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 8 Turn ignition off. Disconnect the Memory Seat Mirror Module C2 connector. Disconnect the Driver Power Seat Horizontal Position Sensor connector. Measure the resistance of t

Page 692 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: HORIZONTAL SENSOR OUT OF RANGE LOW When Monitored and Set Condition: HORIZONTAL SENSOR OUT OF RANGE LOW When Monitored: Continuously when the PCI bus is active. Set Condition: This condition

Page 693 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn ignition off. Disconnect the Driver Power Seat Horizontal Position Sensor Connector. Disconnect the Memory Seat Mirror Module C1 Connector. Measure the resistance of t

Page 694 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 8 Turn ignition off. Disconnect the Memory Seat Mirror Module C2 connector. Disconnect the Driver Power Seat Horizontal Position Sensor connector. Measure the resistance of t

Page 695 of 4284

CHRYSLER VOYAGER 2001 Service Manual Symptom: LEFT MIRROR HORIZONTAL SENSOR OUT OF RANGE HIGH When Monitored and Set Condition: LEFT MIRROR HORIZONTAL SENSOR OUT OF RANGE HIGH When Monitored: Continuously when the PCI bus is active Set C

Page 696 of 4284

CHRYSLER VOYAGER 2001 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Left Power Mirror connector. Measure the resistance of the Left Mirror Sensor Ground circuit in the harness connector to ground. Is th
