Page 3561 of 5621

INFINITI M35 2006 Factory Service Manual GW-42 POWER WINDOW SYSTEM Revision: 2006 January2006 M35/M45 Encoder Circuit Check (Driver Side) NIS0021Y 1. CHECK POWER WINDOW MOTOR (FRONT DRIVER SIDE) POWER SUPPLY 1. Turn ignition switch ON. 2. Ch

Page 3562 of 5621

INFINITI M35 2006 Factory Service Manual POWER WINDOW SYSTEM GW-43 C D E F G H J K L MA B GW Revision: 2006 January2006 M35/M45 3. CHECK GROUND CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect power window motor (front driver side) connect

Page 3563 of 5621

INFINITI M35 2006 Factory Service Manual GW-44 POWER WINDOW SYSTEM Revision: 2006 January2006 M35/M45 5. CHECK ENCODER SIGNAL 1. Connect power window motor (front driver side) connector. 2. Turn ignition switch ON. 3. Check signal between po

Page 3564 of 5621

INFINITI M35 2006 Factory Service Manual POWER WINDOW SYSTEM GW-45 C D E F G H J K L MA B GW Revision: 2006 January2006 M35/M45 6. CHECK HARNESS CONTINUITY 3 1. Turn ignition switch OFF. 2. Disconnect power window main switch and power windo

Page 3565 of 5621

INFINITI M35 2006 Factory Service Manual GW-46 POWER WINDOW SYSTEM Revision: 2006 January2006 M35/M45 2. CHECK HARNESS CONTINUITY 1 1. Turn ignition switch OFF. 2. Disconnect power window sub-switch (front passenger side) and power

Page 3566 of 5621

INFINITI M35 2006 Factory Service Manual POWER WINDOW SYSTEM GW-47 C D E F G H J K L MA B GW Revision: 2006 January2006 M35/M45 4. CHECK HARNESS CONTINUITY 2 1. Disconnect power window sub-switch (front passenger side) connector. 2. Check c

Page 3567 of 5621

INFINITI M35 2006 Factory Service Manual GW-48 POWER WINDOW SYSTEM Revision: 2006 January2006 M35/M45 6. CHECK HARNESS CONTINUITY 3 1. Turn ignition switch OFF. 2. Disconnect power window sub-switch (front passenger side) and power

Page 3568 of 5621

INFINITI M35 2006 Factory Service Manual POWER WINDOW SYSTEM GW-49 C D E F G H J K L MA B GW Revision: 2006 January2006 M35/M45 2. CHECK HARNESS CONTINUITY 1 1. Turn ignition switch OFF. 2. Disconnect power window sub-switch (rear LH or RH)
