Page 2665 of 5621

INFINITI M35 2006 Factory Service Manual EC-1122 [VK45DE] DTC P0441 EVAP CONTROL SYSTEM Revision: 2006 January2006 M35/M45 4. CHECK EVAP PURGE LINE 1. Turn ignition switch OFF. 2. Check EVAP purge line for improper connection or disconnectio

Page 2666 of 5621

INFINITI M35 2006 Factory Service Manual DTC P0441 EVAP CONTROL SYSTEM EC-1123 [VK45DE] C D E F G H I J K L MA EC Revision: 2006 January2006 M35/M45 8. CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR CONNECTOR 1. Disconnect EVAP control system pre

Page 2667 of 5621

INFINITI M35 2006 Factory Service Manual EC-1124 [VK45DE] DTC P0442 EVAP CONTROL SYSTEM Revision: 2006 January2006 M35/M45 DTC P0442 EVAP CONTROL SYSTEMPFP:14950 On Board Diagnosis LogicNBS005H1 This diagnosis detects leaks in the EVAP purge

Page 2668 of 5621

INFINITI M35 2006 Factory Service Manual DTC P0442 EVAP CONTROL SYSTEM EC-1125 [VK45DE] C D E F G H I J K L MA EC Revision: 2006 January2006 M35/M45 CAUTION: Use only a genuine NISSAN fuel filler cap as a replacement. If an incorrect fu

Page 2669 of 5621

INFINITI M35 2006 Factory Service Manual EC-1126 [VK45DE] DTC P0442 EVAP CONTROL SYSTEM Revision: 2006 January2006 M35/M45 WITH GST NOTE: Be sure to read the explanation of EC-775, " Driving Pattern" before driving vehicle. 1. Star

Page 2670 of 5621

INFINITI M35 2006 Factory Service Manual DTC P0442 EVAP CONTROL SYSTEM EC-1127 [VK45DE] C D E F G H I J K L MA EC Revision: 2006 January2006 M35/M45 5. INSTALL THE PRESSURE PUMP To locate the EVAP leak, install EVAP service port adapter and

Page 2671 of 5621

INFINITI M35 2006 Factory Service Manual EC-1128 [VK45DE] DTC P0442 EVAP CONTROL SYSTEM Revision: 2006 January2006 M35/M45 7. CHECK FOR EVAP LEAK Without CONSULT-II 1. Turn ignition switch OFF. 2. Apply 12 volts DC to EVAP canister v

Page 2672 of 5621

INFINITI M35 2006 Factory Service Manual DTC P0442 EVAP CONTROL SYSTEM EC-1129 [VK45DE] C D E F G H I J K L MA EC Revision: 2006 January2006 M35/M45 10. CHECK EVAP CANISTER Weigh the EVAP canister with the EVAP canister vent control valve an
