Page 4529 of 5621

INFINITI M35 2006 Factory Service Manual LT-102 HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - Revision: 2006 January2006 M35/M45 Headlamp High Beam Does Not Illuminate (Both Sides)NKS003PL 1. CHECK COMBINATION SWITCH INPUT SIGNAL With CONS

Page 4530 of 5621

INFINITI M35 2006 Factory Service Manual HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - LT-103 C D E F G H I J L MA B LT Revision: 2006 January2006 M35/M45 4. CHECK HEADLAMP INPUT SIGNAL With CONSULT-II 1. Turn ignition switch OFF. 2. Discon

Page 4531 of 5621

INFINITI M35 2006 Factory Service Manual LT-104 HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - Revision: 2006 January2006 M35/M45 6. CHECK HEADLAMP (RH SIDE) GROUND 1. Remove daytime light relay. 2. Check continuity between front headlam

Page 4532 of 5621

INFINITI M35 2006 Factory Service Manual HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - LT-105 C D E F G H I J L MA B LT Revision: 2006 January2006 M35/M45 8. CHECK CIRCUIT BETWEEN IPDM E/R AND FRONT COMBINATION LAMP 1. Turn ignition switch

Page 4533 of 5621

INFINITI M35 2006 Factory Service Manual LT-106 HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - Revision: 2006 January2006 M35/M45 3. CHECK CONTINUITY BETWEEN IPDM E/R AND FRONT COMBINATION LAMP 1. Ignition switch OFF. 2. Disconnect IPDM E/R

Page 4534 of 5621

INFINITI M35 2006 Factory Service Manual HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - LT-107 C D E F G H I J L MA B LT Revision: 2006 January2006 M35/M45 6. CHECK DAYTIME RELAY Check continuity between terminal 3 and 4. OK >> Check connec

Page 4535 of 5621

INFINITI M35 2006 Factory Service Manual LT-108 HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - Revision: 2006 January2006 M35/M45 3. CHECK HEADLAMP GROUND 1. Turn ignition switch OFF. 2. Check continuity headlamp harness connector E54

Page 4536 of 5621

INFINITI M35 2006 Factory Service Manual HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM - LT-109 C D E F G H I J L MA B LT Revision: 2006 January2006 M35/M45 Headlamp Low Beam Does Not Illuminate (Both Sides)NKS003PO 1. CHECK COMBINATION SWITC
