Page 3025 of 5621

INFINITI M35 2006 Factory Service Manual EI-20 FENDER PROTECTOR Revision: 2006 January2006 M35/M45 FENDER PROTECTORPFP:63840 Removal and InstallationNIS0024J REMOVAL 1. Remove rear end screw of fender protector (rear). 2. Remove clips of fen

Page 3026 of 5621

INFINITI M35 2006 Factory Service Manual FENDER PROTECTOR EI-21 C D E F G H J K L MA B EI Revision: 2006 January2006 M35/M45 Rear Wheel House ProtectorNIS0024K REMOVAL AND INSTALLATION REMOVAL 1. Remove screw of rear portion wheel house pro

Page 3027 of 5621

INFINITI M35 2006 Factory Service Manual EI-22 CENTER MUD GUARD Revision: 2006 January2006 M35/M45 CENTER MUD GUARDPFP:76850 Removal and InstallationNIS0024L REMOVAL 1. Remove screw and nuts of wind deflector and remove wind deflect

Page 3028 of 5621

INFINITI M35 2006 Factory Service Manual FLOOR SIDE FAIRING EI-23 C D E F G H J K L MA B EI Revision: 2006 January2006 M35/M45 FLOOR SIDE FAIRINGPFP:74586 Removal and Installation of Under Cover (for V6 Engine Models)NIS0024M Removal and Ins

Page 3029 of 5621

INFINITI M35 2006 Factory Service Manual EI-24 FLOOR SIDE FAIRING Revision: 2006 January2006 M35/M45 FRONT UNDER COVER (REAR) Removal 1. Remove front under cover (rear) mounting bolts. 2. Remove front under cover (rear). Installation Install

Page 3030 of 5621

INFINITI M35 2006 Factory Service Manual ROOF SIDE MOLDING EI-25 C D E F G H J K L MA B EI Revision: 2006 January2006 M35/M45 ROOF SIDE MOLDINGPFP:73854 Removal and InstallationNIS0024O REMOVAL 1. Apply protective tape around roof side moldi

Page 3031 of 5621

INFINITI M35 2006 Factory Service Manual EI-26 ROOF SIDE MOLDING Revision: 2006 January2006 M35/M45 INSTALLATION 1. Place roof side molding on roof groove, and then insert the end into front fender. 2. Align roof side molding clips (molding

Page 3032 of 5621

INFINITI M35 2006 Factory Service Manual DOOR SASH MOLDING EI-27 C D E F G H J K L MA B EI Revision: 2006 January2006 M35/M45 DOOR SASH MOLDINGPFP:80282 Removal and InstallationNIS0024P FRONT DOOR SASH MOLDING Removal 1. Remove front door we
