Page 4769 of 5621

INFINITI M35 2006 Factory Service Manual LU-26 [VK45DE] ENGINE OIL Revision: 2006 January2006 M35/M45 ENGINE OILPFP:KLA92 InspectionNBS004QC ENGINE OIL LEVEL NOTE: Before starting engine, put vehicle horizontally and check the engine oil lev

Page 4770 of 5621

INFINITI M35 2006 Factory Service Manual ENGINE OIL LU-27 [VK45DE] C D E F G H I J K L MA LU Revision: 2006 January2006 M35/M45 4. Install oil pressure gauge and hose (SST). 5. Start engine and warm it up to normal operating temperature. 6.

Page 4771 of 5621

INFINITI M35 2006 Factory Service Manual LU-28 [VK45DE] ENGINE OIL Revision: 2006 January2006 M35/M45 Changing Engine OilNBS004QD WAR NING : Be careful not to burn yourself, as engine oil may be hot. Prolonged and repeated contact with

Page 4772 of 5621

INFINITI M35 2006 Factory Service Manual OIL FILTER LU-29 [VK45DE] C D E F G H I J K L MA LU Revision: 2006 January2006 M35/M45 OIL FILTERPFP:15208 Removal and InstallationNBS004QE REMOVAL 1. Remove front engine undercover with power tool. 2

Page 4773 of 5621

INFINITI M35 2006 Factory Service Manual LU-30 [VK45DE] OIL PUMP Revision: 2006 January2006 M35/M45 OIL PUMPPFP:15010 ComponentsNBS004QF Removal and InstallationNBS004QG REMOVAL 1. Remove engine assembly from vehicle. Refer to EM-244, "E

Page 4774 of 5621

INFINITI M35 2006 Factory Service Manual OIL PUMP LU-31 [VK45DE] C D E F G H I J K L MA LU Revision: 2006 January2006 M35/M45 3. Install in the reverse order of removal after this step. INSPECTION AFTER INSTALLATION 1. Check the engine oil l

Page 4775 of 5621

INFINITI M35 2006 Factory Service Manual LU-32 [VK45DE] OIL PUMP Revision: 2006 January2006 M35/M45 OIL PUMP BODY INNER DIAMETER –Measure the inner diameter of oil pump body with inside micrometer. (Position 6) OIL PUMP INNER DIAM

Page 4776 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) LU-33 [VK45DE] C D E F G H I J K L MA LU Revision: 2006 January2006 M35/M45 SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030 Standard and LimitNBS004QI ENGINE OIL P
