Page 3977 of 5621

INFINITI M35 2006 Factory Service Manual LAN-308 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect BCM connector. 2. Check resistance between BCM harness connector terminals. OK or N

Page 3978 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-309 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect steering angle sensor connector. 2. Check resistance b

Page 3979 of 5621

INFINITI M35 2006 Factory Service Manual LAN-310 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect unified meter and A/C amp. connector. 2. Check resistance between unified meter and

Page 3980 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-311 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR OPEN CIRCUIT Check resistance between data link connector terminals. OK or NG OK >>

Page 3981 of 5621

INFINITI M35 2006 Factory Service Manual LAN-312 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect driver seat control unit connector. 2. Check resistance between driver seat con

Page 3982 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-313 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect IPDM E/R connector. 2. Check resistance between IPDM

Page 3983 of 5621

INFINITI M35 2006 Factory Service Manual LAN-314 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR SHORT CIRCUIT 1. Disconnect following connectors. –ECM connector –Harness connector M72 –BCM connector

Page 3984 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-315 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 5. CHECK HARNESS FOR SHORT CIRCUIT Check continuity between A/T assembly harness connector termi-
