Rear Display UnitNKS004BX
: Vehicle front
REMOVAL
1. Insert cloth-covered driver into gaps between rear display cover
(1) and headlining, and remove rear display cover (1).
2. Remove nuts (A) and plastic nuts (B).
3. Disconnect connector, and remove rear display unit (2).
INSTALLATION
Installation is the reverse order if removal.
Multifunction SwitchNKS004BY
REMOVAL
1. Remove instrument panel finisher B and C. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screw (A).
3. Disengage tabs (B) and connector to separate multifunction
switch (1) from instrument panel.
INSTALLATION
Installation is the reverse order of removal.
Preset SwitchNKS004BZ
REMOVAL
1. Remove cluster lid C. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
SKIB4354E
SKIB4355E
SKIB4276E
Page 914 of 5621
REMOVAL AND INSTALLATION
AV-293
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
2. Disengage tabs (A) to separate preset switch (1) from cluster lid
C (2).
INSTALLATION
Installation is the reverse order of removal.
Steering SwitchNKS004C0
REMOVAL
1. Refer to SRS-38, "DRIVER AIR BAG MODULE" .
INSTALLATION
Installation is the reverse order of removal.
SKIB4277E
1. Air bag 2. Steering switch 3. Screw
4. Spring 5. Bracket 6. Screw
SKIB4278E
Page 915 of 5621
AV-294
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2006 January2006 M35/M45
Rear Control SwitchNKS004C1
REMOVAL
1. Remove tray box from armrest. Refer to SE-167, "Removal and Installation" .
2. Remove screws (A).
3. Disconnect connector (1) and disengage tabs (A) to separate
rear control switch (2).
INSTALLATION
Installation is the reverse order of removal.
Video DistributorNKS004C2
REMOVAL
1. Remove multifunction switch. Refer to AV-292, "Multifunction Switch" .
2. Remove audio unit assembly. Refer to AV-285, "
Audio Unit" .
3. Remove screws (A).
4. Disconnect connector and remove video distributor (1).
5. Remove screws (A) and remove bracket (1).
SKIB4300E
SKIB4301E
SKIB4392E
SKIB4393E
Page 916 of 5621
REMOVAL AND INSTALLATION
AV-295
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
INSTALLATION
Installation is the reverse order of removal.
DVD PlayerNKS004C3
REMOVAL
1. Remove cup holder. Refer to IP-11, "Removal and Installation of Instrument Panel & Pad" .
2. Disconnect sub harness connector.
3. Remove sub harness connectors (A) from bracket.
4. Remove metal clips (A) and 8 pawls. Then remove DVD player
cover (1).
5. Remove screws (B) and remove DVD player (2).
6. Remove screws (A) and remove brackets (1).
INSTALLATION
Installation is the reverse order of removal.
PKIC0931E
PKIC0932E
SKIB4358E
Page 917 of 5621
![INFINITI M35 2006 Factory Service Manual AV-296
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2006 January2006 M35/M45
Auxiliary Input JacksNKS004C4
REMOVAL
1. Remove center console rear finisher. Refer to IP-10, " INFINITI M35 2006 Factory Service Manual AV-296
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2006 January2006 M35/M45
Auxiliary Input JacksNKS004C4
REMOVAL
1. Remove center console rear finisher. Refer to IP-10, "](/manual-img/42/57023/w960_57023-916.png)
AV-296
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2006 January2006 M35/M45
Auxiliary Input JacksNKS004C4
REMOVAL
1. Remove center console rear finisher. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screws (A) and disconnect connector. Remove auxil-
iary input jacks (1) from center console rear finisher.
INSTALLATION
Installation is the reverse order of removal.
Headphone AmpNKS004C5
: Vehicle front
REMOVAL
1. Remove rear display cover. Refer to IP-19, "Disassembly and Assembly" .
2. Remove nuts (A) and disconnect connector. Remove head-
phone amp (1).
INSTALLATION
Installation is the reverse order of removal.
MicrophoneNKS004C6
REMOVAL
1. Remove front pillar garnish. Refer to EI-37, "BODY SIDE TRIM" .
2. Remove sun-visor and sun-visor holder. Refer to EI-52, "
HEADLINING" .
3. Remove dual-sunvisor. Refer to EI-52, "
HEADLINING" .
4. Remove assistance grip (front). Refer to EI-52, "
HEADLINING" .
5. Bear down headlining assembly (front) to obtain work space between headlining assembly and vehicle.
6. Disengage tabs (A) and connector to separate microphone unit
(1).
SKIB4351E
SKIB4353E
SKIB4302E
Page 918 of 5621
REMOVAL AND INSTALLATION
AV-297
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
INSTALLATION
Installation is the reverse order of removal.
GPS AntennaNKS004C7
REMOVAL
1. Remove NAVI control unit. Refer to AV- 2 9 0 , "AV (NAVI) Control Unit" .
2. Remove upper ventilator grille. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
3. Remove clips (A) and remove antenna feeder (1) from instru-
ment panel and pad.
4. Remove screw (A) and remove GPS antenna (1).
INSTALLATION
Installation is the reverse order of removal.
SKIB4365E
SKIB4366E
Page 919 of 5621
AV-298
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2006 January2006 M35/M45
Camera Control UnitNKS004C8
REMOVAL
1. Remove trunk side finisher (RH). Refer to EI-56, "Removal and Installation for Trunk Room Trim" .
2. Remove screws (A) and disconnect connector, and remove rear
view camera control unit (1).
3. Remove screws (A) and remove bracket (1).
INSTALLATION
Installation is the reverse order of removal.
Rear View CameraNKS004C9
REMOVAL
1. Remove trunk lid finisher inner. Refer to EI-56, "TRUNK ROOM TRIM & TRUNK LID FINISHER" .
2. Remove screws attaching camera and camera bracket.
3. Remove connector and connector clip.
4. Remove camera bracket (1) while pushing right direction of
vehicle.
INSTALLATION
1. Install rear view camera and camera bracket while pressing to trunk room side.
2. Install connector and connector clip.
3. Install trunk lid finisher inner.
SKIB4398E
SKIB4399E
SKIB5010E
Page 920 of 5621
REMOVAL AND INSTALLATION
AV-299
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
Steering Angle SensorNKS004CA
REMOVAL
1. Remove combination switch. Refer to SRS-40, "SPIRAL CABLE" .
2. Remove screws (A) and remove connector mount screw (B).
3. Remove steering angle sensor (1) from combination switch (2).
INSTALLATION
Installation is the reverse order of removal.
CAUTION:
Insert the projection area, and install steering wheel angle sensor while fitting adjusting the triangle
marks (Larger mark should be upward.).
SKIB4352E
