Page 329 of 5621

INFINITI M35 2006 Factory Service Manual AT-250 ON-VEHICLE SERVICE Revision: 2006 January2006 M35/M45 13. Remove parking gear from output shaft. 14. Remove seal rings from output shaft. 15. Remove needle bearing (1) from rear extension. 16.

Page 330 of 5621

INFINITI M35 2006 Factory Service Manual ON-VEHICLE SERVICE AT-251 D E F G H I J K L MA B AT Revision: 2006 January2006 M35/M45 18. Remove return spring (1) from parking pawl (2). 19. Remove rear oil seal from rear extension. CAUTION: Be car

Page 331 of 5621

INFINITI M35 2006 Factory Service Manual AT-252 ON-VEHICLE SERVICE Revision: 2006 January2006 M35/M45 Installation CAUTION: After completing installation, check A/T fluid leakage, A/T fluid level and A/T position. Refer to AT- 1 3 , "Che

Page 332 of 5621

INFINITI M35 2006 Factory Service Manual ON-VEHICLE SERVICE AT-253 D E F G H I J K L MA B AT Revision: 2006 January2006 M35/M45 5. Install bearing (1) to rear extension. CAUTION: Apply petroleum jelly to needle bearing. Refer to GI section t

Page 333 of 5621

INFINITI M35 2006 Factory Service Manual AT-254 ON-VEHICLE SERVICE Revision: 2006 January2006 M35/M45 10. Apply recommended sealant (Genuine Anaerobic Liquid Gasket or equivalent. Refer to GI-48, " Recommended Chemical Prod- ucts

Page 334 of 5621

INFINITI M35 2006 Factory Service Manual ON-VEHICLE SERVICE AT-255 D E F G H I J K L MA B AT Revision: 2006 January2006 M35/M45 REMOVAL AND INSTALLATION (VK45DE MODELS) Components Removal 1. Drain ATF through drain plug. 2. Remove exhaust fr

Page 335 of 5621

INFINITI M35 2006 Factory Service Manual AT-256 ON-VEHICLE SERVICE Revision: 2006 January2006 M35/M45 8. Remove tightening bolts (1) for output shaft & companion flange complement and transmission case. : Bolt (10) Self-sealing bolts (2) 9.

Page 336 of 5621

INFINITI M35 2006 Factory Service Manual ON-VEHICLE SERVICE AT-257 D E F G H I J K L MA B AT Revision: 2006 January2006 M35/M45 13. Remove return spring (1) from parking pawl (2). Inspection If the contact surface on parking actuator support
