REAR WINDOW DEFOGGER
Revision: 2006 January2006 M35/M45
CONSULT-II Inspection ProcedureNIS0022O
CAUTION:
If  CONSULT-II  is  used  with  no  connection  of  CONSULT-II  CONVERTER,  malfunctions

Page 3602 of 5621

INFINITI M35 2006  Factory Service Manual REAR WINDOW DEFOGGER
GW-83
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 January2006 M35/M45
7. Select  diagnosis  mode,“DATA  MONITOR”  and  “ACTIVE  TEST”
are available.
DATA MONITOR
Display Item

Page 3603 of 5621

INFINITI M35 2006  Factory Service Manual GW-84
REAR WINDOW DEFOGGER
Revision: 2006 January2006 M35/M45
Work FlowNIS0022P
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to GW-73, "
System Desc

Page 3604 of 5621

INFINITI M35 2006  Factory Service Manual REAR WINDOW DEFOGGER
GW-85
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 January2006 M35/M45
BCM Power Supply and Ground Circuit CheckNIS0022R
First  perform  the  “SELF-DIAG  RESULTS”  in  “BCM”

Page 3605 of 5621

INFINITI M35 2006  Factory Service Manual GW-86
REAR WINDOW DEFOGGER
Revision: 2006 January2006 M35/M45
Rear Window Defogger Switch Circuit CheckNIS0022S
1. CHECK REAR WINDOW DEFOGGER SWITCH OPERATION
 With CONSULT-II
Check (“REAR DEF SW

Page 3606 of 5621

INFINITI M35 2006  Factory Service Manual REAR WINDOW DEFOGGER
GW-87
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 January2006 M35/M45
3. CHECK REAR WINDOW DEFOGGER RELAY
Check rear window defogger relay.
OK or NG
OK >> GO TO 4.
NG >> Replace rear

Page 3607 of 5621

INFINITI M35 2006  Factory Service Manual GW-88
REAR WINDOW DEFOGGER
Revision: 2006 January2006 M35/M45
6. CHECK REAR WINDOW DEFOGGER RELAY OUTPUT SIGNAL
1. Connect IPDM E/R connector and rear window defogger relay.
2. Turn ignition switch ON

Page 3608 of 5621

INFINITI M35 2006  Factory Service Manual REAR WINDOW DEFOGGER
GW-89
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 January2006 M35/M45
3. CHECK HARNESS CONTINUITY 1
1. Turn ignition switch OFF.
2. Disconnect condenser and rear window defogger conn
