Page 1049 of 5621

INFINITI M35 2006 Factory Service Manual BL-110 INTELLIGENT KEY SYSTEM Revision: 2006 January2006 M35/M45 Check Outside Key Antenna (Trunk Room)NIS001XV 1. CHECK OUTSIDE KEY ANTENNA FUNCTION With CONSULT-II 1. Check the operation with (“A

Page 1050 of 5621

INFINITI M35 2006 Factory Service Manual INTELLIGENT KEY SYSTEM BL-111 C D E F G H J K L MA B BL Revision: 2006 January2006 M35/M45 3. CHECK OUTSIDE KEY ANTENNA CIRCUIT 1. Disconnect Intelligent Key unit and outside key antenna (trunk room)

Page 1051 of 5621

INFINITI M35 2006 Factory Service Manual BL-112 INTELLIGENT KEY SYSTEM Revision: 2006 January2006 M35/M45 Check Inside Key AntennaNIS001XW 1. CHECK INSIDE KEY ANTENNA FUNCTION With CONSULT-II 1. Check the operation with (“ANTENNA”) in t

Page 1052 of 5621

INFINITI M35 2006 Factory Service Manual INTELLIGENT KEY SYSTEM BL-113 C D E F G H J K L MA B BL Revision: 2006 January2006 M35/M45 3. CHECK INSIDE KEY ANTENNA CIRCUIT 1. Disconnect Intelligent Key unit and inside key antenna connector. 2. C

Page 1053 of 5621

INFINITI M35 2006 Factory Service Manual BL-114 INTELLIGENT KEY SYSTEM Revision: 2006 January2006 M35/M45 4. CHECK INDE KEY ANTENNA INPUT SIGNAL 2 1. Replace inside key antenna. (New antenna or other antenna) 2. Connect Intelligent Key unit

Page 1054 of 5621

INFINITI M35 2006 Factory Service Manual INTELLIGENT KEY SYSTEM BL-115 C D E F G H J K L MA B BL Revision: 2006 January2006 M35/M45 Check Park Position SwitchNIS001XX 1. CHECK PARK POSITION SWITCH INPUT SIGNAL With CONSULT-II Check (“P RA

Page 1055 of 5621

INFINITI M35 2006 Factory Service Manual BL-116 INTELLIGENT KEY SYSTEM Revision: 2006 January2006 M35/M45 3. CHECK PARK POSITION SWITCH 1. Disconnect A/T device connector. 2. Check A/T device. OK or NG OK >> GO TO 4. NG >> Check A/T shift

Page 1056 of 5621

INFINITI M35 2006 Factory Service Manual INTELLIGENT KEY SYSTEM BL-117 C D E F G H J K L MA B BL Revision: 2006 January2006 M35/M45 Check Ignition Switch PositionNIS001XY 1. CHECK IGNITION POWER SUPPLY Check voltage between Intelligent Key u
