INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
Revision: 2006 January2006 M35/M45
2. CHECK HARNESS CONTINUITY 1
1. Disconnect Intelligent Key unit connector.
2. Check continuity between Intelligent Key unit connector and steering lock unit connector.
3. Check continuity between Intelligent Key unit connector and
ground.
OK or NG
OK >> Check the condition of harness and connector.
NG >> Repair or replace harness.
3. CHECK STEERING LOCK UNIT SIGNAL
1. Connect steering lock unit connector.
2. Check voltage between steering lock unit connector and ground.
OK or NG
OK >> Replace steering lock unit.
NG >> GO TO 4.
AB
Continuity
Intelligent Key
unit connectorTe r m i n a l Steering lock unit
connectorTerminal
M32 15 M35 7 Yes
A
GroundContinuity
Intelligent Key
unit connectorTerminal
M32 15 No
PIIB6224E
Te r m i n a l s
ConditionVoltage (V)
(Approx.) (+)
(–)
Steering lock
unit connectorTerminal
M35 4 GroundWhen turn igni-
tion switch to
START with
Intelligent Key in
the carBattery voltage
0
Battery voltage
PIIB6225E
Page 1098 of 5621

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
BL-159
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 January2006 M35/M45
4. CHECK HARNESS CONTINUITY 2
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key unit and steering lock unit connector.
3. Check continuity between Intelligent Key unit connector and steering lock unit connector.
4. Check continuity between Intelligent Key unit connector and
ground.
OK or NG
OK >> Check the condition of harness and connector. If it is OK, check the self-diagnosis results using
CONSULT-II again.
NG >> Repair or replace harness.
DTC B2551 STEERING LOCK UNITNIS001YO
DIAGNOSIS DESCRIPTION
Though the communication between the Intelligent Key unit and the steering lock unit is normal, when the
steering lock/unlock is not normal, B2551 steering lock unit malfunction judges that it is the malfunction and
displays the DTC (Diagnostic Trouble Code)
TERMINALS AND REFERENCE VALUE
Intelligent Key Unit
AB
Continuity
Intelligent Key
unit connectorTerminal Steering lock unit
connectorTerminal
M32 16 M35 4 Yes
A
GroundContinuity
Intelligent Key unit
connectorTerminal
M32 16 No
PIIB6226E
Te r m i -
nal
No.Wire
colorItemCondition
Voltage (V)
(Approx.) Push-
button
ignition
switch
positionOperation or conditions
17 OSteering lock unit con-
dition signal-1LOCK Steering lock: Lock 0
ACC
Steering lock: UnlockBattery voltage
ON Battery voltage
18 L/YSteering lock unit con-
dition signal-2LOCK Steering lock: Lock Battery voltage
ACC
Steering lock: Unlock0
ON 0
71 LG PDU signalLOCK Steering lock: Lock Battery voltage
ACC Steering lock: Unlocked moment 0
Page 1099 of 5621

BL-160
INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
Revision: 2006 January2006 M35/M45
PDU (Power Distribution Unit)
SELF-DIAGNOSTIC LOGIC
DIAGNOSTIC PROCEDURE
1. CHECK STEERING LOCK SIGNAL
Check voltage between power distribution unit connector and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 4.
Te r -
minal
No.Wire
colorItemCondition
Voltage (V)
(Approx.) Push-
button
ignition
switch
positionOperation or conditions
3GRSteering lock unit
power sourceLOCKPush-button ignition switch is pressed
under the condition that Intelligent Key is
in the vehicle or Intelligent Key is inserted0
Battery voltage 0
— Any condition other than above 0
7LGSteering lock control
signal-2—Push-button ignition switch is pressed
under the condition that Intelligent Key is
in the vehicle or Intelligent Key is insertedBattery voltage
LOCKPower supply position is in LOCK posi-
tion
(Steering lock activated)Battery voltage
0 Battery volt-
age
(Battery voltage is detected when
activating the steering lock)
DTC Self-diagnosis name DTC detecting condition Possible causes
B2551STEERING LOCK
UNITThough the communication between the
Intelligent Key and the steering lock unit
is normal, the steering lock unit condition
signal is NG
Harness and connector
(Open or shorted in the circuit between the
units)
Steering lock unit
Te r m i n a l s
ConditionVoltage (V)
(Approx.) (+)
(–)
Power distribu-
tion unit connectorTerminal
M306
GroundWhen turn ignition
switch to START
with Intelligent Key
in the carBattery voltage
7
6
When turn ignition
switch to OFF
(steering lock
operates) Battery voltage
0
Battery voltage 7
PIIB6227E
Page 1100 of 5621

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
BL-161
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 January2006 M35/M45
2. CHECK POWER DISTRIBUTION UNIT POWER SUPPLY
Check voltage between power distribution unit connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Check if "B2558 PDU" is displayed on self-diagnosis results. If it is displayed, first perform the
diagnosis.
3. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect power distribution unit and steering lock unit connector.
3. Check continuity between power distribution unit connector and steering lock unit connector.
4. Check continuity between power distribution unit connector and
ground.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace harness.
Terminals
ConditionVoltage (V)
(Approx.) (+)
(–)
Power distribution
unit connectorTerminal
M30 3 GroundWhen turn ignition
switch to OFF
(steering lock oper-
ates)Battery voltage
0
Battery voltage
Ignition switch OFF 0
PIIB6228E
AB
Continuity
P o w e r d i s t r i b u t i o n
unit connectorTerminal Steering lock unit
connectorTerminal
M30 3 M35 1 Yes
A
GroundContinuity
Power distribution
unit connectorTerminal
M30 3 No
PIIB6229E
Page 1101 of 5621

BL-162
INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
Revision: 2006 January2006 M35/M45
4. CHECK COMMUNICATION CIRCUIT 1
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key unit and power distribution unit connector.
3. Check continuity between Intelligent Key unit connector and power distribution unit connector.
4. Check continuity between Intelligent Key unit connector and
ground.
OK or NG
OK >> Check the condition of harness and connector.
NG >> Repair or replace harness.
5. CHECK SIGNAL CIRCUIT
1. Connect steering lock unit and power distribution unit connector.
2. Check continuity between steering lock unit connector and ground.
OK or NG
OK >> Replace steering lock unit.
NG >> GO TO 6.
AB
Continuity
Intelligent Key
unit connectorTe r m i n a lPower distribution
unit connectorTerminal
M3346
M306
Ye s
71 7
A
GroundContinuity
Intelligent Key
unit connectorTerminal
M3346
No
71
PIIB6230E
Terminals
ConditionVoltage (V)
(Approx.) (+)
(–)
Steering lock
unit connectorTerminal
M353
GroundWhen turn igni-
tion switch to
START with
Intelligent Key
in the carBattery voltage
80
3
Ignition switch:
OFF0
8 Battery voltage
PIIB6231E
Page 1102 of 5621

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
BL-163
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 January2006 M35/M45
6. CHECK COMMUNICATION CIRCUIT 2
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key unit and steering lock unit connector.
3. Check continuity between Intelligent Key unit connector and steering lock unit connector.
4. Check continuity between Intelligent Key unit connector and
ground.
OK or NG
OK >> Check the condition of harness and connector. If it is OK, check the self-diagnosis results using
CONSULT-II again.
NG >> Repair or replace harness.
DTC B2552 INTELLIGENT KEYNIS001YP
DIAGNOSIS DESCRIPTION
B2552 Intelligent Key unit internal malfunction judges NG by self-detecting the Intelligent Key unit internal mal-
function.
If this DTC (Diagnostic Trouble Code) is displayed, replace the Intelligent Key unit and perform the specified
registration procedure. Refer to the Technical Bulletin.
DTC B2553 IGN POWER CIRCUITNIS001YQ
DIAGNOSIS DESCRIPTION
Though the power supply switching control to ON position by push-button ignition switch operation is per-
formed normally, if there is no ON power supply input to the Intelligent Key unit, B2553 ignition power supply
system judges it is the malfunction and displays the DTC (Diagnostic Trouble Code)
TERMINAL AND REFERENCE VALUE FOR INTELLIGENT KEY UNIT
CONSULT-II DATA MONITOR STANDARD VALUE
AB
Continuity
Intelligent Key
unit connectorTerminalSteering lock unit
connectorTerminal
M3217
M353
Ye s
18 8
A
GroundContinuity
Intelligent Key
unit connectorTerminal
M3217
No
18
PIIB6232E
Te r m i -
nal
No.Wire
colorItemCondition
Voltage (V)
(Approx.) Push-
button
ignition
switch
positionOperation or conditions
31 GRIgnition power supply
(ON)ONPower supply position is in ON or
START positionBattery voltage
Monitor item Measuring condition Reference value
ON POSPower supply position is in ON position ON
Power supply position is in any position other than ON OFF
Page 1103 of 5621

BL-164
INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
Revision: 2006 January2006 M35/M45
SELF-DIAGNOSTIC LOGIC
DIAGNOSTIC PROCEDURE
1. CHECK POWER SUPPLY CIRCUIT
With CONSULT-II
Check (“IGN ON SW”) in DATA MONITOR mode with CONSULT-II.
Without CONSULT-II
Check voltage between Intelligent Key unit connector and ground.
OK or NG
OK >> Check the condition of harness and connector. If it is
OK, check the self-diagnosis results using CONSULT-II
again.
NG >> Check Intelligent Key unit power supply circuit for open or short.
DTC B2554 ACC POWER CIRCUITNIS001YR
DIAGNOSIS DESCRIPTION
B2554 ACC power supply circuit monitors the following 2 signals.
Though the power supply switching control to ACC position by push-button ignition switch operation is
performed normally, if there is no ACC power supply input to the Intelligent Key unit, it judges that it is the
malfunction and displays the DTC (Diagnostic Trouble Code)
When performing the power supply switching control to ACC position by push-button ignition switch oper-
ation, if the power supply position switching cannot be performed because the wake-up signal is not
entered into PDU (Power Distribution Unit), it judges that it is the malfunction and displays the DTC (Diag-
nostic Trouble Code)
DTCSelf-diagnosis
nameDTC detecting condition Possible causes
B2553IGN POWER CIR-
CUITThough the changing control to ON position by push-
button ignition switch operation is performed normally,
ON position power supply to the Intelligent Key unit is
not supplied
10A fuse
Harness and connector
(Open or shorted in the circuit)
When ignition switch is turned to ON
IGN ON SW : ON
PIIB6233E
Terminals
Ignition switch
conditionVoltage (V)
(Approx.) (+)
(–)
Intelligent Key
unit connectorTerminal
M32 31 GroundON Battery voltage
OFF 0
PIIB6234E
Page 1104 of 5621

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION
BL-165
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 January2006 M35/M45
TERMINALS AND REFERENCE VALUE FOR INTELLIGENT KEY UNIT
CONSULT-II DATA MONITOR STANDARD VALUE
SELF-DIAGNOSTIC LOGIC
Te r m i -
nal
No.Wire
colorItemCondition
Voltage (V)
(Approx.) Push-
button
ignition
switch
positionOperation or conditions
30 L/WIgnition power supply
(ACC)ACCPower supply position is in ACC posi-
tionBattery voltage
42 P PDU wake up signalLOCKAt sleep (30 seconds or more after all
doors are closed under the condition
that the power supply position is in the
LOCK position)Battery voltage
— At wake-up (Open driver door) 0
Monitor item Measuring condition Reference value
ACC POSPower supply position is in ACC position ON
Power supply position is in any position other than ACC OFF
DTCSelf-diagnosis
nameDTC detecting condition Possible causes
B2554ACC POWER
CIRCUIT
Though the changing control to ACC position by push-button
ignition switch operation is performed normally, ACC position
power supply to the Intelligent Key unit is not supplied
The power supply position switching cannot be performed
because the wake-up signal is not entered into PDU (Power
Distribution Unit) during position changing control to ACC
position by push-button ignition switch operation
Fuse
Harness and connector
(Open or shorted in the cir-
cuit)
